MOVON TDU-WBT-MSB Wi-Fi 6 and Bluetooth 5.x System Module

Product Specification

Revision History

Reference document

NXP 88W9098 (Concurrent Dual Wi-Fi (CDW) and Bluetooth 5.3 Combo SoC) – Data sheet
NXP 88W9098_UM11471_Design Guide for 88Q9098 and 88W9098
SD-WLAN-UART-BT-9098-LNX_5_15_71-IMX8-17.92.1.p136.13-17.92.1.p136.13-MM
88W9098_A1_RF_Performance_Report_WLAN
88W9098_A1_RF_Performance_Report_BT_BLE

Product description

The module is that the System on Module (SOM) designed according as the BIXOLON board to board specification for use with Wi-Fi6/Bluetooth 5.3 networks that provides IEEE 802.11a/b/g/n/ac/ax and

Bluetooth SIG 5.x mobile connectivity. This module is applicable to dedicated to BIXOLON POS, KIOSK and other potable device.

The purpose of this document is to describe the Wi-Fi/Bluetooth features and specifications of the SOM and to provide BIXOLON with the information required to integrate them into products.

So, in this document, only the specifications related to Wi-Fi and Bluetooth are specified, and specification related the host part (SAM9x60D1G, NAND Flash and MFI) is excluded.

But a block diagram, pin maps and power distribution network of whole SOM including SAM9x60D5MI/4FB are provided for system integration.

Application and hardware interface requirements are discussed at a high level only; for more detail, see the following chapter

Overview

• Board to board Wi-Fi6 and Bluetooth 5.x combo system on module (SOM type)
• Compact size as 40.5mm x 29.8mm x 5.9mm
• Compliance IEEE 8021.11a/b/g/n/ac/ax standard the module uses DSSS, OFDM, DBPSK, DQPSK and QAM baseband modulation technologies
• Compliance Bluetooth 5.3 SIG standard

Key Feature

– Wi-Fi

• Supports Wi-Fi6 dual MACs, independent MACs support true
• Not support dual band CDW (Only support 1×1 Wi-Fi RF front-end and RF PHY)
• Supports a 1X1 MISO configuration in both the Wi-Fi 2.4GHZ and 5GHz bands
• Two independent basebands, each band supporting independent Wi-Fi operation at 2.4GHz and 5GHz
• 5GHz PHY data rates up to 350Mbps@HE80, 2.4GHz PHY data rates up to 180 Mbps@HE20 Based on TCP/SDIO 3.0
• Uplink and downlink OFDMA and MU-MISO
• Supports WPA 3
• Supports OFDM A up to 1024 QAM and Target Wake Time (TWT)
• Instantaneous 0-DFS

– Bluetooth

• Bluetooth 5.3 SIG standard/specifications compliant
• Supports up to EDR 3Mbps
• Supports Low Energy 2Mbps and Long Range
• Up to 16 Bluetooth LE links in the connection mode

– Antenna and Co-existence

• Integrated two antennas as Wi-Fi and Bluetooth
• Implements advanced Wi-Fi and Bluetooth coexistence hardware in conjunction with algorithms to optimize collaborative performance
• Wi-Fi/Bluetooth coexistence protocol support

– Host interface

•  Supports SDIO 3.0 for Wi-Fi host interface and high-speed UART for Bluetooth host interface

Standard Compliance

• IEEE 802.11 a/b/g/n/ac/ax
• Bluetooth V5.3 SIG conformance

Application

• Dedicated BIXOLON portable devices (POS, fixed printer and portable printer)

Product Specifications

SW Block Diagram

(Software structure is depended on Operating Systems)

Specification Overview

– Wi-Fi RF performance

– Bluetooth RF performance

Pin Assignment

Pin allocations

Pin description

Electrical Specification

Power sequence

– Power up sequence

The external 1.8V_DUT and 3.3V_DUT shall not rise (10 – 90%) faster than 40 microseconds for minimize in-rush current and not slower than 100 milliseconds. PDN must be held low for at least 100 milliseconds after external 1.8V_DUT and 3.3V_DUT has reached specification level before pulled high.

– Power down sequence

– Reset

DC characteristics

– Power Tree

The module utilizes VDD_3.3V, 3.3V_DUT and 1.8V_DUT power sources.
Do not exceed minimum or maximum voltage. Module will be permanently damaged above this limit.

– Electrical characteristics

* The power supply must be designed for this maximum current

Power dashboard according to Wi-Fi/Bluetooth use cases

Mechanical Specifications

Product Drawing

Recommended B2B plug selection guide

Please refer to dimension in red box of figure below that is recommended plug dimension.

<B2B socket of module>

<Recommended B2B Plug>

Regulatory and compliance

FCC Compliance Statement

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

FCC Caution

Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Industry Canada Statement

This device complies with RSS-247 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Industry Canada Radiation Exposure Statement

This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body

Information on test modes and additional testing requirements

a) The modular transmitter has been fully tested by the module grantee on the required number of channels, modulation types and modes, it should not be necessary for the host installer to retest all the available transmitter modes or settings. It is recommended that the host product manufacturer installing the modular transmitter, perform some investigative measurements to confirm that the resulting composite system does not exceed the spurious emissions limits or band edge limits(e.g., where a different antenna may be causing additional emissions).
b) The testing should check for emissions that may occur due to the intermixing of emissions with the other transmitter, digital circuitry, or due to physical properties of the host product(enclosure).
This investigation is especially important when integrating multiple modular transmitters where the certification is based on testing each of them in a standalone configuration. It is important to note that host product manufactures should not assume that because the modular transmitter is certified that they do not have any responsibility for final product compliance.

Additional testing, Part 15 subpart B disclaimer

The final host/module combination need to be evaluated against the FCC Part 15B criteria for unintentional radiators in order to be properly authorized for operation as a Part 15 digital device.

The host integrator installing this module into their product must ensure that the final composite product complies with the FCC requirements by a technical assessment or evaluation to the FCC rules, including the transmitter operation and should refer to guidance in KDB 996369.

This appliance and its antenna must not be co-located or operation in conjunction with any other antenna or transmitter.

• OEM integrators must ensure that its product is electrically identical to the device, FCC ID:
  TDU-WBT-MSB reference designs . Any modifications to module reference designs may invalidate regulatory approvals in relation to the product, or may necessitate notifications to the relevant regulatory authorities.
• OEM integrators are responsible for regression testing to accommodate changes to designs, new antennas, and host and submit for C2PC filings.
• Colocation with other transmitter modules will be addressed through filings for those co-located transmitters when necessary or that colocation of other transmitters will be according to applicable KDB guidelines including those for RF exposure
• Appropriate labels must be affixed to the product that complies with applicable regulations in all respects. The regulatory label on the final system must include the statement:

“Contains FCC ID: TDU-WBT-MSB”.

“Contains IC Number: 6432A-WBTMSB”.

1. The module is limited to OEM installation ONLY.
2. OEM integrators are responsible for ensuring that the end-user has no manual instructions to remove or install module.
3. The module is limited to installation in mobile or fixed applications, according to Part 2.1091(b).
4. Separate approval is required for all other operating configurations, including portable configurations with respect to Part 2.1093 and different antenna configurations.

End Product Labeling

The module is labeled with its own FCC ID & IC Number. If the FCC ID & IC number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. In that case, the final end product must be labeled in a visible area with the following:

“Contains FCC ID: TDU-WBT-MSB”
“Contains IC Number: 6432A-WBTMSB”.
