H.Koenig Mini Blender SMOO10 User Manual

1. 서론

Thank you for choosing the H.Koenig Mini Blender SMOO10. This portable and compact blender is designed to help you prepare fresh, healthy smoothies and drinks quickly and easily. With its powerful 300W motor, 4 stainless steel blades, and two 570mL BPA-free travel bottles, it's perfect for a healthy lifestyle on the go.

This manual provides essential information for the safe and efficient use of your blender. Please read it thoroughly before first use and keep it for future reference.

2. 중요 안전 지침

전기 제품을 사용할 때는 화재, 감전 및/또는 인명 부상의 위험을 줄이기 위해 다음 사항을 포함한 기본적인 안전 예방 조치를 항상 따라야 합니다.

• 기기를 작동하기 전에 모든 지침을 읽으십시오.
• 모터 베이스를 물이나 다른 액체에 담그지 마십시오.amp 천만.
• 사용하지 않을 때, 부품을 조립하거나 분해하기 전, 그리고 청소하기 전에는 항상 블렌더의 전원 플러그를 콘센트에서 뽑으십시오.
• Avoid contact with moving parts. The blades are sharp. Handle with care.
• 코드나 플러그가 손상된 경우, 또는 제품이 오작동하거나 어떤 방식으로든 떨어뜨리거나 손상된 후에는 제품을 작동하지 마십시오.
• Do not blend hot liquids, as this may cause pressure buildup and result in scalding.
• Ensure the blade assembly is securely attached to the bottle and the bottle is correctly seated on the motor base before operating.
• Do not overfill the blending bottle.
• 본 기기는 신체적, 감각적 또는 정신적 능력이 저하된 사람(어린이 포함)이나 경험 및 지식이 부족한 사람이 사용하도록 의도된 것이 아니며, 안전을 책임질 사람으로부터 기기 사용에 관한 감독이나 지시를 받은 경우에만 사용할 수 있습니다.
• 제조업체에서 권장하지 않거나 판매하지 않는 부착물을 사용하지 마십시오.

3. 제품 구성품

Your H.Koenig Mini Blender SMOO10 comes with the following components:

• Motor Base (with power button)
• Blade Assembly (with 4 stainless steel blades)
• 2 x 570 mL Blending/Travel Bottles (BPA-free)
• 2 x Travel Lids with drinking spout
• 2 x Silicone Grips (for bottles)

Image: The H.Koenig Mini Blender SMOO10 showing its main components: the motor base, two blending bottles, and the blade assembly.

4. 설정 및 첫 사용

4.1 풀기

Carefully remove all components from the packaging. Retain the packaging for future storage or transport if needed. Check for any damage. If any parts are damaged or missing, contact customer support.

4.2 처음 사용 전 청소

Before using your blender for the first time, wash the blending bottles, travel lids, and blade assembly in warm, soapy water. Rinse thoroughly and dry. The bottles and lids are dishwasher safe. Wipe the motor base with a damp 천에 묻히지 않도록 주의하세요. 절대로 물에 담그지 마세요.

4.3 조립

1. 모터 베이스를 깨끗하고, 건조하고, 안정적인 표면에 놓으세요.
2. 모터 받침대가 전원 콘센트에서 분리되어 있는지 확인하십시오.
3. Prepare your ingredients (see Section 5.1).

Image: The H.Koenig Mini Blender SMOO10 fully assembled with a blending bottle containing fruit, alongside a second empty travel bottle.

5. 사용 설명서

5.1 재료 준비

Cut fruits and vegetables into small pieces (approximately 1-2 cm) to ensure optimal blending. For best results, add liquids first, then soft ingredients, followed by harder ingredients and ice. Do not exceed the MAX fill line on the bottle.

Image: Various fresh fruits and berries, such as papaya, kiwi, banana, blackberries, and raspberries, prepared for blending into a smoothie.

5.2 블렌딩 프로세스

1. Fill the blending bottle with your prepared ingredients.
2. Screw the blade assembly firmly onto the open end of the blending bottle. Ensure it is tight to prevent leaks.
3. Invert the bottle and place it onto the motor base, aligning the tabs on the bottle with the slots on the base. Twist clockwise to lock it into place.
4. 전원 코드를 적합한 콘센트에 꽂으세요.
5. Press and hold the power button on the motor base to start blending. Release the button to stop. Use short pulses for better control and to prevent overheating. Do not operate continuously for more than 60 seconds.
6. Once blending is complete, release the button, unplug the blender, and twist the bottle counter-clockwise to unlock and remove it from the motor base.
7. 병에서 칼날 조립체를 조심스럽게 돌려서 분리하세요.
8. Attach a travel lid to the bottle if you plan to take your drink on the go, or pour your smoothie into a glass.

Image: A user's hand pressing the power button on the H.Koenig Mini Blender SMOO10 to activate blending, with the bottle filled with green ingredients.

Image: A freshly blended green smoothie served in a glass, accompanied by a green apple and a sliced kiwi, demonstrating a typical result.

6. 청소 및 유지 관리

6.1 일일 청소

After each use, unplug the blender. Remove the bottle and blade assembly. Rinse the blade assembly, bottle, and travel lid under running water. For a quick clean, fill the bottle with warm water and a drop of dish soap, attach the blade assembly, and pulse on the motor base for a few seconds. Rinse thoroughly.

6.2 심층 청소

The blending bottles and travel lids are dishwasher safe (top rack recommended). The blade assembly can be hand-washed with a brush to remove any residue. Always be careful when handling the sharp blades. The motor base should only be wiped clean with a damp 천으로 닦아주세요. 모터 본체를 물에 담그지 마세요.

6.3 보관

Store the blender in a clean, dry place. Ensure all parts are dry before storing. Do not wrap the power cord tightly around the motor base.

7. 문제 해결

8. 사양

9. 보증 및 지원

Your H.Koenig Mini Blender SMOO10 comes with an extended 2년 보증. This warranty is supported by an after-sales service workshop in France, providing confidence and peace of mind for prolonged and reliable use.

For technical assistance, warranty claims, or spare parts information, please refer to the contact details provided with your purchase documentation or visit the official H.Koenig web대지.
