Aigostar A60 E27 12W Bluetooth Mesh Smart LED Bulb User Manual

مقدمه

Thank you for choosing the Aigostar A60 E27 12W Bluetooth Mesh Smart LED Bulb. This manual provides detailed instructions for the safe and efficient use of your smart bulb. Please read this manual thoroughly before installation and operation, and retain it for future reference.

اطلاعات ایمنی

• Ensure the power is turned off before installing or replacing the bulb.
• این لامپ فقط برای استفاده در محیط داخلی طراحی شده است.
• لامپ را جدا یا تغییر ندهید.
• از قرار گرفتن در معرض آب یا رطوبت زیاد خودداری کنید.
• در حجم مشخص شده عمل کنیدtage range (220V AC).
• دور از دسترس کودکان نگهداری شود.

محتویات بسته

بسته به طور معمول شامل:

• Aigostar A60 E27 12W Bluetooth Mesh Smart LED Bulbs (2 units)
• Bluetooth Remote Control (if included in your specific package)
• راهنمای کاربر

Image: Aigostar A60 E27 12W Bluetooth Mesh Smart LED Bulbs, showing two bulbs, a remote control, and the product packaging.

مشخصات

Image: A diagram illustrating the physical dimensions of the Aigostar A60 E27 12W Smart LED Bulb, with a height of 118mm and a width of 60mm.

راه اندازی

1. نصب فیزیکی

1. خاموش: Ensure the power switch to the light fixture is in the OFF position before installation.
2. لامپ را نصب کنید: Screw the Aigostar smart LED bulb into a standard E27 light socket. Do not overtighten.
3. روشن کردن: Turn on the power switch to the light fixture. The bulb should light up.

Image: A visual comparison showing the simpler setup process for Aigostar Bluetooth Mesh bulbs (direct Alexa connection) compared to traditional WiFi smart bulbs that require a third-party app download and registration.

2. Connecting to Alexa (Direct Bluetooth Mesh Connection)

This method does not require the AigoSmart app or a separate gateway if you have a compatible Alexa Echo device (2nd generation or newer).

1. لامپ را نصب کنید: Follow the physical installation steps above.
2. کشف دستگاه ها: Say, "Alexa, discover devices" to your Alexa Echo device.
3. تایید: Alexa will confirm when the bulb is found and connected. You can then control the bulb using voice commands or the Alexa app.

Image: A family interacting with an Alexa device to control an Aigostar smart bulb, demonstrating voice control functionality.

3. Connecting via AigoSmart App and Gateway (for Remote Control & Advanced Features)

For remote control outside your home network, advanced scheduling, and grouping features, connect your bulbs through the AigoSmart app and an Aigostar Smart Gateway (sold separately).

1. لامپ را نصب کنید: Follow the physical installation steps.
2. Download AigoSmart App: Download the AigoSmart app from your smartphone's app store.
3. Pair Gateway: Follow the instructions within the AigoSmart app to pair your Aigostar Smart Gateway.
4. Add Bulbs: Within the AigoSmart app, add your smart bulbs to the gateway.
5. Link to Alexa (Optional): If you wish to use Alexa voice control with the AigoSmart app, enable the "AigoSmart" skill in your Alexa app and link your AigoSmart account. Your bulbs will then synchronize with Alexa.

Image: The Aigostar Smart Gateway, a central control unit for smart home devices, compatible with Aigostar Bluetooth Mesh products for remote control and automation. This device is sold separately.

دستورالعمل های عملیاتی

1. Basic Control (Voice/App)

• روشن/خاموش کردن: "Alexa, turn on [bulb name]" or "Alexa, turn off [bulb name]". Use the AigoSmart app to toggle power.
• تنظیم روشنایی: "Alexa, set [bulb name] to 50%" or use the dimmer slider in the Alexa/AigoSmart app (1% to 100%).
• تغییر دمای رنگ: "Alexa, set [bulb name] to warm white" (2700K) or "Alexa, set [bulb name] to cool white" (6500K). Adjust using the color temperature slider in the app.
• تغییر رنگ: "Alexa, set [bulb name] to red" or select from 16 million colors in the Alexa/AigoSmart app.

Image: A visual representation of the controls for adjusting brightness (1% to 100%), color temperature (2700K-6500K), and selecting from 16 million RGB colors for the smart bulb.

2. Bluetooth Remote Control (If Included)

The included Bluetooth remote control allows for quick adjustments without an app or voice commands.

• روشن/خاموش: Press the ON or OFF buttons.
• روشنایی: Use the brightness up/down buttons.
• دمای رنگ: Select preset color temperatures (e.g., 2700K, 3200K, 4000K, 6500K).
• رنگ‌های RGB: Select preset RGB colors (R, G, B, C, M, Y).
• حالت های صحنه: Use S1-S4 buttons for preset dynamic scene modes.

3. عملکرد زمان بندی

Set schedules for your bulbs to turn on or off automatically using the AigoSmart app.

1. Open the AigoSmart app and select the desired bulb or group.
2. Navigate to the "Schedule" or "Timer" function.
3. Set your desired ON/OFF times and days of the week.

Image: Two panels illustrating the timing function of the smart bulb: one showing the light turning on at 7:00 AM as a person wakes up, and another showing it turning off at 10:00 PM as a person sleeps.

4. Grouping Bulbs (AigoSmart App)

Control multiple bulbs simultaneously by grouping them in the AigoSmart app.

1. Open the AigoSmart app.
2. Select the option to "Create Group" or "Manage Groups".
3. Add the desired Aigostar smart bulbs to the new group.
4. You can now control the entire group with a single command or setting.

Image: A diagram depicting a Bluetooth Mesh network where multiple smart bulbs in a living room are interconnected, allowing for seamless communication and control between up to 200 devices.

تعمیر و نگهداری

• تمیز کردن: قبل از تمیز کردن، مطمئن شوید که لامپ خاموش و خنک است. با یک پارچه نرم و خشک آن را پاک کنید. از پاک کننده های مایع استفاده نکنید.
• ذخیره سازی: اگر می‌خواهید لامپ را برای مدت طولانی نگهداری کنید، آن را در جای خشک و خنک و دور از نور مستقیم خورشید نگهداری کنید.
• به روز رسانی سیستم عامل: Periodically check the AigoSmart app for any available firmware updates for your bulbs to ensure optimal performance and security.

عیب یابی

For further assistance, please refer to the Aigostar support webسایت یا با خدمات مشتری تماس بگیرید.

گارانتی و پشتیبانی

Aigostar products come with a standard manufacturer's warranty. Please refer to the warranty card included with your purchase or visit the official Aigostar webبرای مشاهده شرایط و ضوابط دقیق گارانتی به سایت مراجعه کنید.

For technical support, product inquiries, or warranty claims, please contact Aigostar customer service through their official webسایت یا اطلاعات تماس ارائه شده در بسته بندی محصول شما.

Webسایت: www.aigostar.com
