Anern 10.2KW Hybrid Solar Inverter User Manual

1. Producto terminadoview

The Anern 10.2KW Hybrid Solar Inverter is an all-in-one solution designed for off-grid solar power systems. It integrates a 10.2KW pure sine wave inverter, a 160A MPPT solar charge controller, and a 160A AC battery charger. This unit supports dual PV input and dual AC output, making it suitable for various household and office loads. It is compatible with 48V Lead-Acid (Seal, AGM, Gel, Flooded) and Lithium batteries, providing a reliable power source for home backup and off-grid applications.

Figure 1: The Anern 10.2KW Hybrid Solar Inverter powering common household appliances.

2. Características principales

• Diseño todo en uno: Combines inverter, MPPT solar charge controller, and AC battery charger.
• Salida de alta potencia: 10.2KW pure sine wave output, suitable for sensitive electronics.
• Entrada fotovoltaica dual: Supports up to 10200W (90-450VDC range, max 500VOC) from two independent PV inputs.
• Salida CA dual: Provides uninterrupted power supply for various loads.
• Amplia compatibilidad de baterías: Works with 48V Lead-Acid (Seal, AGM, Gel, Flooded) and Lithium batteries.
• Modo de luz RGB: Visual indication of different working modes (Purple-PV, Red-Battery, Blue-Utility).
• Backlight LCD Screen: Easy parameter browsing and setting.
• Restauración con un clic: Quickly restore default settings to prevent configuration errors.
• Múltiples modos de carga: Solar First (CSO), Solar and Utility (SNU), Only Solar (OSO).
• Múltiples modos de salida: Solar First, Mains First, SBU Priority.
• Protección integral: Includes Overload, Over temperature, and Short circuit protection.
• Built-in Anti-dust Kit: Enhances product reliability in harsh environments.
• Refrigeración eficiente: Equipped with three cooling fans for effective heat dissipation.
• Función de arranque en frío: Supports cold start at 46VDC.

Figura 2: Sobreview of the inverter's main power and charging capabilities.

3. Configuración e instalación

Proper installation is crucial for the safe and efficient operation of your hybrid solar inverter. Please follow all local electrical codes and safety guidelines. It is recommended that installation be performed by a qualified professional.

3.1 Diagrama de cableado

The inverter supports dual photovoltaic (PV) inputs and dual AC outputs. Ensure all connections are secure and correctly polarized.

Figure 3: Comprehensive wiring diagram showing connections for PV, battery, AC input, and AC output.

3.2 Pautas de conexión

• Entrada fotovoltaica: Vol máx. de circuito abierto PVtage 500VDC. MPPT voltage range 90-450VDC. Suggested cable: 10 AWG/6mm². Connect solar modules in series for optimal performance.
• Conexión de la batería: Compatible with 48V lead-acid/lithium batteries. Recommended cable and terminal size: Wire size 2 AWG/Cable 25mm². Recommended Fuse: 150A.
• Entrada de CA (servicio público/generador): 230 VDC. Maximum AC input voltage: 300VAC. Max AC charging current: 160A. Suggested cable: 10AWG/6mm². Recommended switch: 63A.
• Salida de CA: Output power 10200W. Output voltage: 220V/230V. Suggested cable: 10AWG/6mm². Recommended breaker: 63A.

Nota: The inverter's output is 230V. For 110V/120V US home appliances, a separate converter (not included) is required to step down the voltage.

Figure 4: Rear panel connections for PV, AC, and battery inputs/outputs.

4. Modos de funcionamiento

El inversor ofrece modos de carga y salida flexibles para adaptarse a diversas necesidades de gestión de energía.

4.1 modos de carga

• CSO (Solar First): Solar energy charges the battery as a priority. The utility company only charges the battery when solar input is unavailable.
• SNU (Energía Solar y Servicios Públicos): Solar energy and utility power charge the battery simultaneously. (Default mode)
• OSO (Solo Solar): Solar energy is the sole source of charging, regardless of utility availability.

4.2 modos de salida

• Solar Primero: Prioritizes solar power for loads. If solar is insufficient, the grid or battery supplements.
• Primero la red eléctrica: Prioritizes utility power for loads. Solar power is used when utility is unavailable or for charging.
• Prioridad de SBU: Solar energy powers loads first. If solar is insufficient, battery power is used. If both are insufficient or battery voltage drops, utility power takes over.

