YXQUA LP-216302 USB Rechargeable Flashlight & Camp„Lantern“ vartotojo vadovas

1. Įvadas

Thank you for choosing the YXQUA LP-216302 USB Rechargeable Flashlight & Camping Lantern. This versatile device combines a powerful flashlight with a 360° COB camping lantern, offering multiple light modes and a power bank function. Designed for portability and durability, it is an essential tool for outdoor activities, emergencies, and everyday use. Please read this manual thoroughly before use to ensure proper operation and maintenance.

2. Saugos informacija

• Nežiūrėkite tiesiai į įjungtą LED lemputę, nes tai gali laikinai sutrikdyti regėjimą.
• Laikyti vaikams nepasiekiamoje vietoje.
• Do not disassemble, modify, or attempt to repair the device. This may void the warranty and pose a safety risk.
• Use only the provided or certified USB cables for charging.
• Avoid exposing the device to extreme temperatures, direct sunlight for prolonged periods, or highly corrosive environments.
• The device is IPX4 water-resistant, meaning it is protected against splashing water from any direction. Nemerkite prietaiso į vandenį.

3. Pakuotės turinys

• YXQUA LP-216302 Flashlight & Camping Žibintas
• USB įkrovimo laidas
• Vartotojo vadovas

4. Produkto ypatybės

• Aukštos Ryškumas: Equipped with 50 LED bulbs and upgraded headlamp chips, providing up to 500 lumens.
• 360° COB Light: Features a COB light with 3000-9000K color temperature for wide-area illumination.
• „Du viename“ dizainas: Functions as both a handheld flashlight and a compact camping lantern with a metal hook for hanging.
• 6 šviesos režimai: Includes Headlight (100%, 50%), COB White Light (100%, 50%), and COB Warm Light (100%, 50%).
• Įkraunamas: Built-in Lithium-Ion battery, fully charged via USB in approximately 2 hours, offering 3-10 hours of use depending on mode.
• Maitinimo banko funkcija: Integrated USB output port allows charging of mobile devices in emergencies.
• IPX4 atsparus vandeniui: Apsaugotas nuo vandens purslų.
• Patvari konstrukcija: Made from aluminum for lightweight and robust performance.

5. Produktas baigtasview

Figure 1: YXQUA LP-216302 Flashlight and Camping Lantern. This image shows the overall design of the product, highlighting its dual functionality as a flashlight and a lantern.

Figure 2: USB Charging and Output Ports. This image illustrates the location of the USB input for charging the device and the USB output for using it as a power bank.

Figure 3: Flashlight Spotlight and Side Lantern Modes. This image demonstrates the difference between the focused front spotlight and the wide-area side lantern illumination.

6. Sąranka

6.1 Pradinis mokestis

Before first use, fully charge the device. Connect the provided USB charging cable to the device's input port and to a USB power source (e.g., wall adapter, computer USB port). The charging indicator light will show the charging status. A full charge typically takes about 2 hours.

Figure 4: Charging the Device. This image shows the flashlight connected to a USB power source for charging.

7. Naudojimo instrukcijos

7.1 Įjungimas / išjungimas ir režimo pasirinkimas

The YXQUA LP-216302 features 6 light modes. Use the power button to cycle through modes and turn the device off.

1. Trumpas paspaudimas: Press the power button briefly to cycle through the 6 light modes in the following order:
   • Headlight 100% brightness (approx. 2-3 hours runtime)
   • Headlight 50% brightness (approx. 3-4 hours runtime)
   • COB White Light 100% brightness (approx. 3-4 hours runtime)
   • COB White Light 50% brightness (approx. 8-9 hours runtime)
   • COB Warm Light 100% brightness (approx. 3-4 hours runtime)
   • COB Warm Light 50% brightness (approx. 8-9 hours runtime)
2. Long Press to Turn Off: To turn off the light from any mode, press and hold the power button for approximately 2-3 seconds.
3. Quick Turn Off: Alternatively, after cycling through all modes, wait 5-8 seconds, then click the button again to turn off the light.

Figure 5: Light Modes and Operation. This diagram illustrates the different light modes and how to switch between them using short presses and turn off using a long press.

7.2 Naudojimas kaip išorinės baterijos

The device can be used to charge other USB-powered devices in an emergency.

1. Ensure the flashlight has sufficient charge.
2. Connect your mobile device's charging cable to the USB output port on the flashlight.
3. Įkrovimas prasidės automatiškai.

Figure 6: Emergency Phone Charging. This image shows the flashlight being used to charge a smartphone via its USB output port.

7.3 Flashlight and Lantern Functionality

The YXQUA LP-216302 offers both a focused beam and a wide-area lantern light.

• Žibintuvėlio režimas: The front LED provides a concentrated beam for long-distance illumination (up to 150 meters / 500 feet).
• Žibinto režimas: The side COB light emits a 360° diffused light, ideal for lighting up tents, rooms, or work areas. Use the integrated metal hook to hang the lantern for overhead lighting.

7 paveikslas: Camping Lantern Use. This image shows the device functioning as a lantern, illuminating the inside of a tent.

Figure 8: Illumination Capabilities. This image illustrates the maximum distance of the flashlight beam and the area covered by the lantern mode.

8. Priežiūra

• Valymas: Nuvalykite prietaisą minkšta, damp audinys. Nenaudokite abrazyvinių valiklių ar tirpiklių.
• Saugykla: Store the device in a cool, dry place away from direct sunlight and extreme temperatures. If storing for extended periods, charge the battery every 3-6 months to maintain battery health.
• Atsparumas vandeniui: The IPX4 rating protects against splashes. Ensure the USB port cover is securely closed to maintain water resistance. Do not immerse in water.

9. Problemų sprendimas

10. Specifikacijos

11. Oficialus produkto vaizdo įrašas

12. Garantija ir palaikymas

This product comes with a standard manufacturer's warranty. For detailed warranty information, technical support, or customer service inquiries, please refer to the contact information provided on the product packaging or the official YXQUA websvetainėje. Prašome išsaugoti pirkimo įrodymą garantiniams reikalavimams.
