OLIGHT Goshawk 1600 Bike Light User Manual

Introduction

The OLIGHT Goshawk 1600 is a high-performance, rechargeable bike light designed for both mountain and urban riding. It features a powerful 1600-lumen output, a long-lasting battery, and a wireless remote control for convenient operation. This manual provides detailed instructions for the proper setup, operation, maintenance, and troubleshooting of your Goshawk 1600 bike light.

The Goshawk 1600 bike light mounted on a bicycle, showcasing its compact design and integration with a bike computer.

Caractéristiques principales :

• Sortie puissante : Delivers up to 1600 lumens with distinct high and low beam modes.
• Anti-Glare Low Beam: Features a sharp cut-off line to prevent glare for oncoming traffic.
• Extended High Beam: Provides broad and long-distance illumination for dark paths.
• Batterie longue durée : Rechargeable high-capacity battery offers up to 15 hours of continuous runtime.
• Chargement USB-C: Fast and reliable recharging via a USB-C port.
• IPX6 imperméable à l'eau: Protects against heavy rain and harsh conditions.
• Télécommande sans fil : Allows for easy mode adjustments and maximum output activation.
• Fonction mémoire : Retains previous settings upon reactivation.
• Under-Bar Mounting: Sleek design keeps handlebars clear and stable.
• Protection de verrouillage : Empêche l'activation accidentelle.
• Construction durable : Robust aluminum housing for efficient heat management.

Instructions d'installation

Contenu du colis :

Avant de commencer, assurez-vous que tous les composants sont présents :

• Goshawk 1600 Bike Light (x1)
• Support de guidon avant (x1)
• Remote Control (including strap) (x1)
• Adaptateur GoPro en métal (x1)
• Nylon Shims (28mm/32mm/35mm) (x3)
• Vis (x2)
• Clé Allen 2mm (x1)
• Clé Allen 3mm (x1)
• Câble de chargement USB-C (x1)
• Manuel d'utilisation (x1)

Un plusview of the Goshawk 1600 components, including the light unit, handlebar mount, remote control, and various adapters and tools.

Mounting the Bike Light:

1. Select Appropriate Shim: Choose the nylon shim that best fits your handlebar diameter (28mm, 32mm, or 35mm) to ensure a secure fit for the handlebar out-front mount.
2. Fixer le support au guidon : Position the handlebar out-front mount on your handlebar. Use the provided screws and hex key to tighten the mount securely. Ensure the mount is centered and stable.
3. Install GoPro Adapter (Optional): If using a GoPro-compatible device, attach the metal GoPro adapter to the top of the out-front mount.
4. Attach Bike Light: Slide the Goshawk 1600 bike light onto the quick-release mechanism of the out-front mount until it clicks into place. Ensure it is firmly secured. The light should be positioned underneath the handlebars.

The under-bar mounting system allows for a clean cockpit setup, securing the light below the handlebars with a quick-release mechanism.

Mounting the Remote Control:

Attach the wireless remote control to a convenient location on your handlebar using the provided strap. Ensure it is within easy reach for safe operation during your ride.

The wireless remote control provides seamless adjustments, allowing for one-touch activation of full brightness while keeping hands on the bars.

Mode d'emploi

Chargement de la batterie :

Before first use, fully charge the Goshawk 1600. The USB-C charging port is located on the rear of the light unit.

1. Ouvrez le cache de protection du port USB-C.
2. Connectez le câble USB-C fourni à la lampe et à une source d'alimentation USB (par exemple, un ordinateur, un adaptateur secteur).
3. The battery indicator will show charging status. A full charge is indicated when the light turns solid green.
4. Close the protective cover firmly after charging to maintain water resistance.

The USB-C charging port is conveniently located and protected by a cover, also functioning as a power source for other electronic devices.

Mise sous/hors tension et sélection du mode :

The Goshawk 1600 can be operated using the button on the light unit or the wireless remote control.

• Marche/Arrêt : Press and hold the main button on the light or the power button on the remote for approximately 1 second.
• Modes de cycle : Short press the main button on the light or the mode button on the remote to cycle through available brightness modes (Low Beam Low, Low Beam Mid, Low Beam High, High Beam Low, High Beam Mid, High Beam High, Day Flash, Night Flash).
• Fonction mémoire : La lampe mémorisera le dernier mode utilisé lorsqu'elle sera éteinte puis rallumée.
• Instant Max Output: Tap the designated button on the remote control for immediate access to maximum output.

The low beam provides a distinct cut-off line to prevent glare, while the high beam offers increased coverage and distance for dark environments.

Protection de verrouillage :

To prevent accidental activation and conserve battery during transport or storage, the Goshawk 1600 features a lock function.

• Activer le verrouillage : While the light is off, press and hold the main button for 3 seconds. The indicator light will flash to confirm locking.
• Désactiver le verrouillage : Press and hold the main button for 3 seconds again. The light will turn on in the last used mode.

The lock protection feature prevents unintended activation, preserving battery life and ensuring readiness when needed.

Indicateur de batterie :

The battery indicator on both the light unit and the remote control provides real-time battery status:

• Vert: 75 % - 100 % de batterie restante
• Jaune: 25 % - 75 % de batterie restante
• Rouge: 10 % - 25 % de batterie restante
• Rouge clignotant : Less than 10% battery remaining (recharge immediately)

The easy-to-read battery indicator keeps you informed of the remaining power, ensuring you are prepared for your ride.

Entretien

Nettoyage:

Regular cleaning helps maintain the performance and longevity of your Goshawk 1600.

• Essuyez le corps de la lampe avec un chiffon doux et sec.amp chiffon pour enlever la saleté et les débris.
• Clean the lens gently with a microfiber cloth to ensure maximum light output. Avoid abrasive materials.
• Ensure the USB-C port cover is clean and properly sealed after charging to maintain its IPX6 waterproof rating.

The Goshawk 1600 features an IPX6 waterproof rating, protecting it from heavy rain and splashes, making it suitable for all weather conditions.

Stockage:

When storing the light for extended periods:

• Charge the battery to approximately 50-70% before storage.
• Conserver dans un endroit frais et sec, à l'abri de la lumière directe du soleil.
• Recharge the battery every 3-6 months to prevent deep discharge and prolong battery life.

Dépannage

If you encounter issues with your Goshawk 1600, refer to the following common problems and solutions:

Si le problème persiste après avoir essayé ces solutions, veuillez contacter le service client.

Caractéristiques

The following table outlines the key specifications of the OLIGHT Goshawk 1600 bike light:

A visual summary of the Goshawk 1600's key performance and physical specifications.

Output Table:

The following table details the various output modes and their corresponding runtimes:

Detailed output table illustrating lumen levels and runtimes for each mode, measured according to ANSI/NEMA FL 1-2009 standards. Runtimes may vary based on environmental conditions.

Informations sur la garantie

The OLIGHT Goshawk 1600 comes with a Garantie à vie for products purchased after January 1st, 2023. This warranty covers defects in materials and workmanship under normal use. For specific terms and conditions, or to make a warranty claim, please refer to the official OLIGHT website ou contacter le support client.

Assistance clientèle

For further assistance, technical support, or inquiries regarding your OLIGHT Goshawk 1600 bike light, please contact OLIGHT customer service through their official website. You can typically find contact information, FAQs, and additional resources on the manufacturer's support page.
