1. Einrichtung
1.1. Lieferumfang
Verify all components are present:
- 1 x CEYOMUR Trail Camera (Model CY70)
- 1 x Sonnenkollektor
- 1 x USB-Kabel
- 1 x Benutzerhandbuch
- 1 x Befestigungsgurt
- 1 x Befestigungswinkel
- 1 x Antenne
- 1 x Pinzette
- 1 x Pre-installed SIM Card
- 1 x 64 GB TF-Karte
1.2. Erste Vorbereitung
- SIM-Karte und TF-Karte einlegen: Open the camera housing. Locate the SIM card slot and TF card slot. Insert the pre-installed SIM card and the included 64GB TF card into their respective slots. Ensure they are correctly oriented and fully seated.
- Antenne anschließen: Screw the antenna onto the designated port on the top of the camera.
- Einschalten: Turn on the camera using the power switch located inside the housing.
Figure 1: Initial setup steps including inserting SIM/TF cards and attaching the antenna.
1.3. Montage der Kamera und des Solarpanels
The camera and solar panel can be mounted using the provided strap or bracket. Ensure the solar panel is placed in a location with adequate sunlight for optimal charging.
Video 1: Quick Guide: Trail Camera Mount Assembly. This video demonstrates how to assemble and mount the solar panel bracket for the CEYOMUR trail camera.
Figure 2: CEYOMUR CY70 Trail Camera with solar panel mounted on a tree, illustrating the power connection.
Figure 3: Solar panel providing continuous power to the trail camera in an outdoor setting.
2. Bedienung der Kamera
2.1. Dual-Mode-Funktionalität
The CEYOMUR CY70 operates in two modes: Traditional and 4G Cellular.
- Traditioneller Modus: Use the built-in 2-inch screen for direct setup, viewing, and playback of captured media. This mode does not require cellular data.
- 4G Cellular Mode: For remote access, live viewing, real-time alerts, and managing settings from your smartphone via the "TrailCam Go" app.
Figure 4: Demonstrating the dual viewing methods: remote via app and direct on-camera.
2.2. App Connection and Remote Features
Download the "TrailCam Go" app from your device's app store. Follow the in-app instructions to connect your camera. Once connected, you can:
- Receive real-time motion alerts.
- View Live-Videostreams.
- Wiedergabe von aufgezeichneten Videos und Fotos.
- Kameraeinstellungen fernsteuern.
- Monitor the camera's location on a map.
Abbildung 5: Fernbedienung viewing and playback of camera footage via the mobile application.
Figure 6: Monitoring camera location and adjusting settings through the app.
2.3. Bild- und Videoaufnahme
The camera captures 2K video and 48MP photos. In 4G mode, the maximum image resolution is 8MP.
- Bewegungserkennung: An advanced PIR sensor triggers recording in 0.2 seconds upon detecting movement.
- Nachtsicht: Equipped with 850nm low-glow infrared LEDs for clear nighttime footage without disturbing wildlife.
Figure 7: Daytime capture of wildlife with the CEYOMUR CY70 Trail Camera.
Figure 8: Night vision comparison, highlighting the clarity of CEYOMUR CY70's infrared LEDs.
Abbildung 9: Bspample of 2K video quality from the trail camera.
Figure 10: Illustration of the 0.2-second fast trigger speed.
Figure 11: Real-time motion alerts delivered to your smartphone.
Video 2: Video Clips of Trail Camera CY70Pro. This video showcases various video clips captured by the CEYOMUR CY70Pro trail camera, demonstrating its recording capabilities.
3. Wartung
3.1. Energieverwaltung
The CEYOMUR CY70 features an integrated 5200mAh rechargeable lithium battery and a 3W solar panel for continuous power. Ensure the solar panel is positioned to receive maximum direct sunlight to maintain battery charge. No external batteries are typically required for long-term operation.
Figure 12: Solar panel providing power to the trail camera, eliminating the need for disposable batteries.
3.2. Witterungsbeständigkeit
The camera is rated IP66 waterproof, providing protection against dust and strong jets of water. This ensures reliable operation in various outdoor weather conditions, including rain and snow.
Figure 13: IP66 waterproof rating ensures durability in harsh weather.
3.3. Reinigung
Reinigen Sie das Kameraobjektiv und das Solarpanel regelmäßig mit einem weichen Tuch.amp cloth to ensure optimal performance. Avoid using abrasive cleaners or solvents.
4. Fehlerbehebung
| Ausgabe | Mögliche Ursache | Lösung |
|---|---|---|
| Kamera lässt sich nicht einschalten | Low battery; Power switch off; Incorrect SIM/TF card insertion. | Ensure solar panel is receiving sunlight or charge via USB. Check power switch. Reinsert SIM/TF cards correctly. |
| No remote access/alerts | Poor 4G signal; SIM card not activated; App not configured correctly. | Verify 4G signal strength at camera location. Check SIM card status. Reconfigure app connection. |
| Schlechte Bild-/Videoqualität | Verschmutzte Linse; Schwache Lichtverhältnisse; Falsche Einstellungen. | Reinigen Sie die Linse. Stellen Sie ausreichende Beleuchtung oder die korrekte Aktivierung der Nachtsichtfunktion sicher. Passen Sie die Auflösungseinstellungen an. |
| Bewegungssensor löst nicht aus | PIR sensitivity too low; Obstructions in detection zone. | Increase PIR sensitivity in settings. Clear any foliage or objects blocking the sensor. |
Weitere Unterstützung finden Sie im Abschnitt Garantie & Support.
5. Spezifikationen
| Besonderheit | Detail |
|---|---|
| Modellnummer | CY70 |
| Konnektivität | 4G Mobilfunk |
| Stromquelle | Solar Powered, 5200mAh Lithium Ion Battery (included) |
| Videoauflösung | 2K HD |
| Fotoauflösung | Up to 48MP (8MP in 4G mode) |
| Nachtsicht | 850nm Low-Glow IR LEDs |
| Bewegungserkennung | 0.2s PIR Trigger Speed |
| Anzeige | Built-in 2-inch screen |
| Lagerung | TF Card (up to 128GB, 64GB included), Cloud Storage |
| Wasserbeständigkeit | IP66 |
| Abmessungen (L x B x H) | 5.31 x 3.94 x 2.99 Zoll |
| Gewicht | 1.83 Pfund |
| Im Lieferumfang enthaltene Komponenten | Trail Camera, Solar Panel, USB Cable, User Manual, Mounting Strap, Mounting Bracket, Antenna, Tweezers, SIM Card, 64GB TF Card |
6. Garantie und Support
6.1. Garantieinformationen
Die CEYOMUR CY70 Wildkamera wird mit einer 2 Jahr Garantie and parts replacement service. This warranty covers manufacturing defects and ensures peace of mind regarding product quality.
6.2. Kundendienst
For any questions regarding your 4G LTE camera, data plan, or technical assistance, please contact CEYOMUR's dedicated support team through the following channels:
- CEYOMUR Official Email: (Siehe Produktverpackung oder offizielle Angaben) webWebsite für eine bestimmte E-Mail-Adresse)
- Amazon Messaging: Contact seller via your Amazon order page.
- TrailCam Go App: Utilize the support features within the mobile application.
Our support team is committed to providing a worry-free experience and ensuring your complete satisfaction.
