FANGOR Fangor F802
FANGOR F802 5G WiFi Projector User Manual
Model: F802 | Brand: FANGOR
ಉತ್ಪನ್ನ ಮುಗಿದಿದೆview
The FANGOR F802 is a portable 5G WiFi projector designed for versatile entertainment and presentation needs. It supports up to 1080P Full HD resolution, offers a large display size, and features a 360° stereo speaker with Bluetooth 5.0 connectivity. Its compact design and multiple input options make it suitable for various environments, from home entertainment to outdoor movie nights and office presentations.
Figure 1: FANGOR F802 5G WiFi Projector with smartphone screen mirroring illustration.
ಪ್ರಮುಖ ಲಕ್ಷಣಗಳು:
- Supports 1080P Full HD resolution with native 720P.
- Capable of projecting a display up to 300 inches.
- Integrated 360° omnidirectional stereo speaker.
- Bluetooth 5.0 for wireless audio device connection.
- 5G WiFi and USB cable support for smartphone screen synchronization (iOS/Android).
- Multiple connectivity options: HDMI, AV, USB.
- Portable and compact design with a convenient handle.
ಬಾಕ್ಸ್ನಲ್ಲಿ ಏನಿದೆ
Upon opening the package, verify that all components are present and in good condition. The standard package includes:
- FANGOR F802 Projector
- ರಿಮೋಟ್ ಕಂಟ್ರೋಲ್
- ಪವರ್ ಅಡಾಪ್ಟರ್
- HDMI ಕೇಬಲ್
- ಎವಿ ಕೇಬಲ್
- ಬಳಕೆದಾರ ಕೈಪಿಡಿ
ಸೆಟಪ್ ಗೈಡ್
1. ಉದ್ಯೋಗ
Position the projector on a stable, flat surface. Ensure there is adequate ventilation around the unit. For optimal viewing, place the projector perpendicular to the projection surface (wall or screen). The ideal projection distance ranges from 1 to 5 meters to achieve a display size up to 300 inches.
ಚಿತ್ರ 2: ಉದಾample of projector placement for a large display.
2. ವಿದ್ಯುತ್ ಸಂಪರ್ಕ
Connect the provided power adapter to the projector's power input port and then plug it into a wall outlet. The projector requires continuous power to operate.
3. ಆರಂಭಿಕ ಪವರ್ ಆನ್
Press the power button on the projector or the remote control to turn on the device. The power indicator light will illuminate.
4. ಫೋಕಸ್ ಹೊಂದಾಣಿಕೆ
Rotate the focus ring located on the projector lens until the projected image appears clear and sharp on the screen.
ಆಪರೇಟಿಂಗ್ ಸೂಚನೆಗಳು
1. ಇನ್ಪುಟ್ ಮೂಲ ಆಯ್ಕೆ
Use the 'Source' button on the remote control or the projector's control panel to select the desired input source (e.g., HDMI, AV, USB, WiFi).
2. ಸಾಧನಗಳನ್ನು ಸಂಪರ್ಕಿಸಲಾಗುತ್ತಿದೆ
- HDMI ಸಂಪರ್ಕ: Connect your TV Stick, PS4, laptop, or other HDMI-enabled devices to the projector's HDMI port using an HDMI cable.
- AV ಸಂಪರ್ಕ: Use the provided AV cable to connect DVD players or other devices with AV output to the projector's AV port.
- USB ಸಂಪರ್ಕ: Insert a USB drive into the USB port to play media files directly. For smartphone screen synchronization, connect your iOS or Android phone via a USB cable (no HDMI adapter needed).
- Wireless (WiFi) Connection:
- Select the 'WiFi' input source.
- Follow the on-screen instructions to connect the projector to your home WiFi network.
- For iOS devices, use AirPlay/Screen Mirroring. For Android devices, use the screen mirroring function. Ensure both the projector and your smartphone are connected to the same WiFi network.
Figure 3: Wireless and wired smartphone connection options.
3. ಬ್ಲೂಟೂತ್ ಆಡಿಯೊ ಸಂಪರ್ಕ
The projector features Bluetooth 5.0 for connecting external audio devices (speakers, headphones). This function only supports audio output.
