1. ບົດແນະນຳ
This manual provides essential information for the safe and efficient operation, installation, and maintenance of your JINJUNYE 18000BTU Mini Split Air Conditioner. Please read this manual thoroughly before using the appliance and retain it for future reference.
2. ຂໍ້ມູນຄວາມປອດໄພ
ປະຕິບັດຕາມຄວາມລະມັດລະວັງດ້ານຄວາມປອດໄພຕໍ່ໄປນີ້ສະເໝີເພື່ອປ້ອງກັນການບາດເຈັບ ຫຼືຄວາມເສຍຫາຍຂອງໜ່ວຍ.
- ຕ້ອງມີການຕິດຕັ້ງແບບມືອາຊີບ: This unit requires professional installation by a qualified technician. Improper installation can lead to electric shock, fire, or water leakage.
- ຄວາມປອດໄພທາງໄຟຟ້າ: Ensure the power supply matches the unit's specifications (208-230V). Do not operate with wet hands. Do not modify the power cord or plug.
- ຕູ້ເຢັນ: This unit uses R-32 refrigerant. Handle with care and ensure proper ventilation during installation and servicing.
- ເດັກນ້ອຍແລະສັດລ້ຽງ: ຮັກສາເດັກນ້ອຍ ແລະສັດລ້ຽງຢູ່ຫ່າງຈາກຫນ່ວຍບໍລິການໃນລະຫວ່າງການປະຕິບັດງານ ແລະບໍາລຸງຮັກສາ.
- ການເກັບກູ້: Maintain adequate clearance around both indoor and outdoor units for proper airflow.
- ບໍາລຸງຮັກສາ: ຕັດການເຊື່ອມຕໍ່ໄຟຟ້າກ່ອນທຳຄວາມສະອາດ ຫຼື ບຳລຸງຮັກສາໃດໆ.
3. ຜະລິດຕະພັນເກີນview
The JINJUNYE 18000BTU Mini Split Air Conditioner is a ductless inverter heating and cooling system designed for efficient climate control in spaces up to 1250 sq. ft. It features advanced inverter technology for energy saving and a 17 SEER2 rating.
ສ່ວນປະກອບລວມ:
- ຫນ່ວຍງານພາຍໃນ
- ໜ່ວຍນອກ
- ການຄວບຄຸມໄລຍະໄກ & ຫມໍ້ໄຟ
- 18.45ft Signal Cable
- Refrigerant Pipe (17ft *2)
- Drain Hose (6.5ft*2)
- ເສອແຂນຝາ
- Sealing Gum*2, Tape*2, Drab Joint, Wall Cover
- ຄູ່ມືຜູ້ໃຊ້
- Guide Plate, Rubber Feet, Screws, Remote Holder, Heat Preservation Tube
4. ການຕິດຕັ້ງແລະການຕິດຕັ້ງ
ສຳຄັນ: Installation of this mini split system requires specialized tools and knowledge. It must be performed by a certified HVAC professional to ensure proper function, safety, and warranty validity.
Key Installation Steps (for professional reference):
- ການເລືອກເວັບໄຊ: Choose appropriate locations for both indoor and outdoor units, ensuring adequate clearance, structural support, and drainage.
- ການຕິດຕັ້ງ: Securely mount the indoor unit to the wall and the outdoor unit on a stable surface or wall bracket.
- ການເຊື່ອມຕໍ່ທໍ່: ເຊື່ອມຕໍ່ທໍ່ສານເຮັດຄວາມເຢັນລະຫວ່າງໜ່ວຍພາຍໃນ ແລະ ພາຍນອກ. ຮັບປະກັນການເປີດ ແລະ ຮັດແໜ້ນທີ່ເໝາະສົມເພື່ອປ້ອງກັນການຮົ່ວໄຫຼ.
- ສາຍໄຟຟ້າ: Connect the signal cable and power wiring according to the wiring diagram provided in the full installation manual. Ensure all electrical connections are secure and comply with local codes.
- ການສາກໄຟສູນຍາກາດ ແລະເຄື່ອງເຮັດຄວາມເຢັນ: Evacuate the refrigerant lines to remove air and moisture. If necessary, add additional R-32 refrigerant to achieve optimal performance.
