Sharmeal 5000A Car Jump Starter with Air Compressor (Model TM16F) User Manual

مقدمه

This manual provides essential instructions for the safe and effective operation, maintenance, and troubleshooting of your Sharmeal 5000A Car Jump Starter with Air Compressor, Model TM16F. Please read this manual thoroughly before using the product and retain it for future reference.

The Sharmeal 5000A Car Jump Starter is a versatile device designed to jump-start vehicles with up to 10.0L gas or 9.0L diesel engines. It also functions as a portable air compressor, a power bank for USB devices, and an 800-lumen LED flashlight with multiple modes.

دستورالعمل های ایمنی

برای جلوگیری از آسیب یا جراحت به دستگاه یا وسیله نقلیه، همیشه اقدامات احتیاطی ایمنی زیر را رعایت کنید:

• قبل از استفاده تمام دستورالعمل ها را بخوانید.
• در صورت آسیب دیدن جامپ استارتر، آن را روشن نکنید.
• Ensure proper polarity when connecting to a vehicle battery. Reverse polarity can cause sparks and damage.
• باتری یخ زده را پرش نکنید.
• دور از دسترس کودکان نگهداری شود.
• دستگاه را در معرض باران یا رطوبت قرار ندهید.
• از اتصال کوتاه کردن مدار جلوگیری کنیدamps.
• در مکانی با تهویه مناسب استفاده گردد.
• Do not disassemble the unit. Contact qualified service personnel for repairs.
• The device is equipped with 14 advanced safety features, including protection against short circuits, over-temperature, over-charge, over-discharge, and reverse polarity.

This image illustrates the various safety protections integrated into the Sharmeal jump starter, such as short-circuit, over-charge, over-load, spark-proof, over-voltage, high-temperature, low-temperature, and over-current protection. These features ensure safe operation and prevent damage to the device and vehicle.

محصول تمام شده استview

محتویات بسته

بسته شامل موارد زیر است:

• 1x Sharmeal Jump Starter with Air Compressor
• 1x Jump Starter Clamps
• 1x Air Pump Hose
• 3x Gas Nozzles (for various inflatables)
• 1 عدد کابل شارژ Type-C
• ۱ عدد دفترچه راهنمای کاربر (این سند)
• 1 عدد جعبه بسته بندی

This image displays all components included in the Sharmeal jump starter package, such as the main unit, battery clamps, air hose, different inflation nozzles, and a USB-C charging cable, alongside the user manual and packaging.

طرح بندی دستگاه

This diagram labels the key components of the Sharmeal jump starter: the inflatable port, USB output, Type-C input, LED light, operation buttons, LED display, and jump start output. Understanding these components is crucial for proper operation.

• Inflatable Port: Connect the air pump hose here for tire inflation.
• USB Output (5V/2A): For charging mobile phones, tablets, and other USB-powered devices.
• Type-C Input (5V/2A): For charging the jump starter unit itself.
• چراغ LED: Provides illumination with Flashlight, Strobe, and SOS modes.
• دکمه های عملیات: Control various functions, including power, light modes, and air compressor settings.
• نمایشگر ال ای دی: Shows battery level, inflation mode, and real-time tire pressure.
• Jump Start Output: جامپ استارتر cl را وصل کنیدampاینجاست

راه اندازی

شارژ شروع کننده پرش

Before first use, fully charge the jump starter. Connect the provided Type-C charging cable to the Type-C Input port (3) on the device and to a 5V/2A USB power adapter (not included). The LED display (6) will indicate the charging status and battery level. A full charge typically takes several hours.

It is recommended to recharge the unit every 3-6 months to maintain battery health, even if not in use.

دستورالعمل های عملیاتی

۱. روشن کردن سریع وسیله نقلیه

Ensure the jump starter is at least 50% charged before attempting to jump-start a vehicle.

1. Cl را وصل کنیدampبه جامپ استارتر: Insert the blue plug of the jump starter clamps into the Jump Start Output port (7) on the device. Ensure a firm connection.
2. اتصال به باتری خودرو:
   • را وصل کنید قرمز (+) کلرamp به ترمینال مثبت (+) باتری خودرو.
   • را وصل کنید مشکی (-) کلرamp به ترمینال منفی (-) باتری خودرو.

