1. Introducción y másview
The Streamlight PolyStinger LED HAZ-LO is an intrinsically safe rechargeable flashlight designed for hazardous locations, atmospheres, and environments such as petrochemical, utility, and other heavy industrial applications. It features microprocessor-controlled intensity modes, a long-running moonlight mode, and advanced LED technology. The combination of rechargeable batteries and LED technology ensures low operating costs. The flashlight has a 50,000-hour LED lifetime and is constructed from super-tough, non-conductive nylon polymer with a camshaft-style grip. The lens is made from unbreakable polycarbonate with a scratch-resistant coating. Its deep-dish parabolic reflector provides a tight beam with optimal peripheral illumination for navigation. The multi-function, head-mounted electronic push-button on/off switch is designed for extended durability, tested at 1 million actuations. In moonlight mode, the PolyStinger LED HAZ-LO can operate for 20 days continuously.
2. Información de seguridad
ADVERTENCIA: Este producto contiene sustancias químicas que el estado de California reconoce como causantes de cáncer, defectos de nacimiento u otros daños reproductivos.
The PolyStinger LED HAZ-LO is intrinsically safe, meaning it is designed to prevent ignition of flammable gases, vapors, or dust in hazardous environments. Always ensure the flashlight is properly maintained and used according to its safety ratings to prevent accidents.
3. Características del producto
- LED technology for extreme brightness
- IPX4 Rated for water resistant operation
- 3 meter impact resistance tested
- LED Charge-continuity indicator on charger base
- Compact, snap-in charger mounts in any position
4. Configuración
4.1 Carga de la linterna
Before first use, fully charge the flashlight. The PolyStinger LED HAZ-LO includes both 120V AC and 12V DC chargers. Connect the appropriate charger to a power source and then to the charging base. Insert the flashlight into the charging base. The LED indicator on the charger base will illuminate to confirm that charging is in progress. A full charge typically takes several hours.
5. Instrucciones de funcionamiento
5.1 Encendido/apagado y selección de modo
The flashlight features a multi-function, head-mounted electronic push-button switch for operation. Press the button to cycle through the different light modes:
- Alto: Provides maximum brightness (130 lumens) for approximately 4 hours.
- Bajo: Offers reduced brightness (50 lumens) for extended runtime, approximately 12 hours.
- Modo de luz de luna: For extremely long runtime (up to 20 days) at very low illumination (1.3 lumens). Activate by pressing and holding the switch for approximately 10 seconds past the regular low mode.
To turn the flashlight off, cycle through all modes until the light extinguishes, or press and hold the button for a few seconds in any mode.
5.2 Strobe Feature
The flashlight also includes a strobe feature, which can be used for signaling or disorienting. Consult the detailed instructions included with your product for specific activation sequences for the strobe mode.
6. Mantenimiento
6.1 Limpieza
Limpiar la linterna con publicidad.amp cloth. Do not use abrasive cleaners or solvents, as these may damage the nylon polymer body or lens coating.
6.2 Cuidado de la batería
To maximize battery life, fully charge the flashlight before initial use and recharge regularly. Avoid complete discharge for extended periods. Store the flashlight in a cool, dry place when not in use.
6.3 Cuidado de las lentes
The polycarbonate lens is scratch-resistant. Clean with a soft, lint-free cloth to maintain optimal light output. Avoid touching the lens with bare hands to prevent smudges.
7. Solución de problemas
- La linterna no enciende: Ensure the battery is fully charged. Check for any obstructions in the charging port or switch mechanism.
- Luz tenue o parpadeante: Recargue la batería. Si el problema persiste, es posible que deba reemplazarla.
- El indicador de carga no funciona: Verify the charger and charging base connections. Ensure the power source is active.
If issues persist after attempting these troubleshooting steps, please contact Streamlight customer support for further assistance.
8. Especificaciones
| Característica | Detalle |
|---|---|
| Número de modelo | 76412 |
| Marca | Luz de corriente |
| Color | Amarillo |
| Fuente de poder | Battery Powered (Rechargeable NiCAD) |
| Tipo de fuente de luz | CONDUJO |
| Material | Nylon |
| Brillo blanco (alto) | 130 lúmenes |
| White Brightness (Low) | 50 lúmenes |
| Modo de luz de luna | 1.3 Lumens, 20 days runtime |
| Volumentage | 4.8 voltios (CC) |
| Light Path Distance (High) | 245 metros |
| Light Path Distance (Low) | 151 metros |
| Tiempo de ejecución (alto) | 4 horas |
| Tiempo de ejecución (bajo) | 12 horas |
| Nivel de resistencia al agua | Clasificación IPX4 (resistente al agua) |
| Resistencia al impacto | 3 metros |
| Peso del artículo | 16 onzas |
9. Garantía y soporte
9.1 Información de garantía
The Streamlight PolyStinger LED HAZ-LO Flashlight comes with a limited lifetime warranty. This warranty covers manufacturing defects and ensures the product's quality and durability under normal use. For full details on warranty coverage, terms, and conditions, please refer to the official Streamlight websitio o la tarjeta de garantía incluida con su producto.
9.2 Atención al cliente
For technical assistance, troubleshooting, or to inquire about warranty claims, please visit the official Streamlight websitio en www.streamlight.com or contact their customer service department directly. Contact information can typically be found on the websitio o en el embalaje del producto.
10. Recursos adicionales
10.1 Vídeo oficial del producto
Watch the official video for an overview of the Streamlight PolyStinger series, including the HAZ-LO model, and demonstrations of its features and operation.
