Manuale utente dell'inverter solare ibrido POWLAND da 12000 W

1. Introduzione

This manual provides essential information for the installation, operation, and maintenance of your POWLAND 12000W Solar Hybrid Inverter. This inverter is designed to provide a reliable and powerful energy solution for both daily use and backup situations, ensuring stable power for various applications.

The inverter features a 12,000W pure sine wave output, capable of powering demanding appliances. It incorporates an advanced MPPT charge controller for efficient solar energy harvesting and supports various battery types, including LiFePO4 and lead-acid batteries. The system is also designed for scalability, allowing up to 6 units to be stacked for a total output of 72,000W.

Image 1.1: The POWLAND 12000W Solar Hybrid Inverter connected to various household appliances.

Immagine 1.2: Es.ample installation of the POWLAND Solar Hybrid Inverter for home energy storage.

2. Informazioni sulla sicurezza

Leggere attentamente tutte le istruzioni e le avvertenze prima dell'installazione e dell'uso. Il mancato rispetto di queste istruzioni può causare scosse elettriche, incendi o lesioni gravi.

• Assicurarsi che tutti i cablaggi siano eseguiti da personale qualificato e siano conformi alle normative elettriche locali.
• Do not attempt to open or repair the inverter. Refer all servicing to authorized service personnel.
• Tenere l'inverter lontano da materiali infiammabili, umidità e luce solare diretta.
• Garantire un'adeguata ventilazione intorno all'inverter per evitare il surriscaldamento.
• Scollegare sempre tutte le fonti di alimentazione (solare, batteria, rete elettrica) prima di effettuare qualsiasi operazione di manutenzione o cablaggio.

The POWLAND inverter includes 8 safeguard technologies for comprehensive protection:

• Protezione da sovraccarico
• Protezione da cortocircuito
• Protezione polarità inversa
• Vol. automaticotage Cutoff (AC 90-280V)
• Overcurrent Defense
• Sovravoltage Protezione
• Sottovoltage Prevenzione
• Protezione da sovratemperatura

Immagine 2.1: Passoview of the inverter's 360° comprehensive protection features.

3. Prodotto finitoview

The POWLAND 12000W Solar Hybrid Inverter integrates a pure sine wave inverter, a 200A MPPT solar charge controller, and a battery charger into one compact unit. It features a user-friendly interface for monitoring and control.

3.1. LCD HD Display and LED Indicators

The inverter is equipped with a 6.25-inch tempered glass LCD touchscreen and tri-color LED indicators. This display allows for real-time monitoring of energy output, battery status, and solar input. Users can also set various parameters directly from the touchscreen interface.

Image 3.1: The LCD HD Display provides real-time data and parameter settings.

Image 3.2: The LCD display panel and LED indicators for operational status.

3.2. Sistema di raffreddamento

The inverter features an intelligent design with dual cooling fans to optimize heat dissipation and prevent dust accumulation. This ensures efficient and safe operation, maintaining a low noise level of 45dB.

Image 3.3: Intelligent design with dual cooling fans for optimal performance.

4. Configurazione e installazione

Proper installation is crucial for the safe and efficient operation of your solar hybrid inverter. Always consult a qualified electrician for installation.

4.1. Schema di collegamento

The inverter supports various connection configurations, including single-phase and parallel operation for increased power output. Ensure all connections are secure and correctly polarized.

Image 4.1: Standard connection diagram for the inverter, showing solar panels, battery, and home load connections.

Image 4.2: Alternative connection diagram including generator and mains power input.

4.2. Funzionamento parallelo

For higher power requirements, up to 6 units of the inverter can be connected in parallel, achieving a total output of up to 72,000W. This is facilitated by proprietary phase synchronization technology.

• 2 inverters in single phase: Up to 24,000W output.
• 3 inverters in single phase: Up to 36,000W output.
• 6 inverters in single phase: Up to 72,000W output.

Image 4.3: Parallel connection diagrams for multiple inverters.

5. Istruzioni per l'uso

Once installed, the inverter is ready for operation. The LCD display provides all necessary information for monitoring and adjusting settings.

5.1. Battery Compatibility and ECO Mode

The inverter offers universal compatibility with various battery types, including lead-acid and lithium batteries. It also supports a battery-free mode for direct PV-to-AC conversion.

• Tipi di batterie supportate: SLD, FLD, AGM, GEL, LI (Lithium).
• Battery-less Mode: Allows the inverter to operate directly from solar input without a battery.
• Smart ECO Mode: Extends battery life by optimizing charge and discharge cycles.
• Attivazione della batteria al litio: Features an activation function for dormant lithium batteries, triggered by utility or photovoltaic access.

Image 5.1: The inverter is compatible with multiple battery types.

Image 5.2: Visual representation of compatible battery types.

6. Manutenzione

Regular maintenance ensures the longevity and optimal performance of your POWLAND Solar Hybrid Inverter.

• Pulizia: Pulire periodicamente l'esterno dell'inverter, in particolare le aperture di ventilazione, per evitare l'accumulo di polvere. Utilizzare un panno asciutto e morbido. Non utilizzare detergenti liquidi.
• Ispezione: Regularly inspect all cables and connections for any signs of wear, damage, or loose connections. Ensure all terminals are tight.
• Ventilazione: Ensure the area around the inverter remains clear and unobstructed to allow for proper airflow and cooling by the dual intelligent fans.
• Controllo della batteria: If using batteries, follow the manufacturer's maintenance guidelines for your specific battery type.

7. Risoluzione Dei Problemi

In caso di problemi con l'inverter, fare riferimento ai seguenti passaggi generali per la risoluzione dei problemi. Per problemi più complessi, contattare l'assistenza tecnica.

• Nessuna potenza in uscita: Check all input power sources (solar, battery, utility) and ensure they are connected and supplying power. Verify circuit breakers are not tripped.
• Surriscaldamento dell'inverter: Ensure the inverter's ventilation openings are not blocked and that there is sufficient clearance around the unit for airflow. Reduce load if necessary.
• Codici di errore sul display LCD: Consult the full product manual for a list of specific error codes and their corresponding solutions.
• Batteria non in carica: Check solar panel connections and output. Verify battery settings on the inverter match your battery type.

8. Specifiche

Key technical specifications for the POWLAND 12000W Solar Hybrid Inverter:

Image 8.1: Key specifications of the POWLAND 12000W 48V Solar Inverter.

9. Supporto tecnico

For any questions regarding the product, installation, operation, or troubleshooting, please contact our technical support team. Our engineers are available to assist you with any issues.

• Informazioni sui contatti: Refer to the product packaging or the official POWLAND website for the most current technical support contact details.
• Resi: Questo prodotto può essere restituito facilmente entro 30 giorni.
