Танилцуулга
Thank you for choosing the Verkstar 5-in-1 Wireless Bluetooth Karaoke Microphone. This device combines a microphone, Bluetooth speaker, recorder, music player, and voice changer into one portable unit. It is designed to provide an enjoyable audio experience with features like 3-layer noise reduction and LED lights. Please read this manual carefully to ensure proper use and optimal performance.
Image: The Verkstar Karaoke Microphone in blue, showcasing its design and integrated LED lights.
Хайрцагт юу байна
Хайрцагнаас задлахад бүх зүйл байгаа эсэхийг шалгана уу:
- Verkstar Karaoke Microphone
- Цэнэглэх кабель (USB)
- Аудио кабель (3.5 мм залгуур)
- Зааварчилгааны гарын авлага
Бүтээгдэхүүний онцлог
- 5-ын-1 функциональ байдал: Operates as a wireless microphone, Bluetooth speaker, music player, recorder, and voice changer.
- Өндөр дууны чанар: Features a professional tuning system and 3-layer noise reduction technology for clear audio.
- Динамик LED гэрэл: Colorful LED lights flash in rhythm with the music, enhancing the experience.
- Батерейны урт наслалт: Provides 6-8 hours of playtime on a full charge.
- Өргөн нийцтэй байдал: Connects with mobile phones, laptops, and other Bluetooth-enabled devices.
Зураг: дэлбэрсэн view diagram illustrating the 3-layered noise reduction system and indicating a working time of 6-8 hours for the microphone.
Тохируулах заавар
1. Микрофоныг цэнэглэх
Before first use, fully charge the microphone. Connect the provided USB charging cable to the microphone's charging port and a suitable USB power source (e.g., computer, wall adapter). The charging indicator light will show the charging status.
2. Асаах/унтраах
Press and hold the power button (usually located at the bottom of the control panel) for a few seconds to turn the microphone on or off. A voice prompt will indicate the power status.
3. Bluetooth хослол
To connect the microphone to your device (smartphone, tablet, laptop) via Bluetooth:
- Микрофоныг асаана уу. Энэ нь автоматаар Bluetooth хослуулах горимд орно.
- Мобайл төхөөрөмж дээрээ Bluetooth-г идэвхжүүлнэ үү.
- хайх available Bluetooth devices and select "WS-858" (or similar model name) from the list.
- Хослуулсны дараа дуут мэдэгдэл холболтыг баталгаажуулна.
Image: A smartphone displaying music lyrics, wirelessly connected to the Verkstar Karaoke Microphone via Bluetooth, indicating a 10-meter transmission range.
Image: The Verkstar Karaoke Microphone shown with icons representing compatibility with mobile phones, laptops, and various karaoke applications.
Ашиглалтын заавар
Хяналтын самбар дууссанview
Image: A detailed diagram of the microphone's control panel, clearly labeling each button's function, including volume, echo, track control, and mode switch.
| Товчлуур | Чиг үүрэг |
|---|---|
| Power Switch/Mode Change | Long press to power on/off. Short press to switch between modes (Bluetooth, Micro SD, USB). |
| PREV (Previous) | Өмнөх дууг богино хугацаанд дарна уу. |
| ДАРААГИЙН | Дараагийн дууг эхлүүлэхийн тулд богино дарна уу. |
| SCAN/LED | Short press to play/pause music. Double press to change LED light mode. |
| REC (Бичлэг) | Short press to start/stop recording (requires Micro SD card). |
| VOL+ (Music Volume Up) | Increase music playback volume. |
| VOL- (Music Volume Down) | Decrease music playback volume. |
| MIC VOL +/- | Микрофоны оролтын хэмжээг тохируулна уу. |
| REMIX +/- (Echo Volume) | Adjust the echo effect level. |
Using the Voice Changer
The microphone includes a voice changer function. To activate and cycle through different voice effects (e.g., child's voice, female voice, male voice, little devil voice, original sound), refer to the specific button on the control panel, often integrated with another function or a dedicated button.