- ການລະບາຍນໍ້າ: ເຊື່ອມຕໍ່ທໍ່ລະບາຍນ້ຳອອກຈາກໜ່ວຍພາຍໃນເພື່ອຮັບປະກັນການກຳຈັດນ້ຳທີ່ລະລາຍອອກມາຢ່າງຖືກຕ້ອງ.
- ກວດສອບຮົ່ວ: Perform a thorough leak check on all refrigerant connections.
- ແລ່ນທົດສອບ: Conduct a test run in all modes (cooling and heating) to verify correct operation.
5. ຄໍາແນະນໍາການດໍາເນີນງານ
Your JINJUNYE Mini Split Air Conditioner offers multiple modes and features for customized comfort.
ຮູບແບບການເຮັດວຽກ:
- ໂໝດເຮັດຄວາມເຢັນ: Cools the room to a set temperature, down to 61°F (16°C).
- ໂໝດທຳຄວາມຮ້ອນ: Heats the room to a set temperature, up to 88°F (31°C).
- ແບບພັດລົມ: Circulates air without cooling or heating. Features 8 air speed adjustments and 4D airflow.
- ໂໝດແຫ້ງ (Dehumidification): ຫຼຸດຜ່ອນຄວາມຊຸ່ມຊື່ນໃນອາກາດ.
- ແບບອັດຕະໂນມັດ: Automatically selects the appropriate mode (cooling, heating, or fan) based on the room's ambient temperature.
ຫນ້າທີ່ພິເສດ:
- ຟັງຊັນນອນ: Operates at an ultra-quiet 22dB, adjusting temperature for comfortable sleep.
- ໂມງຈັບເວລາ: Set the unit to turn on or off automatically within a 0.5-24 hour period.
- ຟັງຊັນແບບປະຢັດ: Optimizes operation for energy saving.
- ຟັງຊັນປິດສຽງ: ຫຼຸດຜ່ອນສິ່ງລົບກວນໃນການດຳເນີນງານໃຫ້ຕໍ່າສຸດເທົ່າທີ່ເປັນໄປໄດ້.
- ຟັງຊັນ Turbo: ໃຫ້ຄວາມເຢັນ ຫຼື ຄວາມຮ້ອນຢ່າງໄວວາ ສຳລັບການປ່ຽນແປງອຸນຫະພູມຢ່າງໄວວາ.
- ໜ້າທີ່ດ້ານສຸຂະພາບ: Activates features designed to improve air quality.
- ຟັງຊັນ Swing: Controls the direction of airflow (vertical and horizontal).
- ລັອກເດັກ: Locks the remote control to prevent accidental changes.
- I Set (Memory Function): Remembers your preferred settings (temperature, mode, fan speed) for quick recall.
- ຂ້ອຍຮູ້ສຶກວ່າ: The remote control senses the temperature at its location and adjusts the unit's operation for localized comfort.
6. ບໍາລຸງຮັກສາ
ການບໍາລຸງຮັກສາເປັນປົກກະຕິຮັບປະກັນປະສິດທິພາບທີ່ດີທີ່ສຸດແລະອາຍຸຍືນຂອງເຄື່ອງປັບອາກາດຂອງທ່ານ.
ຟັງຊັນທໍາຄວາມສະອາດດ້ວຍຕົນເອງ:
- The unit features a 131°F (55°C) high-temperature self-cleaning function for the indoor coil. This helps to remove accumulated dust and bacteria, ensuring fresh air.
- To activate, refer to your remote control or the full user manual for specific instructions.
ທໍາຄວາມສະອາດການກັ່ນຕອງ:
- The air filter can be easily removed and cleaned under running water.
- Clean the filter regularly, especially when a "CL" code appears on the display, to maintain airflow and efficiency.
- Allow the filter to dry completely before reinserting it into the indoor unit.
ການບຳລຸງຮັກສາໜ່ວຍກາງແຈ້ງ:
- Keep the area around the outdoor unit clear of obstructions (leaves, debris) to ensure proper airflow.
- The outdoor unit includes an automatic defrost function to prevent ice buildup and maintain efficiency in cold weather.
- The air-cooled technology helps cool down the temperature of the outdoor unit's components, allowing it to withstand high operating temperatures up to 132°F (55.5°C).
