홀펜리 어린이용 맥박 산소 측정기 사용 설명서

소개

About the HOLFENRY Children Pulse Oximeter

The HOLFENRY Children Pulse Oximeter is a multifunctional device designed specifically for children to measure blood oxygen saturation (SpO2), pulse rate, and perfusion index (PI). Its child-specific size and comfortable design make it suitable for small fingers. Please note: This device is not suitable for children under 2 years old.

This pulse oximeter is intended for sport and aviation use, suitable for sports enthusiasts or anyone interested in measuring SpO2 and pulse rate, especially during high endurance and outdoor activities like mountain climbing, running, or cycling.

The HOLFENRY Children Pulse Oximeter features a friendly blue penguin design, making it less intimidating for young users. It displays blood oxygen saturation (%SpO2) and pulse rate (PI) readings clearly.

설정

언박싱 및 구성품

Your HOLFENRY Children Pulse Oximeter package includes everything you need to get started:

• 1 x Children Pulse Oximeter
• AAA 배터리 2개(포함)
• 1 x 라니어드
• 1 x 사용자 설명서

The product package includes the children's pulse oximeter, two AAA batteries, a lanyard for portability, and a user manual for detailed instructions.

배터리 설치

To install the batteries, gently slide off the battery compartment cover located at the back of the device. Insert the two AAA batteries, ensuring correct polarity as indicated inside the compartment. Replace the cover securely.

This diagram illustrates the correct method for installing AAA batteries, ensuring proper polarity for device operation.

Official video demonstrating the features and usage of the HOLFENRY pediatric pulse oximeter, including battery installation.

작동 지침

사용 방법

1. Click the power button (shaped like a beak) to turn on the oximeter.
2. 뚜껑을 살며시 여세요amp and place the child's finger into the measuring hole. Ensure the finger is fully inserted and the device is securely clipped.
3. Keep the child's hand still during the measurement. The device will display results within 20-30 seconds.
4. If the reading varies greatly, wait for the reading to stabilize as a steady reading is the most accurate.

The HOLFENRY Children Pulse Oximeter is designed for children aged 2 and above, providing a comfortable and easy way to monitor their health.

측정 위치

The pediatric pulse oximeter is versatile and can be used on various parts of a child's body for accurate readings:

• 손가락: The most common and recommended site for measurement.
• 발가락: Suitable for smaller children or when finger measurement is difficult.
• Ball of the Foot: An alternative for infants or very young children, though the product description states it's not suitable for children under 2 years old.

The pulse oximeter supports multi-site measurement, allowing for readings to be taken comfortably from a child's finger, toe, or the ball of their foot.

독서 이해

The large display shows the following measurements:

• SpO2 (%): Blood Oxygen Saturation, indicating the percentag산소로 포화된 혈액 속의 헤모글로빈.
• PR(bpm): Pulse Rate, or heart rate, measured in beats per minute.
• PI(%): Perfusion Index, which indicates the strength of the pulse signal.

The device provides accurate measurements for Oxygen Saturation (SpO2), Pulse Rate (PR), and Perfusion Index (PI) within seconds, with specified ranges and resolutions.

자동 종료

To conserve battery life, the HOLFENRY Children Pulse Oximeter automatically shuts off after 8 seconds of non-use. This low energy design ensures extended operational time.

Designed for low energy consumption, the oximeter automatically shuts off after 8 seconds of non-use, providing up to 18 hours of continuous operation on two AAA batteries.

유지

청소 및 보관

맥박산소측정기의 수명과 정확성을 보장하려면 다음 유지 관리 지침을 따르십시오.

• 청소: 부드러운 천으로 기기를 닦습니다 dampened with a mild disinfectant (e.g., 70% isopropyl alcohol). Do not immerse the device in water or any cleaning solution. Ensure the device is completely dry before storage or next use.
• 저장: Store the oximeter in a cool, dry place away from direct sunlight and extreme temperatures. When not in use for extended periods, it is recommended to remove the batteries to prevent leakage.

문제 해결

일반적인 문제 및 솔루션

• 일관되지 않은 판독값: If the readings vary greatly, ensure the child's finger is fully inserted into the device and remains still during the measurement. Movement can affect accuracy. Wait for the reading to stabilize for the most accurate result.
• "Finger Out" or No Reading: Ensure the finger is properly placed within the clamp. The device requires proper contact to detect a pulse.
• Abnormality Reminder (Flashing Readings): If the device displays flashing readings, it indicates that the measured levels (SpO2, Pulse Rate, or PI) are lower than normal. Consult a healthcare professional if you observe persistent abnormal readings.
• 장치가 켜지지 않음: Check if the batteries are correctly installed with the proper polarity. Replace the batteries if they are depleted.
• Not Suitable for Very Young Children: Please note that this pulse oximeter is designed for children aged 2 years and above. It may not provide accurate readings or fit properly on children younger than 2 years old.

The device includes an abnormality reminder feature where readings will flash if they are lower than normal, alerting the user to potential issues.

명세서

보증 및 지원

For any questions, technical support, or warranty inquiries regarding your HOLFENRY Children Pulse Oximeter, please contact the manufacturer directly or visit the official HOLFENRY store.

Official HOLFENRY Store: HOLFENRY Store on Amazon

법적 고지: 건강 보조 식품에 관한 진술은 FDA에서 평가하지 않았으며, 어떠한 질병이나 건강 상태를 진단, 치료, 완치 또는 예방하기 위한 것이 아닙니다.