4.3 Indicadores de luz RGB

The inverter features RGB lighting to indicate its current operating mode:

• Púrpura: Modo PV (la energía solar está activa).
• Rojo: Modo batería (funcionamiento con energía de batería).
• Azul: Utility Mode (Operating from grid/utility power).
• Blanco: Stationary Mode (Idle or standby).

Figure 5: RGB lighting indicates the inverter's current operational status.

5. Compatibilidad de la batería

The inverter is designed to work with various 48V battery types, including Lead-Acid (Sealed, AGM, Gel, Flooded) and Lithium batteries.

• The inverter can be used without batteries.
• For Lithium batteries, it can only be connected to PACE BMS. It is not compatible with BMS from other manufacturers.
• The inverter cannot communicate with other battery brands.
• If using a Lithium battery, select "User defined" in program 05 to configure battery parameters.

Figure 6: Supported battery types for the hybrid solar inverter.

6. Monitoreo y conectividad

The inverter includes a WiFi module for remote monitoring and control via a mobile application.

• The inverter can be used with a WiFi transmitter (included).
• Monitor your hybrid inverter anytime, anywhere, by registering via the dedicated app.
• The app provides real-time performance monitoring, data visualizations, and control over system settings.

Figure 7: WiFi module for remote monitoring via a smartphone app.

Figure 8: The system's operation can be controlled and monitored via mobile phone.

7. Seguridad y protección

The Anern Hybrid Solar Inverter is equipped with multiple protection features to ensure safe and reliable operation.

• Protección contra sobrecarga: Previene daños por carga excesiva.
• Protección contra sobretemperatura: Apaga la unidad si las temperaturas internas exceden los límites seguros.
• Protección contra cortocircuitos: Protege contra cortocircuitos en la salida.
• Protección contra la sobretensión: Protecciones contra el flujo excesivo de corriente.
• sobrevoltajetagy Protección: Protege contra el volumen de entradatage surge.
• Vol bajotagy Protección: Prevents deep discharge of batteries.
• Backfilling Protection: Evita el flujo de corriente inversa.
• Protección contra sobrecargas: Ensures batteries are not overcharged.

Figure 9: Visual representation of the inverter's comprehensive safety protections.

8. Mantenimiento

El mantenimiento regular ayuda a garantizar la longevidad y el rendimiento óptimo de su inversor.

• Protección contra el polvo: The inverter features a built-in removable dust protection grille. Regularly clean this grille to prevent dust accumulation, which can cause short circuits and reduce efficiency.
• Sistema de enfriamiento: The unit is equipped with three cooling fans for efficient heat dissipation. Ensure the fan vents are clear of obstructions to maintain proper airflow and prevent overheating.
• Conexiones: Revise periódicamente todas las conexiones eléctricas (PV, batería, entrada/salida de CA) para asegurarse de que estén firmes y libres de corrosión.
• Ambiente: Asegúrese de que el inversor esté instalado en un área bien ventilada, lejos de la luz solar directa, la humedad y materiales inflamables.

Figure 10: Features for easy maintenance and efficient cooling.

9. Solución de problemas

If you encounter any issues with your Anern 10.2KW Hybrid Solar Inverter, please refer to the following general guidelines. For specific error codes or persistent problems, consult the detailed troubleshooting section in the full product manual or contact customer support.

• Sin energía/pantalla apagada: Check all power connections, including battery and AC input. Ensure the on/off switch is in the 'on' position. Verify battery voltage está dentro del rango operativo.
• Sin salida de CA: Check for overload conditions. Reduce the load if necessary. Verify AC output breaker is not tripped. Check for fault indicators on the LCD screen.
• Sin carga solar: Asegúrese de que los paneles fotovoltaicos estén conectados correctamente y reciban suficiente luz solar. Compruebe el voltaje de entrada de los paneles fotovoltaicos.tage and current on the display. Verify MPPT controller is functioning.
• La batería no se carga: Check battery connections and ensure battery type settings are correct in the inverter's menu (Program 05). Verify AC input is present if using utility charging.
• Códigos de error: If an error code appears on the LCD, note the code and refer to the comprehensive manual for its meaning and recommended actions.

If issues persist after following these steps, please contact Anern customer support for assistance.

10. Especificaciones técnicas

11. Garantía y soporte

The Anern 10.2KW Hybrid Solar Inverter comes with a 1 año de garantía. For warranty claims, technical support, or any inquiries, please contact Anern customer service. Ensure you have your product model number (B0G18VC2JV) and purchase details available when contacting support.

Anern is committed to providing high-quality solar solutions and professional after-sales support. If you experience a malfunction, providing pictures or videos of the issue can help our technicians diagnose the problem efficiently.
