Uvod
This instruction manual provides essential information for the safe and efficient operation of your Greenworks 24V Cordless Brushless 400 in-lbs Drill/Driver, Model DD345. Please read this manual thoroughly before using the tool and retain it for future reference. Understanding the features and proper usage will ensure optimal performance and extend the life of your drill/driver.
The Greenworks 24V Brushless Drill/Driver is engineered for precision drilling and screwdriving across various materials such as wood and metal. It incorporates a 1/2-inch keyless chuck, a 2-speed transmission (0-450/2000 RPM), and delivers up to 400 in-lbs (45Nm) of torque. The 18+1 position clutch allows for precise control over fastening applications. Powered by a 24V brushless motor, this tool offers enhanced efficiency and extended runtime compared to brushed motor alternatives. Its lightweight design (approximately 2.28 lbs) combined with an ergonomic non-slip grip ensures comfortable handling, particularly in confined spaces. This tool is suitable for carpentry, automotive tasks, and general home improvement projects.
Važne sigurnosne informacije
Uvijek slijedite osnovne sigurnosne mjere kako biste smanjili rizik od požara, strujnog udara i tjelesnih ozljeda prilikom rada s električnim alatima.
- Pročitajte sve upute: Prije upotrebe upoznajte se s radom alata i sigurnosnim uputama.
- Nosite zaštitu za oči: Always wear safety goggles or safety glasses with side shields when operating the drill/driver.
- Održavajte radni prostor čistim: Neuredna područja i klupe izazivaju ozljede.
- Izbjegavajte opasna okruženja: Nemojte koristiti električne alate u damp ili mokrim mjestima ili ih izložiti kiši. Neka radni prostor bude dobro osvijetljen.
- Osigurajte radni komad: Koristite clampili škripac za držanje obratka. To je sigurnije od korištenja ruke i oslobađa obje ruke za rukovanje alatom.
- Koristite ispravan bit: Ensure the drill bit or screwdriver bit is appropriate for the task and securely installed in the chuck.
- Održavajte pravilan oslonac i ravnotežu: Nemojte pretjerivati. Održavajte pravilan oslonac i ravnotežu cijelo vrijeme.
- Odspojite napajanje: Prije bilo kakvih podešavanja, promjene pribora ili skladištenja alata izvadite bateriju iz njega.
- Alati za neaktivnost u trgovini: Kada se alati ne koriste, treba ih čuvati na suhom, visokom ili zaključanom mjestu, izvan dohvata djece.
Značajke proizvoda
The Greenworks 24V Cordless Brushless Drill/Driver is equipped with several features designed for performance and user convenience:
- 1/2-inch Keyless Chuck: Allows for quick and easy bit changes without a chuck key.
- 2-brzinski mjenjač: Provides versatility for various applications, with low speed (0-450 RPM) for high torque tasks and high speed (0-2000 RPM) for faster drilling.
- 400 in-lbs (45Nm) Torque: Isporučuje ample power for demanding drilling and driving tasks.
- Spojka s 18+1 položajem: Offers 18 torque settings for screwdriving to prevent over-driving screws and stripping, plus a drill mode for maximum power.
- Motor bez četkica: Provides increased efficiency, longer runtime, more power, and extended tool life compared to traditional brushed motors.
- Lagan i kompaktan dizajn: Weighing approximately 2.28 lbs and featuring a compact length of 5.8 inches, it reduces user fatigue and allows access to tight spaces.
- Ergonomski neklizajući rukohvat: Enhances comfort and control during prolonged use.
- Ugrađeno LED radno svjetlo: Osvjetljava radno područje za bolju vidljivost u uvjetima slabog osvjetljenja.
- Kopča za remen: For convenient carrying and quick access to the tool.
- 24V POWERALL™ Battery System Compatibility: Shares batteries with over 150 other Greenworks 24V tools.
Image: Greenworks 24V Drill Driver highlighting its key features including the 1/2-inch keyless chuck, 2-speed transmission, 18-position clutch, variable speed trigger, cushioned overmold grip, LED worklight, and belt clip.
Postavljanje
Ugradnja i uklanjanje baterije
Your Greenworks 24V Drill/Driver operates with a 24V lithium-ion battery pack. Ensure the battery is fully charged before initial use.
- Instalirati: Poravnajte rebra na baterijskom paketu s utorima u priključku za bateriju alata. Umetnite baterijski paket u alat dok ne klikne na svoje mjesto.
- Za uklanjanje: Press the battery release button located on the battery pack. Pull the battery pack out of the tool.
Punjenje baterije
The 2.0Ah battery can be charged using the provided 30W GaN fast charger or via its USB-C port. The battery also functions as a 10,000mAh power bank for charging other devices.
- Spojite punjač na strujnu utičnicu.
- Connect the charging cable to the battery's charging port.
- Indikatorska svjetla baterije prikazivat će status punjenja.
Ugradnja i uklanjanje svrdla
The 1/2-inch keyless chuck allows for quick and easy bit changes.
- Instalirati: Rotate the chuck counter-clockwise until the jaws are open wide enough to insert the bit. Insert the drill bit or screwdriver bit into the chuck as far as it will go. Rotate the chuck clockwise to tighten the jaws firmly around the bit. Ensure the bit is centered and secure.
- Za uklanjanje: Okrenite steznu glavu suprotno od smjera kazaljke na satu kako biste olabavili čeljusti i uklonili svrdlo.
Image: The Greenworks 24V Cordless Brushless Drill/Driver with its battery pack attached, ready for use.
Upute za rad
Odabir brzine
The drill/driver features a 2-speed transmission. Use the speed selector switch located on top of the tool to choose between low and high speed.