Image: The Verkstar Karaoke Microphone displaying its smart LED dancing lights and illustrating various voice changer options such as child's, female, male, and little devil voices, along with the original sound.
Бичлэг хийх функц
To use the recording function, insert a Micro SD card into the designated slot. Press the "REC" button to start recording your performance. Press it again to stop. Recordings will be saved to the Micro SD card.
LED гэрлийн хяналт
The microphone features colorful LED lights. Double-press the "SCAN/LED" button to cycle through different light modes or turn them off.
Видео үзүүлбэр
Watch this video for a visual guide on using the Verkstar Karaoke Microphone.
Video: A demonstration of the Verkstar Karaoke Microphone's features and usage, including setup and various functions.
Засвар үйлчилгээ
- Цэвэрлэгээ: Use a soft, dry cloth to clean the microphone's exterior. Do not use harsh chemicals or abrasive cleaners.
- Хадгалах: Микрофоныг сэрүүн, хуурай газар, нарны шууд тусгал болон хэт өндөр температураас хол хадгална уу.
- Батерейны арчилгаа: To prolong battery life, avoid fully discharging the battery frequently. Charge the microphone regularly, even if not in use for extended periods.
- Чийгнээс зайлсхийх: Keep the microphone away from water and other liquids to prevent damage to internal components.
Алдааг олж засварлах
| Асуудал | Боломжит шалтгаан | Шийдэл |
|---|---|---|
| Микрофон асахгүй байна. | Батерей бага. | Микрофоныг бүрэн цэнэглэ. |
| Bluetooth-ээр холбогдож чадахгүй байна. | Bluetooth is off on device; microphone is out of range; incorrect pairing. | Ensure Bluetooth is enabled on your device. Move closer to the microphone. Re-scan and select "WS-858" to pair. |
| Чанга яригчаас дуу гарахгүй. | Volume too low; microphone not connected; music paused. | Increase music volume (VOL+) and microphone volume (MIC VOL+). Ensure Bluetooth is connected. Press SCAN/LED to play/pause. |
| Цуурайны нөлөө хэт хүчтэй/сул байна. | REMIX level incorrectly set. | Adjust the REMIX +/- buttons to your desired echo level. |
| Бичлэг ажиллахгүй байна. | No Micro SD card inserted; card full or corrupted. | Insert a Micro SD card. Ensure the card has sufficient space and is formatted correctly. |
Үзүүлэлтүүд
- Загварын дугаар: BT032AG
- Микрофоны хэлбэр хүчин зүйл: Гарын төхөөрөмж
- Хэмжээ (L x W x H): 9.57 x 3.35 x 3.35 инч
- Барааны жин: 12.6 унц
- Эрчим хүчний эх үүсвэр: Батерейгаар ажилладаг
- Материал: Хуванцар
- Дуу шуугианы харьцаа: 120 дБ
- Давтамжийн хариу: 10 кГц
- Холболтын технологи: Bluetooth
- Холбогч төрөл: 3.5 мм-ийн залгуур, USB
- Тохиромжтой төхөөрөмжүүд: Headphone, Laptop, Smartphone
- Оруулсан бүрэлдэхүүн хэсгүүд: Караоке микрофон
- Туйлын загвар: Нэг чиглэлтэй
Баталгаат хугацааны мэдээлэл
The Verkstar Karaoke Microphone BT032AG comes with a 1 жилийн баталгаат хугацаа from the date of purchase. This warranty covers manufacturing defects and malfunctions under normal use. It does not cover damage caused by misuse, accidents, unauthorized modifications, or normal wear and tear. Please retain your proof of purchase for warranty claims.
Хэрэглэгчийн дэмжлэг
For any questions, technical assistance, or warranty claims, please refer to the product packaging or the official Verkstar website for contact details. We offer 24-hour friendly customer service.
Please have your model number (BT032AG) and proof of purchase ready when contacting support.