7. ການແກ້ໄຂບັນຫາ
ກ່ອນທີ່ຈະຕິດຕໍ່ສະຫນັບສະຫນູນລູກຄ້າ, ກະລຸນາເບິ່ງບັນຫາທົ່ວໄປຕໍ່ໄປນີ້ແລະວິທີແກ້ໄຂ.
| ບັນຫາ | ສາເຫດທີ່ເປັນໄປໄດ້ | ການແກ້ໄຂ |
|---|---|---|
| ຫນ່ວຍບໍລິການບໍ່ເປີດ | ບໍ່ມີໄຟຟ້າ, ເບກເກີຕັດວົງຈອນ, ແບັດເຕີຣີຣີໂໝດໝົດ. | ກວດສອບການສະຫນອງພະລັງງານ, reset breaker circuit, ທົດແທນຫມໍ້ໄຟທາງໄກ. |
| ຄວາມເຢັນ/ຄວາມຮ້ອນບໍ່ພຽງພໍ | Dirty air filter, blocked outdoor unit, wrong mode selected, temperature setting too high/low. | Clean air filter, clear obstructions from outdoor unit, select correct mode, adjust temperature setting. |
| ສຽງຜິດປົກກະຕິ | ຊິ້ນສ່ວນທີ່ວ່າງ, ວັດຖຸແປກປອມ, ຫົວໜ່ວຍບໍ່ໄດ້ຮາບພຽງ. | Inspect for loose parts or foreign objects. Ensure unit is installed on a level surface. If noise persists, contact a professional. |
| ນ້ໍາຮົ່ວໄຫຼຈາກຫນ່ວຍບໍລິການພາຍໃນ | ທໍ່ລະບາຍນ້ໍາອຸດຕັນ, ການຕິດຕັ້ງທີ່ບໍ່ຖືກຕ້ອງ. | Check and clear the drain hose. If issue persists, professional inspection is required. |
| ການຄວບຄຸມໄລຍະໄກບໍ່ເຮັດວຽກ | ຫມໍ້ໄຟທີ່ຕາຍແລ້ວ, ການຂັດຂວາງລະຫວ່າງຫ່າງໄກສອກຫຼີກແລະຫນ່ວຍ. | Replace batteries. Ensure clear line of sight to the indoor unit's receiver. |
For issues not listed here or if solutions do not resolve the problem, please contact JINJUNYE customer support.
8. ຂໍ້ມູນຈໍາເພາະ
Detailed technical specifications for the JINJUNYE 18000BTU Mini Split Air Conditioner.
- ຍີ່ຫໍ້: ຈິນຈູນ
- ໝາຍເລກຕົວແບບ: KF450068-02
- ຄວາມອາດສາມາດເຮັດຄວາມເຢັນ: 18,000 BTU
- ຄວາມອາດສາມາດເຮັດຄວາມຮ້ອນ: 19,000 BTU
- SEER2 Rating: 17
- ສະບັບtage: 208-230 ໂວນ
- ວັດtage: 1770 ວັດ
- ລະດັບສຽງລົບກວນ: 22 ເດຊີເບວ (ໃນໂໝດນອນຫຼັບ)
- ປະເພດຕູ້ເຢັນ: R-32
- ພື້ນທີ່ຄອບຄຸມ: ເຖິງ 1250 ຕາແມັດ
- ຂະໜາດຫົວໜ່ວຍພາຍໃນ: 35.82" W x 11.57" H x 8.11" D
- ນ້ໍາຫນັກລາຍການ: 85.4 ປອນ (ລະບົບທັງຫມົດ)
- ວັດສະດຸ: ເຫຼັກ, ທອງແດງ, ພາດສະຕິກ
- ຄຸນນະສົມບັດພິເສດ: 4 Way Swing, Fast Cooling, Heating & Cooling Function, Remote Controlled, Sleep Mode, Self-Cleaning, Inverter Technology.
9. ການຮັບປະກັນແລະການສະຫນັບສະຫນູນ
For warranty information, please refer to the documentation included with your product or contact JINJUNYE customer support directly. Professional installation is often a prerequisite for warranty validity.
ການຊ່ວຍເຫຼືອລູກຄ້າ:
For technical assistance, troubleshooting beyond this manual, or warranty claims, please contact JINJUNYE customer support. Refer to the contact information provided in your product packaging or on the official JINJUNYE webເວັບໄຊ.
You may also find support resources on the JINJUNYE Store on Amazon.
