Go Power GP-RVC-DIS-3 Display PowerTrak
PRODUCT DESCRIPTION
| No. | Description | No. | Description |
| 1 | Battery Image Indicator | 6 | Input/Output Current (+/-) |
| 2 | Battery Percentage Remaining | 7 | Ah Remaining |
| 3 | Battery Temperature | 8 | Settings |
| 4 | Battery Voltage | 9 | Time Remaining |
| 5 | Input/Output Power (+/-) | 10 | Connectivity Icon |
INSTALLATION AND WIRING – OVERVIEW
The GP-BMG shunt should be mounted as close to the battery as possible and the remote display is intended to be mounted on a wall.
RECOMMENDED TOOLS
- Wrench
- Drill
- 2″ hole saw
- 2 ring terminals of appropriate size for battery cable
- Crimp tool for ring terminals
WIRING DIAGRAMS
The following wiring diagrams will be referenced in the next section.
SETUP
- Tap the SETTINGS icon on the touchscreen display.
- Next, set the battery type and system voltage.
- Followed by setting the system size.
- Lastly, enable an external relay if you have one, and you are done.
COMPATIBLE
| NO. | DESCRIPTION | MODEL |
| 1 | Advanced Lithium Battery 300AH | GP-ADV LIFEPO4-300 |
| 2 | Advanced Lithium Battery 100AH | GP-ADVLIFEPO4-100 |
| 3 | IC2000 Watt Inverter (Dongle required) | GP-IC-2000-12 |
| 4 | IC3000 Watt Inverter (Dongle required) | GP-IC-3000-12 |
| 5 | 30A MPPT Solar Controller | GP-MPPT-30-RVC |
Cables sold separately.
Contact your Go Power! representative for more information.
SPECIFICATIONS
| DISPLAY | |
| Size | 3.2” |
| Resolution | 320×240 |
| Touchscreen | Resistive |
| Viewing Angle | Short axis 70° | Long axis 55° |
| Supply Voltage | 7.5 to 76 VDC |
| Max Supply Current @ 12 VDC Input | 150 mA |
| Max Supply Current @ 24 VDC Input | 80 mA |
| MECHANICAL | |
| Dimensions | 4.77” x 2.84” x 0.51” |
| ENVIRONMENTAL | |
| Operating Temperature Range | -20 to +50 °C |
| Storage Temperature Range | -30 to +70 °C |
| Humidity | 5-95 % RH, non-condensing |
| COMMUNICATIONS | |
| Connectivity Range | 50 meters (unobstructed) |
| WiFi Bandwidth | 2.4 Ghz |
BATTERY MANAGER COMPONENTS
- GP Shunt
- 1x GP-Shunt Power Cable
- 1x RV-C Extension Cable, 25ft
- 2x RV-C Adapter Cable
CUSTOMERS SUPPORT
 |
 |
Sold separately. Contact your Go Power! representative for more information.
Find tech tips, manuals and support at gopowersolar.com/BMG
