Perkenalan
This manual provides essential instructions for the safe and efficient operation, maintenance, and troubleshooting of your Borosil 1000W Handheld Garment Steamer, Model GS01. Please read this manual thoroughly before first use and retain it for future reference.
Petunjuk Keselamatan Penting
- Selalu pastikan stopkontak sesuai dengan tegangan yang dibutuhkan.tage ditentukan pada alat.
- Jangan merendam pengukus di dalam air atau cairan lainnya.
- Jauhkan alat pengukus dari jangkauan anak-anak dan hewan peliharaan.
- Berhati-hatilah saat menangani uap panas. Jauhkan tangan dan wajah dari nosel uap.
- Unplug the appliance from the power outlet before filling or emptying the water tank, and when not in use.
- Do not operate the steamer with a damaged cord or plug, or if the appliance malfunctions or has been damaged in any manner.
- Gunakan hanya air suling atau air demineralisasi untuk mencegah penumpukan mineral dan memperpanjang umur peralatan.
- This appliance is equipped with overheat protection and a thermal fuse for safety.
- Ensure the power socket is rated for 16 Amps for optimal and safe operation. Using a lower-rated socket may not provide sufficient power and could be unsafe.
Produk Selesaiview
Familiarize yourself with the components of your Borosil Handheld Garment Steamer:
- Steamer Unit: The main body housing the heating element and water tank.
- Pelat Sol Berlapis Keramik: For even heat distribution and smooth gliding.
- Detachable Cloth Brush: Attaches to the steam head for removing lint and opening fabric weaves.
- 120ml Detachable Water Tank: Transparent tank for water storage.
- Water Cup: For easy filling of the water tank.
- Steam Release Trigger: Activates steam output.
- Indikator Daya Lamp: Illuminates when the steamer is heating up and ready for use.
- Kabel Listrik Panjang: Memberikan fleksibilitas selama penggunaan.
- Membawa Kantong: Untuk penyimpanan dan pengangkutan yang mudah.
Gambar 1: Key components of the Borosil Handheld Garment Steamer.
Pengaturan
- Isi Tangki Air:
- Press and hold the release button located at the bottom of the steamer to detach the water tank.
- Using the provided water cup, fill the detachable water tank with distilled or demineralized water up to the MAX line. Do not overfill.
- Reattach the water tank securely until it clicks into place.
Gambar 2: Steps for removing and refilling the water tank.
- Pasang Kuas (Opsional): For fabrics that require lint removal or deeper steam penetration, attach the detachable cloth brush to the steam head.
- Hubungkan Daya: Plug the steamer into a 16 Amp power outlet. The power indicator lamp akan menyala.
- Pemanasan awal: Allow approximately 35 seconds for the steamer to heat up. The indicator lamp will change or turn off when ready, depending on the model.
Petunjuk Pengoperasian
- Persiapan Pakaian: Gantung pakaian pada gantungan. Untuk hasil terbaik, tarik kain hingga kencang dengan satu tangan sambil menguapinya dengan tangan lainnya.
- Steaming Technique:
- Hold the steamer upright for vertical steaming or horizontally for flat surfaces.
- Press the steam release trigger to emit steam. Move the steam head slowly over the fabric, allowing the steam to penetrate and relax the fibers.
- The steamer supports dual steam modes (High & Eco) for different fabric types. Select the appropriate mode as needed.
Gambar 3: Steaming a garment vertically.
- Delicate Fabrics: For delicate fabrics like silk or heavily embroidered items, hold the steamer slightly further away from the fabric or use the Eco steam mode.
Gambar 4: Steaming delicate fabrics with care.
- Penyelesaian: Once steaming is complete, release the steam trigger and allow the garment to cool and dry before wearing or storing.
Perawatan dan Pembersihan
- Tangki Air Kosong: Always empty the water tank after each use to prevent water stagPembangunan negara dan mineral.
- Membersihkan Bagian Luar: Usap bagian luar alat pengukus dengan kain lembut dan kering.amp kain. Jangan gunakan pembersih atau pelarut yang bersifat abrasif.
- Kerak: Periodically, if you notice reduced steam output or white residue, descale the steamer. Consult the Borosil customer support for recommended descaling procedures or use a steam burst feature with distilled water.
- Penyimpanan: Store the steamer in its carry pouch in a dry place when not in use.
Penyelesaian Masalah
| Masalah | Kemungkinan Penyebab | Larutan |
|---|---|---|
| Tidak ada uap atau keluaran uap rendah. | Water tank empty or not properly seated. Mineral buildup. Steamer not heated sufficiently. | Refill water tank and ensure it's securely attached. Allow adequate pre-heating time. Perform descaling if mineral buildup is suspected. |
| Kebocoran air. | Water tank overfilled or not properly seated. Steamer not fully heated. | Do not overfill the water tank. Ensure the tank is securely attached. Allow the steamer to fully heat up before use. |
| Mesin pengukus tidak menyala. | Not plugged in. Power outlet issue. Appliance malfunction. | Check power connection. Try a different power outlet. Ensure the outlet is 16 Amp rated. If problem persists, contact customer support. |
| Kerutan tidak hilang secara efektif. | Incorrect steaming technique. Fabric type. | Ensure fabric is taut. Move steamer slowly. Use the High steam mode for tougher wrinkles. For very stubborn wrinkles, traditional ironing may be required. |
Spesifikasi
| Fitur | Detil |
|---|---|
| Merek | Borosil |
| Nomor Model | GS01 (BHGS) |
| Apatage | 1000 Watt |
| Jil.tage | 230 Volt (AC) |
| Kapasitas Tangki Air | 120 Mililiter |
| Dimensi Produk | 8P x 25L x 13.5T Sentimeter |
| Berat Barang | 0.67 Kilogram (670 g) |
| Jenis Pelat Sol | Dilapisi Keramik |
| Mode Uap | Dual (High & Eco) |
| Waktu Pemanasan | Kira-kira 35 detik |
| Fitur Keamanan | Overheat Protection, Thermal Fuse |
Gambar 5: Dimensi produk.
Garansi dan Dukungan
Your Borosil 1000W Handheld Garment Steamer (Model GS01) comes with a Garansi 2 tahun terhadap cacat produksi sejak tanggal pembelian.
For warranty claims, technical assistance, or any product-related inquiries, please contact Borosil customer support. Keep your purchase receipt as proof of purchase.
- Pabrikan: Borosil Limited
- Alamat: 1101, Parinee Crescenzo, G Block, BKC, Bandra Kurla Complex, Bandra East, Mumbai, Maharashtra 400051
- Weblokasi: www.borosil.com
