GBEAST Wearable Bluetooth Speaker BH008A User Manual

1. परिचय

This manual provides detailed instructions for the safe and efficient use of your GBEAST Wearable Bluetooth Speaker BH008A. Please read this manual thoroughly before operating the device and retain it for future reference.

2. पॅकेज सामग्री

• 1 x GBEAST Wearable Bluetooth Speaker BH008A
• 1 x Adjustable Rope
• 1 x USB चार्जिंग केबल
• 1 x वापरकर्ता मॅन्युअल

3. उत्पादन संपलेview

The GBEAST Wearable Bluetooth Speaker BH008A is a compact and versatile audio device designed for portability and hands-free use. It features a clip-on design, Bluetooth 5.4 connectivity, a built-in microphone for calls, IPX6 waterproof rating, and integrated flashlight and RGB lighting functions.

आकृती 3.1: समोर view of the GBEAST Wearable Bluetooth Speaker BH008A, showcasing its compact design and control buttons.

4. सेटअप

३.१ स्पीकर चार्ज करणे

Before first use, fully charge the speaker. The speaker is equipped with a 700mAh rechargeable battery. A full charge takes approximately 2 hours and provides up to 30 hours of playtime at 60% volume.

आकृती 4.1: Connect the provided USB cable to the USB-C charging port on the speaker and a power source.

4.2 पॉवर चालू/बंद

• चालू करण्यासाठी: Press and hold the Function button (central button) for 3 seconds. The indicator light will illuminate, and you will hear an audible prompt.
• पॉवर ऑफ करण्यासाठी: Press and hold the Function button for 3 seconds. The indicator light will turn off, and you will hear an audible prompt.

4.3 ब्लूटूथ पेअरिंग

1. Ensure the speaker is powered on and in pairing mode (indicator light flashing blue).
2. तुमच्या डिव्हाइसवर (स्मार्टफोन, टॅबलेट, इ.), ब्लूटूथ सेटिंग्जमध्ये जा आणि उपलब्ध डिव्हाइस शोधा.
3. Select "BH008A" from the list. Once connected, the indicator light will turn solid blue, and you will hear a confirmation tone.

४.२ ट्रू वायरलेस स्टीरिओ (TWS) पेअरिंग

For an enhanced stereo experience, you can pair two GBEAST BH008A speakers together.

1. दोन्ही स्पीकर चालू आहेत आणि इतर कोणत्याही ब्लूटूथ डिव्हाइसशी कनेक्ट केलेले नाहीत याची खात्री करा.
2. Triple-press the Function button on एक of the speakers. This speaker will enter TWS pairing mode.
3. The speakers will automatically connect to each other. Once paired, the indicator lights on both speakers will synchronize.
4. Connect your device to one of the paired speakers via Bluetooth as described in section 4.3.

5. ऑपरेटिंग सूचना

5.1 संगीत प्लेबॅक

• प्ले/पॉज: Press the Function button once during music playback.
• आवाज वाढवणे: Press the "+" button. The speaker offers 16 precise volume levels.
• आवाज कमी: "-" बटण दाबा.
• पुढील गाणे: "+" बटण जास्त वेळ दाबा.
• मागील गाणे: "-" बटण जास्त वेळ दाबा.

४.२ हँड्स-फ्री कॉल्स

The speaker features a built-in ENC noise-canceling microphone for clear calls.

• उत्तर द्या/कॉल संपवा: एकदा फंक्शन बटण दाबा.
• कॉल नाकारणे: फंक्शन बटण दाबा आणि धरून ठेवा.

आकृती 5.1: The GBEAST speaker allows for hands-free calls, ideal for noisy environments like a jobsite.

Voice. Voice व्हॉईस सहाय्यक

Summon your device's voice assistant (Siri/Google) for convenient control.

• व्हॉईस सहाय्यक सक्रिय करा: Double-press the Function button.

आकृती 5.2: Voice control allows for seamless interaction with your device's assistant while on the go.

5.4 Flashlight & RGB Light

The speaker includes a versatile flashlight and dynamic RGB lighting.

• Turn on Flashlight: Press the flashlight button once. Press again for low brightness.
• Turn on RGB Light: Long press the flashlight button. The RGB light changes color to the rhythm of the music.

5.5 परिधान पर्याय

The lightweight design and strong clip allow for various wearing styles.

• Clip-On: Attach the speaker to tool belts, clothing collars, backpacks, or bike handlebars.
• डोंगर: Use the included adjustable rope to hang the speaker around your neck or wrist.

आकृती 5.3: The strong clip ensures the speaker stays secure during activities like cycling.

आकृती 5.4: The speaker can be clipped to a belt for hands-free audio during activities like golf.

6. देखभाल

५.१ जलरोधक आणि धूळरोधक

The GBEAST BH008A speaker has an IPX6 rating, making it resistant to water jets and dust. This means it can withstand outdoor rainy weather, water activities, or dusty environments.

• Do not submerge the speaker completely in water for extended periods.
• स्पीकरला पाणी किंवा धुळीच्या संपर्कात आणण्यापूर्वी चार्जिंग पोर्ट कव्हर सुरक्षितपणे बंद असल्याची खात्री करा.

आकृती 6.1: The IPX6 waterproof rating makes the speaker suitable for outdoor use in various weather conditions.

6.2 स्वच्छता

स्पीकरला मऊ, डीamp कापड कठोर रसायने किंवा अपघर्षक क्लीनर वापरू नका.

५.८.१ स्टोरेज

वापरात नसताना स्पीकर थेट सूर्यप्रकाशापासून आणि अति तापमानापासून दूर थंड, कोरड्या जागी ठेवा.

7. समस्या निवारण

• स्पीकर चालू होत नाही: बॅटरी चार्ज झाली आहे याची खात्री करा. पॉवर सोर्सशी कनेक्ट करा आणि पुन्हा प्रयत्न करा.
• ब्लूटूथ द्वारे पेअर करू शकत नाही: Ensure the speaker is in pairing mode (flashing blue light) and within range of your device. Disconnect from other devices if already paired.
• आवाज नाही: Check the volume levels on both the speaker and your connected device. Ensure the speaker is properly paired.
• TWS पेअरिंग अयशस्वी: Ensure both speakers are powered on, not connected to any other device, and within close proximity. Try resetting both speakers and attempting TWS pairing again.

8. तपशील

9. हमी आणि समर्थन

The GBEAST Wearable Bluetooth Speaker BH008A comes with a limited warranty. For detailed warranty information, product support, or technical assistance, please refer to the contact information provided on the product packaging or the official GBEAST webसाइट
