소개
Thank you for choosing the RUBOT Mini Car Vacuum Cleaner P12. This compact and powerful handheld vacuum is designed for efficient cleaning in various environments, including your car, home, and office. Please read this manual thoroughly before operating the device to ensure safe and optimal performance. Keep this manual for future reference.
Image: The RUBOT Mini Car Vacuum Cleaner P12, showcasing its sleek, compact design in red.
패키지 내용
상자를 풀 때 모든 품목이 있는지 확인하세요.
- RUBOT Mini Car Vacuum Cleaner P12 (Main Unit)
- 2-in-1 Crevice Tool (with retractable brush)
- Blowing Hose
- USB Type-C 충전 케이블
- HEPA 필터(사전 설치)
- 예비 HEPA 필터
- Cleaning Brush for Filter
- 보관 가방
- 사용 설명서 (본 문서)
Image: All components included with the RUBOT Mini Car Vacuum Cleaner P12, laid out on a surface.
설정
1. 초기 충전
Before first use, fully charge the vacuum cleaner. The device features a built-in Lithium-Ion battery.
- Connect the USB Type-C charging cable to the charging port located at the rear of the vacuum.
- Connect the other end of the USB cable to a compatible USB power source (e.g., car charger, power adapter, computer USB port).
- The indicator lights will show charging status. A full charge typically takes approximately 4 hours.
- 완전히 충전되면 충전 케이블을 분리하세요.
Image: The RUBOT Mini Car Vacuum Cleaner P12 connected to a USB-C charger, illustrating the charging process.
2. 액세서리 부착
The vacuum comes with versatile attachments for different cleaning needs:
- 2-in-1 틈새 도구: This tool can be used as a narrow nozzle for tight spaces or with its retractable brush for upholstery and carpets. Simply slide the brush head forward or backward to switch modes. Attach it to the suction inlet at the front of the vacuum.
- Blowing Hose: For blowing dust out of hard-to-reach areas, attach the blowing hose to the exhaust port at the rear of the vacuum.
Image: The RUBOT Mini Car Vacuum Cleaner P12 demonstrating the attachment of the 2-in-1 crevice tool and the blowing hose for different functions.
작동 지침
1. 전원 켜기/끄기 및 속도 조절
The vacuum features a push-button control for power and two suction speeds:
- Press the power button once to turn on the vacuum at the standard suction speed (8K PA).
- Press the power button a second time to switch to the high suction speed (16K PA) for more powerful cleaning.
- 전원 버튼을 세 번 눌러 진공을 끕니다.
Image: The RUBOT Mini Car Vacuum Cleaner P12 illustrating its two-speed adjustment feature for different cleaning intensities.
2. 진공 청소
Use the appropriate attachment for the surface you are cleaning:
- For general debris on flat surfaces, use the narrow nozzle.
- For pet hair, crumbs, or dust on upholstery, carpets, or keyboards, extend the brush on the 2-in-1 crevice tool.
- Move the vacuum slowly over the area to ensure thorough cleaning.
Image: The RUBOT Mini Car Vacuum Cleaner P12 being used to clean crumbs and debris from a car's center console.
3. 송풍 기능
To use the blowing function:
- Attach the blowing hose to the exhaust port at the rear of the vacuum.
- Turn on the vacuum. Air will be expelled from the hose, allowing you to dislodge dust and debris from crevices, keyboard keys, or other hard-to-reach spots.
Video: Official RUBOT video demonstrating the vacuum's suction and blowing capabilities, including cleaning car interiors and keyboards.
유지
1. 먼지통 비우기
For optimal suction, empty the dust container regularly, especially after each use or when it appears full.
- Twist the dust container counter-clockwise to detach it from the main unit.
- Carefully remove the HEPA filter from the dust container.
- Empty the collected debris into a trash bin.
2. HEPA 필터 청소
The HEPA filter is washable and reusable. Regular cleaning ensures efficient filtration and suction power.
- After emptying the dust container, gently tap the HEPA filter to dislodge any remaining dust. Use the provided cleaning brush for thorough cleaning.
- Rinse the HEPA filter under running water until clean. Do not use hot water or detergents.
- Allow the filter to air dry completely before reinserting it into the dust container. Ensure it is completely dry to prevent mold or damage to the vacuum.
- Reassemble the filter and dust container, then attach them back to the main unit by twisting clockwise until secure.
Important: Do not immerse the main vacuum unit in water.
Image: A visual guide demonstrating the steps to remove, clean, and reassemble the washable HEPA filter.
문제 해결
| 문제 | 가능한 원인 | 해결책 |
|---|---|---|
| 전원이 켜지지 않음/켜지지 않음 | 배터리가 소진되었습니다. | 진공청소기를 완전히 충전합니다(약 4시간). |
| 흡입력이 약하다 | 먼지통이 가득 찼습니다. HEPA 필터가 막혔습니다. 부착물이 제대로 고정되지 않았습니다. | 먼지통을 비우세요. HEPA 필터를 청소하거나 교체하십시오. Ensure attachments are firmly connected. |
| 진공이 예기치 않게 멈춤 | 배터리가 부족합니다. 과열 보호 기능이 활성화되었습니다. | 배터리를 충전하세요. Turn off the vacuum and let it cool down for 15-30 minutes before resuming use. |
| 송풍 기능이 약합니다. | Blowing hose not properly attached. | Ensure the blowing hose is securely attached to the exhaust port. |
If the problem persists after trying these solutions, please contact RUBOT customer support.
명세서
| 상표 | 루봇 |
| 모델명 | 피12 |
| 폼 팩터 | 핸드헬드 |
| 특별 기능 | Compact, Portable, Cordless, Blowing Function |
| 흡입력 | 8K PA (Standard), 16K PA (High) |
| 배터리 유형 | 리튬이온 |
| 충전 시간 | 약 4시간 |
| 실행 시간 | Approx. 25-30 Minutes (depending on speed setting) |
| 연결 기술 | USB 타입-C |
| 필터 유형 | 세척 가능한 HEPA 필터 |
| 소음 수준 | <75 데시벨 |
| 제품 치수 | 5 x 2 x 2인치(대략) |
| 품목 무게 | 1.79파운드(대략) |
| 색상 | 빨간색 |
보증 및 지원
RUBOT products come with a comprehensive warranty and dedicated customer support:
- 24 월 보증 : Your RUBOT Mini Car Vacuum Cleaner P12 is covered by a 24-month warranty from the date of purchase.
- 12개월 교환 보증: In case of manufacturing defects, a replacement will be provided within 12 months.
- 30일 반품 정책: 안심하고 구매하실 수 있도록 30일 반품 정책을 제공합니다.
- Lifelong Free HEPA Filter: Benefit from lifelong free HEPA filter replacements.
- 24/7 Email Assistant: For any questions or issues, please contact the RUBOT Customer Team. We aim to reply within 12 hours.
For support, please refer to the contact information provided on the product packaging or the official RUBOT web대지.
Image: Graphic detailing RUBOT's customer care, including warranty, replacement, and support contact.