   هشدار: به cl قرمز و سیاه دست نزنیدamps together. Ensure correct polarity.

3. استارت خودرو: Once connected, the jump starter will automatically detect the battery. Start your vehicle's engine.
4. Clamps: After the engine starts, immediately remove the black (-) clamp اول، سپس قرمز (+) clamp از باتری خودرو. سپس، اتصال را جدا کنیدamps از جامپ استارتر.

This image demonstrates the correct connection of the Sharmeal jump starter clamps to a vehicle battery for jump-starting. The red clamp is on the positive terminal, and the black clamp is on the negative terminal.

This image shows the Sharmeal 5000A jump starter connected and ready to operate, highlighting its capacity for large gas and diesel engines.

۵.۲ استفاده از کمپرسور هوا

The integrated air compressor can inflate tires and other inflatables.

1. شیلنگ اتصال: Screw the air pump hose onto the Inflatable Port (1) of the jump starter.
2. وصل کردن نازل: Select the appropriate gas nozzle for your item (tire, ball, etc.) and attach it to the other end of the air pump hose.
3. تنظیم فشار: Turn on the jump starter. Use the operation buttons (5) to set the desired pressure (PSI, Bar, Kpa, Kg/cm²). The LED display (6) will show the current and target pressure.
4. شروع تورم: Press the inflation button to begin. The compressor will automatically stop once the preset pressure is reached.
5. قطع ارتباط: Remove the nozzle and hose.

This image illustrates the Sharmeal jump starter's function as a cordless tire inflator, with the air hose connected to a tire and various inflation nozzles displayed. It highlights the 160 PSI maximum pressure and 35L/min air flow.

۶.۳ استفاده به عنوان پاور بانک

The jump starter can charge USB devices.

1. اتصال دستگاه: Plug your USB charging cable into the USB Output port (2) on the jump starter.
2. اتصال به دستگاه: Connect the other end of the cable to your mobile phone, tablet, or other USB-powered device.
3. شارژ کردن: The jump starter will begin charging your device. The LED display (6) will show the remaining battery level of the jump starter.

This image shows the Sharmeal jump starter being used as a power bank, charging a smartphone. It highlights the input, output, start output, and inflatable ports.

۳. استفاده از چراغ LED

The 800-lumen LED light has three modes: Flashlight, Strobe, and SOS.

1. روشن/خاموش کردن: Press and hold the light button (part of operation buttons 5, or a dedicated light button near port 4) to turn the flashlight on or off.
2. تغییر حالت ها: With the light on, short press the light button to cycle through Flashlight, Strobe, and SOS modes.

This image displays the Sharmeal jump starter's 800-lumen LED light in operation, illustrating its three modes: Flashlight, Strobe, and SOS, useful for emergencies or working in low-light conditions.

تعمیر و نگهداری

• تمیز کردن: دستگاه را با یک پارچه خشک و نرم پاک کنید. از مواد شیمیایی قوی یا پاک کننده های ساینده استفاده نکنید.
• ذخیره سازی: استارتر پرشی را در جای خشک و خنک و دور از نور مستقیم خورشید و دمای شدید نگهداری کنید.
• شارژ مجدد: Recharge the unit every 3-6 months to maintain optimal battery performance, even when not in use.
• عمر باتری: The device uses high-performance lithium batteries designed for reliability in various temperatures.

این تصویر یک نمای داخلی ارائه می‌دهد view of the Sharmeal jump starter, highlighting its high-performance lithium battery cells. It emphasizes the battery's suitability for extreme temperatures, from cold winters to hot summers.

عیب یابی

مشخصات

گارانتی و پشتیبانی

This Sharmeal jump starter comes with a گارانتی 24 ماهه از تاریخ خرید. این ضمانت‌نامه شامل نقص‌های تولیدی و نقص‌های ناشی از کار در شرایط استفاده عادی می‌شود.

The warranty does not cover damage caused by misuse, accident, unauthorized modification, or neglect.

For technical support, warranty claims, or service inquiries, please contact Sharmeal customer service through the retailer where the product was purchased or visit the official Sharmeal webسایت برای اطلاعات تماس

سازنده: Foshan Xianming Intelligent Technology Co, Ltd.