- ನಿಮ್ಮ ಬ್ಲೂಟೂತ್ ಆಡಿಯೊ ಸಾಧನವು ಜೋಡಿಸುವ ಮೋಡ್ನಲ್ಲಿದೆ ಎಂದು ಖಚಿತಪಡಿಸಿಕೊಳ್ಳಿ.
- ಪ್ರೊಜೆಕ್ಟರ್ನಲ್ಲಿ, ಬ್ಲೂಟೂತ್ ಸೆಟ್ಟಿಂಗ್ಗಳ ಮೆನುಗೆ ನ್ಯಾವಿಗೇಟ್ ಮಾಡಿ.
- Select your device from the list to pair.
Figure 4: The FANGOR F802 projector features a 360° HIFI speaker.
ನಿರ್ವಹಣೆ
1. ಲೆನ್ಸ್ ಕ್ಲೀನಿಂಗ್
Use a soft, lint-free cloth specifically designed for optical lenses to gently wipe the projector lens. Avoid using abrasive cleaners or cloths that could scratch the lens surface.
2 ವಾತಾಯನ
Ensure the projector's ventilation vents are clear of dust and obstructions. Regular cleaning with a soft brush or compressed air can help maintain optimal airflow and prevent overheating.
3. ಸಂಗ್ರಹಣೆ
When not in use, store the projector in a cool, dry place away from direct sunlight and extreme temperatures. Use the original packaging or a protective case to prevent dust accumulation and physical damage.
ದೋಷನಿವಾರಣೆ
| ಸಮಸ್ಯೆ | ಸಂಭವನೀಯ ಕಾರಣ | ಪರಿಹಾರ |
|---|---|---|
| No image projected / Power off | Power cable disconnected; Projector not powered on. | Check power connections; Press the power button. |
| ಮಸುಕಾದ ಚಿತ್ರ | Focus not adjusted; Keystone correction needed. | Adjust the focus ring; Access menu for keystone correction. |
| ಶಬ್ದವಿಲ್ಲ | Volume too low; Incorrect audio output selected; Bluetooth device not connected. | Increase volume; Check audio settings; Re-pair Bluetooth device. |
| Cannot connect via WiFi/Screen Mirroring | Projector and device on different networks; Network issues; App restrictions (e.g., Netflix). | Ensure both devices are on the same 5G WiFi network; Restart router/projector; Use wired USB connection for restricted apps. |
| ರಿಮೋಟ್ ಕಂಟ್ರೋಲ್ ಕಾರ್ಯನಿರ್ವಹಿಸುತ್ತಿಲ್ಲ | Batteries low/dead; Obstruction between remote and projector. | Replace batteries; Ensure clear line of sight to the projector's IR receiver. |
For further assistance, please refer to the "Warranty and Support" section.
ವಿಶೇಷಣಗಳು
- ಮಾದರಿ: F802
- ಆಯಾಮಗಳು: 4.33 x 4.33 x 6.22 ಇಂಚುಗಳು
- ತೂಕ: 5.14 ಪೌಂಡ್
- ಸ್ಥಳೀಯ ರೆಸಲ್ಯೂಶನ್: 720P
- ಬೆಂಬಲಿತ ರೆಸಲ್ಯೂಶನ್: 1080P ಪೂರ್ಣ HD ವರೆಗೆ
- ಹೊಳಪು: 10000L (Lumens)
- ಪ್ರದರ್ಶನ ಗಾತ್ರ: 300 ಇಂಚುಗಳವರೆಗೆ
- ಸಂಪರ್ಕ: 5G WiFi, Bluetooth 5.0, HDMI, AV, USB
- ಸ್ಪೀಕರ್: 360° Stereo Speaker
ಖಾತರಿ ಮತ್ತು ಬೆಂಬಲ
FANGOR products come with a 1-Month refund and exchange policy ಮತ್ತು ಎ 1 ವರ್ಷಗಳ ಖಾತರಿ from the date of purchase. For any product-related issues, technical support, or warranty claims, please contact the FANGOR Support team.
You can visit the official FANGOR store for more information and contact details: FANGOR Official Store
ಖಾತರಿ ದೃಢೀಕರಣಕ್ಕಾಗಿ ದಯವಿಟ್ಟು ನಿಮ್ಮ ಖರೀದಿ ರಸೀದಿಯನ್ನು ಇಟ್ಟುಕೊಳ್ಳಿ.