- Brzina 1 (niska brzina, 0-450 okretaja u minuti): Ideal for high-torque applications such as driving screws or drilling large diameter holes.
- Brzina 2 (velika brzina, 0-2000 okretaja u minuti): Suitable for fast drilling with smaller diameter bits.
Image: A Greenworks 24V Drill Driver in action, demonstrating its 2000 RPM drill speed for efficient material penetration.
Torque Adjustment (Clutch Settings)
The 18+1 position clutch allows you to adjust the torque output to match the material and fastener size, preventing over-driving or stripping.
- Rotate the clutch collar to select a setting from 1 to 18. Lower numbers indicate lower torque, suitable for smaller screws and softer materials. Higher numbers provide more torque for larger screws and harder materials.
- The drill symbol setting provides maximum torque for drilling applications.
Image: A Greenworks 24V Drill Driver being used to drive a screw, illustrating its capability of delivering up to 400 in-lbs of torque.
Bušenje i uvrtanje vijaka
- Držite alat čvrsto objema rukama.
- Postavite svrdlo na radni komad.
- Press the variable speed trigger to start the tool. The LED work light will activate automatically.
- Primjenjujte stalan, ravnomjeran pritisak. Nemojte forsirati alat.
- Otpustite okidač da zaustavite alat.
LED radno svjetlo
The integrated LED work light automatically illuminates when the trigger is pressed, providing visibility in dark or confined work areas.
Image: A user operating the Greenworks 24V Drill Driver in an overhead, compact space, demonstrating its lightweight and ergonomic design for ease of use.
Održavanje
Redovito održavanje osigurava dugotrajnost i optimalne performanse vaše bušilice/odvijača.
- Čišćenje: Održavajte otvore za zrak na alatu čistima i bez ostataka. Koristite meku,amp krpom za čišćenje vanjštine. Nemojte koristiti jake kemikalije ili abrazivna sredstva za čišćenje.
- Njega baterije: Baterije čuvajte na hladnom i suhom mjestu, dalje od izravne sunčeve svjetlosti i ekstremnih temperatura. Ne skladištite baterije u ispražnjenom stanju dulje vrijeme.
- Održavanje bita: Ensure drill bits and screwdriver bits are sharp and in good condition. Dull or damaged bits can reduce efficiency and increase strain on the tool.
- Inspekcija: Periodically inspect the tool for any signs of damage, loose screws, or worn parts. Contact customer support for repairs if necessary.
Rješavanje problema
If you encounter issues with your Greenworks 24V Drill/Driver, refer to the following common problems and solutions:
| Problem | Mogući uzrok | Otopina |
|---|---|---|
| Alat se ne pokreće. | Baterija nije ispravno umetnuta ili je prazna. | Ensure battery is fully seated. Charge the battery. |
| Gubitak snage tijekom rada. | Napunjenost baterije je niska. Aktivirana je zaštita od preopterećenja. | Napunite bateriju. Smanjite pritisak na alat. |
| Bit proklizava u steznoj glavi. | Stezna glava nije dovoljno zategnuta. Prihvat bita je prljav ili oštećen. | Čvrsto zategnite steznu glavu. Očistite ili zamijenite svrdlo. |
| Prekomjerne vibracije ili buka. | Oštećeni svrdlo. Labave komponente. | Replace the bit. Check for loose parts and tighten if possible. If issue persists, contact support. |
If you experience any issues not covered here, please contact Greenworks customer support.
Tehnički podaci
| Značajka | Specifikacija |
|---|---|
| Marka | Greenworks |
| Broj modela | DD345 |
| Izvor napajanja | Baterija (24V) |
| Maksimalna brzina rotacije | 2000 okretaja u minuti |
| Maksimalna veličina stezne glave | 0.5 inča (1/2 inča) |
| Maksimalni okretni moment | 400 Inch Pounds (45 Nm) |
| Number of Clutch Settings | 18 + 1 (Način bušenja) |
| Težina artikla | 2.1 funti (samo alat) |
| Dimenzije predmeta (D x Š x V) | 8.7 cm D x 3.54 cm Š x 8.9 cm V |
| Vrsta materijala | Metal |
Greenworks 24V POWERALL™ Battery System
The Greenworks 24V Drill/Driver is part of the extensive Greenworks 24V POWERALL™ battery system, which allows you to use the same battery across over 150 compatible tools for both indoor and outdoor applications. This system provides versatility and cost savings by eliminating the need for multiple battery types.
Slika: Prekoview of the Greenworks 24V POWERALL™ ecosystem, showcasing a wide range of compatible tools that share the same battery system.
Official Product Video: Greenworks 24V POWERALL™ Battery System
Video: Ovaj video pruža pregledview of the Greenworks 24V Home Series, demonstrating the versatility and compatibility of the 24V POWERALL™ battery system across various tools.
Demonstracije proizvoda
Official Product Video: Greenworks New Brushless Cordless Compact Drill Driver DD345
Video: This video showcases the Greenworks New Brushless Cordless Compact Drill Driver DD345 in various applications, highlighting its features and performance in real-world scenarios.
Official Product Video: Greenworks 24V Brushless Drill Driver Compare Video DD345
Video: This comparison video demonstrates the performance of the Greenworks 24V Brushless Drill Driver DD345 against a competitor, focusing on its drilling capabilities.
Jamstvo i podrška
Greenworks stands behind its products with comprehensive warranty coverage.
- Jamstvo za alat: The Greenworks 24V Drill/Driver (Model DD345) is covered by a 3-year limited warranty.
- Jamstvo na bateriju: The 24V battery pack is covered by a 2-year limited warranty.
For warranty claims, technical assistance, or to purchase replacement parts, please contact Greenworks customer support through their official webweb-mjesto ili kontaktne podatke navedene na pakiranju proizvoda.
