Introduzione
Thank you for choosing the PURPLE LEAF 8.2' X 11.5' Left-right Tilting Patio Umbrella. This manual provides essential information for the safe and efficient assembly, operation, and maintenance of your new outdoor umbrella. Please read all instructions carefully before use to ensure proper functionality and to prolong the life of your product.
Image: The PURPLE LEAF 8.2' X 11.5' Left-right Tilting Patio Umbrella providing shade over a modern outdoor seating area next to a pool.
Linee guida di sicurezza
- Always ensure the umbrella base is adequately weighted or bolted down to prevent tipping, especially in windy conditions. The cross base is included, but a weighted base (e.g., model ZY04BSSBL-150) is recommended and sold separately.
- Close the umbrella during strong winds, heavy rain, or when not in use to prevent damage and ensure safety.
- Do not attempt to operate the umbrella if any parts are damaged or missing. Contact customer support for assistance.
- Keep children and pets away from the umbrella during operation to avoid injury.
- Evitare di posizionare l'ombrello vicino a fiamme libere o fonti di calore.
Immagine: Un dettaglio view of the umbrella's internal frame and canopy, highlighting its geometric wind-resistant structure against a blue sky.
Contenuto della confezione
Prima del montaggio, assicurarsi che tutti i componenti siano presenti e integri. Fare riferimento allo schema seguente per l'identificazione.
- Telo per ombrellone (beige, tessuto in poliestere tinto in filo 240 g/m²)
- Aluminum Pole sections
- 8 Heavy-duty ribs
- Crank System Handle
- Foot Pedal for rotation
- Cross Base (weighted base sold separately)
- Ferramenta e utensili per l'assemblaggio
Image: An upward view into the umbrella canopy, clearly showing the eight heavy-duty ribs that provide structural support and balance.
Installazione e assemblaggio
Follow these steps to assemble your patio umbrella. It is recommended to have two people for easier assembly.
- Assemblare la base a croce: Connect the cross base sections as per the included hardware.
- Secure the Umbrella Pole: Attach the main umbrella pole to the assembled cross base using the provided bolts and tools. Ensure all connections are tight and secure.
- Fissare la tettoia: Carefully attach the umbrella canopy to the pole and rib structure.
- Fill the Weighted Base (if applicable): If using a separate weighted base (recommended for stability), fill it with water or sand according to its instructions. Place the assembled umbrella onto the weighted base.
Video: A demonstration of the umbrella's setup and operation, highlighting its ease of use and various features. This video is titled "Perfect Sun Protection, Anytime & Anywhere" by PURPLELEAFSHOP.
Istruzioni per l'uso
Aprire e chiudere l'ombrello
The umbrella features a smooth one-handed crank operation for easy opening and closing.
- A aprire, turn the crank handle clockwise until the canopy is fully extended.
- A vicino, turn the crank handle counter-clockwise until the canopy is fully retracted.
Image: A detailed shot of the cast aluminum handle and crank system, illustrating the mechanism for opening and closing the umbrella.
Tilting the Canopy (Left-right Tilt)
The easy-tilt system allows you to adjust the canopy angle up to 50° to the left or right, providing optimal shade as the sun moves.
- Locate the swivel handle on the main pole.
- Push or pull the handle to tilt the canopy to your desired left or right angle.
- Release the handle to lock the canopy in place.
Image: A close-up of the unique swivel handle mechanism, demonstrating how to effortlessly adjust the canopy's tilt in dual directions.
Image: A visual representation of the umbrella's 5-position tilt function, illustrating how the canopy can be adjusted to various angles for optimal shade.
Video: A demonstration of the umbrella's left-right tilt functionality, showing how the canopy can be adjusted to follow the sun's movement. This video is titled "Swaying Shadows: Right-left Tilt Canopy Experience" by PURPLELEAFSHOP.
Rotazione di grado 360
The foot pedal allows for complete 360-degree rotation of the umbrella, enabling you to easily reposition the shade without moving the entire base.
- Step on the foot pedal located at the base of the pole.
- Rotate the umbrella canopy to your desired position.
- Rilasciare il pedale per bloccare l'ombrello in posizione.
Image: A visual guide demonstrating the 360-degree rotation system, with a close-up of the foot pedal and an illustration of the umbrella's rotational movement.
Image: A composite image illustrating the umbrella's ability to provide all-day shade by adjusting its tilt and rotation to track the sun from morning to evening.
Manutenzione
- Pulizia: Clean the polyester canopy fabric with mild soap and water. Rinse thoroughly and allow to air dry completely before closing or storing.
- Magazzinaggio: When not in use for extended periods, especially during off-seasons or severe weather, close the umbrella and cover it with a protective cover (sold separately). Store in a dry, sheltered area.
- Cura del telaio: The aluminum frame is powder-coated for anti-oxidation. Periodically check all bolts and connections to ensure they remain tight.
Image: A comparison image showcasing the high-quality 240/gsm yarn-dyed polyester fabric of the PURPLE LEAF umbrella, emphasizing its 3+ year fade-resistant, water-repellent, and abrasion-resistant qualities compared to standard fabrics.
Risoluzione dei problemi
- Umbrella swaying excessively in wind: Ensure the base is properly weighted with sand or water. Always close the umbrella in strong winds.
- Difficulty opening/closing the canopy: Check for any obstructions in the crank mechanism or canopy ribs. Ensure the fabric is not caught.
- Difficulty tilting or rotating: Ensure the locking mechanisms (swivel handle, foot pedal) are fully disengaged before attempting to adjust.
Specifiche
| Marca | FOGLIA VIOLA |
| Nome del modello | PURPLE LEAF Economical Patio Umbrella Swivel Rectangle Outdoor Umbrellas |
| Misurare | 8.2' X 11.5' |
| Colore | Beige |
| Materiale del baldacchino | 240/gsm Yarn Dyed Polyester Fabric (UV resistant, water-repellent, fadeless) |
| Materiale del telaio | Alluminio verniciato a polvere |
| Caratteristiche speciali | Left-right Tilt (up to 50°), 360-degree Rotation (foot pedal), Crank Lift Opening Mechanism |
| Componenti inclusi | Cross Base (weighted base sold separately) |
Garanzia e assistenza clienti
For warranty information, product support, or to purchase replacement parts, please contact PURPLE LEAF customer service directly. Refer to the product packaging or the official PURPLE LEAF websito per i contatti.
