1. Prodotto finitoview
The Ariete Pizza Oven Model 919 is designed for rapid and efficient pizza cooking, replicating the high-temperature environment of a wood-fired oven. It features a high-quality 32 cm diameter refractory stone with a transparent non-stick treatment for enhanced durability and easier cleaning. With 5 cooking levels and a maximum temperature of 400°C, it can cook homemade pizzas in approximately 4 minutes and frozen pizzas in 2 minutes. This appliance is also suitable for heating other food items.
Image 1.1: The Ariete Pizza Oven Model 919 with a pizza ready for serving. The red exterior and open lid reveal the pizza on the refractory stone.
2. Istruzioni di sicurezza
Leggere attentamente tutte le istruzioni di sicurezza prima di utilizzare l'apparecchio. La mancata osservanza di queste istruzioni può causare scosse elettriche, incendi o lesioni gravi.
- Posizionare sempre l'apparecchio su una superficie stabile e resistente al calore.
- Do not touch hot surfaces. Use oven mitts or the provided wooden paddles.
- Assicurarsi che il cavo di alimentazione non entri in contatto con superfici calde.
- Non immergere l'apparecchio, il cavo o la spina in acqua o altri liquidi.
- Tenere fuori dalla portata dei bambini.
- Unplug from the outlet when not in use and before cleaning. Allow to cool completely before handling.
- Non utilizzare alcun apparecchio con un cavo o una spina danneggiati oppure dopo che l'apparecchio stesso non funziona correttamente o è stato danneggiato in qualsiasi modo.
- Utilizzare solo gli accessori consigliati dal produttore.
- Non utilizzare all'aperto.
3. Configurazione e primo utilizzo
- Disimballaggio: Carefully remove the pizza oven from its packaging. Retain packaging for future storage or transport.
- Ispezionare: Controllare che l'apparecchio non presenti segni di danneggiamento. In caso di danni, non utilizzarlo e contattare l'assistenza clienti.
- Posizionamento: Place the oven on a flat, stable, heat-resistant surface, away from walls and flammable materials. Ensure adequate ventilation around the unit.
- Pulizia iniziale: Pulisci l'esterno con un pannoamp cloth. The refractory stone should not be washed with water. For first use, it is recommended to heat the oven without food for 10-15 minutes on the highest setting to burn off any manufacturing residues. Ensure the area is well-ventilated during this process.
- Collegamento elettrico: Collegare il cavo di alimentazione a una presa elettrica dotata di messa a terra.
4. Istruzioni per l'uso
4.1 Controlli
The Ariete Pizza Oven features a temperature control knob and a timer knob.
- Manopola di controllo della temperatura: Adjusts the heating elements to one of 5 cooking levels, up to a maximum of 400°C.
- Manopola del timer: Sets the cooking duration. The oven will automatically turn off once the set time has elapsed.
Immagine 4.1: In alto view of the Ariete Pizza Oven, highlighting the control knobs for temperature and timer, and the "Pizza in 4 minutes" branding.
4.2 Cottura della pizza
- Preriscaldamento: Close the oven lid. Turn the temperature control knob to the desired setting (e.g., maximum for quick cooking). Set the timer for 5-10 minutes to allow the refractory stone to reach the optimal temperature. The indicator light will illuminate during heating.
- Preparare la pizza: While the oven preheats, prepare your pizza. For best results, avoid overloading the pizza with toppings, as this can increase cooking time and make the crust soggy.
- Inserisci Pizza: Once preheated, carefully open the lid. Using the provided wooden paddles, slide the pizza onto the hot refractory stone. Close the lid immediately.
- Tempo di cottura:
- Pizza fresca: Circa 4 minuti.
- Pizza Surgelata: Circa 2 minuti.
Note: Cooking times may vary based on pizza thickness, toppings, and desired crispness. Monitor the pizza closely.
- Rimuovere la pizza: When cooked, carefully open the lid and use the wooden paddles to slide the pizza off the stone. Close the lid to retain heat if cooking multiple pizzas.
- Servire: Transfer the pizza to a cutting board or plate, slice, and serve immediately.
Image 4.2: The internal refractory stone of the Ariete Pizza Oven, illustrating its high-temperature capability and the concept of 5 cooking levels.
Image 4.3: A user carefully removing a pizza from the oven using the provided wooden paddle.
4.4 Altri usi
The Ariete Pizza Oven can also be used for reheating various food items, such as savory cakes, toasts, or panzerotti, due to its adjustable thermostat and high heat capabilities.
Image 4.4: The Ariete Pizza Oven being used to warm croissants and other pastries, demonstrating its versatility beyond just pizza.
5. Manutenzione e pulizia
Proper maintenance ensures the longevity and performance of your Ariete Pizza Oven.
- Prima della pulizia: Scollegare sempre l'apparecchio dalla presa di corrente e lasciarlo raffreddare completamente prima di pulirlo.
- Esterno: Pulire l'alloggiamento esterno con un panno morbido eamp stoffa. Non utilizzare detergenti abrasivi o spugnette abrasive.
- Pietra refrattaria: The refractory stone has a transparent non-stick treatment, making it resistant to stains and residues.
- Do not wash the stone with water or immerse it.
- After the oven has cooled, gently scrape off any burnt-on food residues using a plastic scraper or a stiff brush.
- Wipe the stone with a dry cloth. Minor discoloration of the stone over time is normal and does not affect performance.
- Wooden Paddles: Wash the wooden paddles by hand with mild soap and water, then dry thoroughly. Do not wash in a dishwasher.
6. Risoluzione Dei Problemi
| Problema | Possibile causa | Soluzione |
|---|---|---|
| Il forno non si riscalda. | Non collegato; alimentazione spentatage; timer not set; temperature knob not turned on. | Check power connection; verify power supply; set the timer; turn the temperature knob to a desired setting. |
| La pizza non cuoce in modo uniforme. | Oven not fully preheated; uneven distribution of toppings; lid not closed properly. | Ensure adequate preheating time (5-10 minutes); distribute toppings evenly; ensure lid is fully closed during cooking. |
| Fumo o odore insolito durante il primo utilizzo. | Combustione dei residui di produzione. | This is normal for first use. Ensure good ventilation. If it persists after initial use, unplug and contact support. |
| Refractory stone is stained. | Normal wear and tear; food residues. | Minor discoloration is normal and does not affect performance. Scrape off residues gently with a plastic scraper when cool. Do not use water. |
7. Specifiche
- Marca: Ariete
- Numero modello: 919
- Energia: 1200 Watt
- Temperatura massima: 400°C
- Livelli di cottura: 5
- Refractory Stone Diameter: 32 centimetri
- Dimensioni del prodotto (L x P x A): Dimensioni: 34 x 30 x 19 cm
- Peso dell'articolo: 3.94 chilogrammi
- Materiali: Refractory stone, wood (paddles)
- Caratteristica speciale: Ideal for cooking frozen pizzas
8. Garanzia e supporto
Warranty information for the Ariete Pizza Oven Model 919 is not provided within this manual. Please refer to the product packaging, the retailer's purchase terms, or the official Ariete websito per termini e condizioni di garanzia dettagliati.
For technical support, spare parts, or service inquiries, please contact the manufacturer or your local distributor. Information regarding spare parts availability is not provided in this document.
