Apowking Portable Power Station E300 User Manual

1. Fampidirana

This manual provides essential instructions for the safe and efficient operation of your Apowking Portable Power Station E300. Please read this manual thoroughly before using the product and retain it for future reference.

The Apowking E300 is a versatile portable power station featuring a 256Wh LiFePO4 battery, capable of delivering 300W rated (600W peak) AC output. It is designed to provide reliable power for various devices during outdoor activities, emergencies, or as a home backup solution.

2. Torolàlana momba ny fiarovana

• Aza esorina na amboary na ovao ilay singa.
• Keep the unit away from fire or direct heat sources.
• Halaviro ny rano na ny hamandoana be.
• Do not use or store the unit in environments with high temperatures or direct sunlight.
• Ataovy izay hahazoana rivotra tsara mandritra ny fampiasana sy ny famandrihana.
• Arovy amin'ny ankizy sy ny biby fiompy.
• Use only recommended accessories and charging methods.
• This generator is designed to support devices with a power consumption lower than 300 Watt Hours. It may not be suitable for high-capacity products such as Electric Grills, Induction Cookers, Microwaves, and Refrigerators.
• Store the battery in a dry environment within the temperature range of 40°F~100°F (4°C~35°C) or in moisture-proof packaging. Keep it away from heat sources and avoid direct sunlight exposure.

3. Ny votoatin'ny fonosana

Hamarino fa tafiditra ao anatin'ny fonosanao ny entana rehetra:

• Apowking 256Wh/300W Portable Power Station (E300) x 1
• AC Power Adapter x 1
• Cable fiampangana fiara x 1
• Torolàlana ho an'ny mpampiasa x 1

4. Vokatra mihoatraview

Familiarize yourself with the components and ports of your Apowking E300 Portable Power Station.

Sary 1: Eo anoloana view of the Apowking E300 Portable Power Station, showing the display, AC outlets, USB ports, DC ports, and control buttons.

4.1 Seranana sy Bokotra

• Bokotra hery: Miverina / mamono ny singa.
• AC Output Switch: Activates/deactivates the AC outlets.
• DC Output Switch: Activates/deactivates the DC output ports.
• Bokotra fahazavana LED: Controls the built-in LED light (SOS, Strobe, Flashlight modes).
• LCD Display: Mampiseho ny haavon'ny bateria, ny herinaratra miditra/mivoakatage, ary ireo mari-pamantarana ny sata.
• AC Outlets (x2): 110V Pure Sine Wave, 300W Rated (600W Peak).
• Port USB-A (x2): 5V/3.1A Max.
• Seranan-tsambo USB-C (x1): 5V/3A, 9V/2A, 12V/1.5A (18W).
• DC Vehicle Output Ports (x3): 12V/10A.
• Seranana fidirana: For AC adapter, car charger, or solar panel.

5. Fametrahana sy fampiasana voalohany

5.1 Fametrahana voalohany

Before first use, fully charge the power station. This ensures optimal battery performance and longevity.

1. Connect the provided AC power adapter to the input port of the power station.
2. Ampidiro amin'ny fivoahana rindrina mahazatra ny adaptatera AC.
3. The LCD display will show the charging status. The unit is fully charged when the battery indicator shows 100%.
4. Charging typically takes 5-7 hours via the 19V/3.42A power adapter.

Figure 2: Charging the power station from a standard wall outlet.

6. Torolàlana miasa

6.1 Mampirehitra/Efa

• Mba hampandeha azy: Tsindrio ary hazòny ny Bokotra Hery for a few seconds until the LCD display illuminates.
• Mba hamonoana: Tsindrio ary hazòny ny Bokotra Hery for a few seconds until the LCD display turns off.

6.2 Fampiasana ny fivoahan'ny herinaratra

1. Ataovy azo antoka fa mandeha ny tobin-jiro.
2. Tsindrio ny AC Output Switch button to activate the AC outlets. The AC indicator on the display will light up.
3. Plug your AC device (up to 300W continuous, 600W peak) into one of the 110V AC outlets.
4. When you activate the AC output function, it is normal to see a red triangle indicator for AC output verification, which will disappear within 3-5 seconds.
5. To turn off AC output: Press the AC Output Switch bokotra indray.

Figure 3: The power station providing AC power for outdoor activities.

6.3 Using DC and USB Ports

1. Ataovy azo antoka fa mandeha ny tobin-jiro.
2. Tsindrio ny DC Output Switch button to activate the DC and USB ports. The DC and USB indicators on the display will light up.
3. Connect your USB or DC devices to the appropriate ports.
4. To turn off DC and USB output: Press the DC Output Switch bokotra indray.

Figure 4: The power station simultaneously charging a laptop, phone, and other small devices.

6.4 Mampiasa ny jiro LED

1. Ataovy azo antoka fa mandeha ny tobin-jiro.
2. Tsindrio ny Boky jiro LED once for constant illumination (Flashlight mode).
3. Press again for Strobe mode.
4. Tsindrio fanintelony raha hijery ny fomba SOS.
5. Press a fourth time to turn off the LED light.

Figure 5: The power station's LED light providing illumination in a dark environment.

7. Famandrihana ny toby famokarana herinaratra

The Apowking E300 offers multiple charging options:

7.1 AC Wall Charging

Use the included AC power adapter. Full charge in 5-7 hours.

Figure 6: Charging the power station from a standard wall outlet.

7.2 Famandrihana fiara

Use the included car charging cable. Full charge in 10-12 hours via a 12V car socket.

Figure 7: Charging the power station using a car's 12V outlet.

7.3 Solar Charging (Solar Panel Not Included)

The power station can be recharged using a compatible solar panel (recommended 40W-100W, input voltage range: DC13V-24V). Full charge in 7-10 hours depending on solar panel wattage sy ny toe-javatra misy ny tara-masoandro.

1. Connect the solar panel to the input port of the power station.
2. Position the solar panel in direct sunlight for maximum efficiency.
3. The LCD display will indicate charging status.

Figure 8: The power station being recharged by solar panels outdoors.

8. Fikojakojana sy fitehirizana

• Famerenana tsy tapaka: If not in use for an extended period, recharge the stored battery every 2-3 months and maintain it between 40%-70% capacity. Recharge the battery before it is completely depleted.
• Fepetra fitahirizana: Store the battery in a dry environment within the temperature range of 40°F~100°F (4°C~35°C) or in moisture-proof packaging. Keep it away from heat sources and avoid direct sunlight exposure.
• Fanadiovana: Mampiasà lamba maina sy malefaka hanadiovana ny ivelany amin'ilay fitaovana. Aza mampiasa ranon-javatra na mpanadio mikikitra.
• Faharetan'ny bateria: The high-quality LiFePO4 batteries are capable of supporting over 3500 charge cycles, ensuring long-term battery performance, reliability, and safety.

9. Famahana olana

10. Famaritana

11. Warranty sy fanohanana

Your Apowking Portable Power Station E300 is covered by a Garantie 12 volana from the date of purchase. This warranty covers manufacturing defects and workmanship.

For technical support, warranty claims, or any questions regarding your product, please contact Apowking Customer Service. Our team is available 7*24 ora to provide assistance.

Please refer to the contact information provided in your purchase documentation or visit the official Apowking webtranonkala ho an'ny antsipiriany fanohanana farany indrindra.

Figure 9: Apowking customer support details, including warranty, return policy, and availability.
