Beurer IH 17 ネブライザー ユーザー マニュアル

製品終了view

The Beurer IH 17 Nebulizer is designed for the treatment of the upper and lower airways, including conditions such as colds, asthma, and various respiratory diseases. It features a high proportion of respirable particles, ensuring effective delivery of medication.

This device is effective in relieving symptoms associated with Asthma, COPD, Bronchitis, and Pneumonia, and is designed for short inhalation times.

図1: The Beurer IH 17 Nebulizer main unit, showing the compact compressor, air tube, and nebulizer cup with mouthpiece attached.

含まれるコンポーネント

The Beurer IH 17 Nebulizer package includes the following essential components:

• Nebulizer compressor unit
• エアチューブ
• Atomizer/Nebulizer cup
• 大人用マスク
• Child/Baby mask
• マウスピース
• ノーズピース
• Replacement filters (typically 10)

図2: 包括的な view of the accessories provided with the nebulizer, including adult and baby masks with straps, the atomizer, air hose, and a set of filters.

セットアップ手順

1. コンポーネントを解凍します: すべてのコンポーネントをパッケージから慎重に取り出し、損傷がないか検査します。
2. ユニットを配置します。 Position the nebulizer compressor unit on a stable, flat surface, ensuring adequate ventilation around the device.
3. エアチューブを接続する: Attach one end of the air tube securely to the air outlet on the compressor unit.
4. Prepare Atomizer: Open the atomizer/nebulizer cup and pour the prescribed medication into the medication chamber. Close the atomizer securely.
5. Connect Atomizer: Attach the other end of the air tube to the inlet port on the atomizer.
6. アクセサリを取り付ける: Connect the desired accessory (mouthpiece, adult mask, or child mask) to the top of the atomizer.
7. 接続電源： 電源コードを適切な電源コンセントに差し込みます。

Operating the Nebulizer

1. 電源オン: Press the power button on the nebulizer unit to turn it on. The compressor will begin to generate airflow, and the medication will start to nebulize into a fine mist.
2. Inhale Medication:
   • If using the mouthpiece: Place the mouthpiece between your teeth and seal your lips around it. Breathe in slowly and deeply through your mouth until all medication is consumed.
   • If using a mask: Place the mask over your nose and mouth, ensuring a snug fit. Breathe normally through the mask.
3. 間隔： Continue the inhalation until the medication chamber is empty, or as directed by your healthcare professional. The Beurer IH 17 is designed for short inhalation times.
4. 電源を切る： Once the treatment is complete, press the power button to turn off the nebulizer. Disconnect the power cord from the outlet.

図3: A user demonstrating the use of the nebulizer with a mask, emphasizing the convenience of short inhalation times.

図4: A user holding the nebulizer atomizer, illustrating the product's effectiveness in relieving symptoms of Asthma, COPD, Bronchitis, and Pneumonia.

メンテナンスと清掃

Regular cleaning and maintenance are crucial for the optimal performance and longevity of your nebulizer. Always disconnect the device from the power supply before cleaning.

使用後：

• Atomizer and Accessories: Disassemble the atomizer, mouthpiece, and masks. Wash these components thoroughly with warm water and a mild detergent. Rinse them well under running water.
• 消毒： For disinfection, boil the washed components in water for 5 minutes, or use a cold sterilization solution as recommended by your healthcare provider. Allow all parts to air dry completely on a clean cloth or paper towel.
• エアチューブ： The air tube does not require cleaning unless visibly soiled. If cleaning is necessary, wipe the exterior with a damp cloth. Do not immerse the air tube in water.

コンプレッサーユニット:

• コンプレッサーユニットの外側を清潔な布で拭きます。amp 布で拭いてください。研磨剤入りの洗剤を使用したり、本体を水に浸したりしないでください。

フィルターの交換:

• Check the air filter regularly. Replace it when it appears discolored or every 100-120 operating hours, or as indicated in the full product manual.

ストレージ：

• Store the nebulizer and its accessories in a clean, dry place, away from direct sunlight and extreme temperatures.

トラブルシューティング

If you encounter issues with your Beurer IH 17 Nebulizer, refer to the following common troubleshooting steps:

If the problem persists after attempting these solutions, please contact Beurer customer support for further assistance.

技術仕様

保証とサポート

For warranty information and customer support, please contact Beurer directly using the details below. It is recommended to retain your purchase receipt for warranty claims.

• メーカーの連絡先： Beurer GMBH, Soflinger, Ulm, Germany
• メールアドレス: info@beurer.com
• 電話： +49 (731) 3989-0
• 輸入業者（インド）: Beurer India Pvt. Ltd., 523-524, JMD Megapolis, Sohna Road, Sector- 48, Gurugram- 122018 India

Please refer to the official Beurer website or the full product manual for detailed warranty terms and conditions specific to your region.
