RORIOS Fashion Men's Analog Quartz Chronograph Watch Instruction Manual

1. Einführung und Endeview

Thank you for choosing the RORIOS Fashion Men's Analog Quartz Chronograph Watch. This manual provides detailed instructions for the proper setup, operation, and maintenance of your new timepiece. Designed with a unique dial featuring a moon phase calendar and chronograph sub-dials, this watch combines sophisticated design with practical functionality.

This image displays the RORIOS Fashion Men's Watch, showcasing its elegant black dial, three chronograph sub-dials, Roman numeral markers, and robust metal band. The watch features a classic design suitable for various occasions.

A man wearing the RORIOS Fashion Men's Watch on his wrist, illustrating how the watch appears when worn. This highlights the watch's size and aesthetic appeal in a real-world context.

2. Produktmerkmale

• High Quality Chronograph: Features a unique dial with moon phase calendar, three functional sub-dials (seconds, minutes, and 24-hour indicator), Roman numeral time-stops, and textured diamond scales.
• Präzisions-Quarzwerk: Equipped with a durable and accurate Japanese Quartz movement for reliable timekeeping.
• Langlebige Konstruktion: Crafted with a high-quality polished stainless steel case and band for long-lasting wear.
• Wasserdicht bis 30 Meter: Suitable for daily use, including splashes from hand-washing, rain, and sweat. Nicht zum Schwimmen oder Tauchen geeignet.
• Leuchtfunktion: Hands and markers absorb light to glow in the dark, ensuring readability in low-light conditions.
• Verstellbares Armband: Comes with a free link remover tool to easily adjust the stainless steel band to your wrist size.

Dieses Bild liefert eine detaillierte Ansicht. view of the watch's multi-functional dial. It highlights the individual sub-dials for seconds, minutes, a sun/moon (24-hour) indicator, and the date calendar window, explaining their respective functions.

An illustration demonstrating the watch's 30-meter water resistance. This indicates the watch is designed to withstand splashes from rain, sweat, and hand-washing, but is not suitable for swimming or diving.

This image demonstrates the practical luminous function of the RORIOS watch. The hour markers and hands glow in low-light conditions, ensuring readability in the dark after absorbing light.

3. Einrichtung

3.1 Einstellen des Bandes

Your RORIOS watch comes with a stainless steel band that can be adjusted to fit your wrist. A link remover tool is included in the package for this purpose. If you are unsure how to use the tool, it is recommended to seek assistance from a professional watch repair service to avoid damaging the band.

This diagram provides precise measurements of the RORIOS watch, including the dial diameter (40mm), case thickness (10mm), band width (20mm), and band length (240mm). The total weight of the watch is 90g, offering a clear understanding of its physical characteristics.

3.2 Erste Zeit- und Datumseinstellung

To set the time and date, locate the crown on the right side of the watch case. The crown typically has three positions:

1. Position 0 (eingeschoben): Normale Betriebsstellung.
2. Position 1 (einen Klick herausgezogen): Wird zur Datumseinstellung verwendet.
3. Position 2 (zwei Klicks herausgezogen): Wird zur Zeiteinstellung verwendet.

4. Bedienungsanleitung

4.1 Uhrzeit und Datum einstellen

1. Einstellen der Uhrzeit: Gently pull the crown out to Position 2. Rotate the crown clockwise or counter-clockwise to move the hour and minute hands to the desired time. Once set, push the crown back to Position 0.
2. Einstellen des Datums: Gently pull the crown out to Position 1. Rotate the crown to adjust the date. Vermeiden Sie es, das Datum zwischen 9:00 Uhr und 3:00 Uhr einzustellen, da dies den automatischen Datumsänderungsmechanismus beeinträchtigen kann. Once set, push the crown back to Position 0.

4.2 Verwendung der Chronographenfunktion

The chronograph function allows you to measure elapsed time. Your watch features three sub-dials for seconds, minutes, and a 24-hour indicator.

1. Start/Stopp: Press the top pusher (button) on the side of the watch case to start the chronograph. Press it again to stop the measurement.
2. Zurücksetzen: While the chronograph is stopped, press the bottom pusher to reset all chronograph hands back to their zero positions.

4.3 Understanding the Moon Phase / 24-Hour Sub-dial

The sub-dial typically located at the 6 o'clock or 9 o'clock position (refer to your specific dial layout) indicates the 24-hour cycle, often represented with a sun and moon icon. This sub-dial helps differentiate between AM and PM when setting the time, especially for the date change mechanism.

5. Wartung

5.1 Wasserbeständigkeit

Your RORIOS watch is rated for 30 meters (3 ATM) of water resistance. This means it is suitable for everyday use and can withstand splashes, rain, and hand-washing. It is not designed for showering, bathing, swimming, diving, or any activities involving prolonged water immersion. Stellen Sie sicher, dass die Krone vollständig eingedrückt ist, bevor sie mit Wasser in Berührung kommt.

5.2 Reinigung Ihrer Uhr

Um das Aussehen Ihrer Uhr zu erhalten:

• Reinigen Sie Gehäuse und Glas regelmäßig mit einem weichen, trockenen, fusselfreien Tuch.
• For the stainless steel band, you can use a slightly damp Mit einem Tuch und milder Seife abwischen und anschließend gründlich trocknen. Scharfe Chemikalien oder scheuernde Materialien vermeiden.

5.3 Batteriewechsel

The watch is powered by a quartz battery. When the watch stops running, it indicates the battery needs replacement. It is highly recommended to have the battery replaced by a qualified watch technician to ensure proper sealing and maintain water resistance.

This image set emphasizes the precision and quality of the Japanese Quartz Movement within the RORIOS watch. It shows a watchmaker meticulously working on watch components, signifying the attention to detail and reliable engineering.

6. Fehlerbehebung

If you encounter any issues with your RORIOS watch, please refer to the following common troubleshooting steps:

• Uhr läuft nicht: Check if the crown is fully pushed in to Position 0. If it is, the battery may need replacement.
• Datum bleibt unverändert: Stellen Sie sicher, dass die Uhrzeit korrekt eingestellt ist, insbesondere die AM/PM-Einstellung. Vermeiden Sie es, das Datum während der automatischen Umstellungsphase (21:00–03:00 Uhr) einzustellen.
• Chronographenzeiger stellen sich nicht auf Null zurück: Try pressing the bottom pusher firmly. If the issue persists, a professional adjustment may be required.
• Kondensation unter Kristall: This may indicate a loss of water resistance. Avoid further contact with water and seek professional service immediately.

For issues not covered here, please contact RORIOS customer support.

7. Spezifikationen

8. Garantie und Support

Your RORIOS watch comes with a user manual and warranty information included in the packaging. Please refer to this document for specific warranty terms and conditions.

The front of the RORIOS watch packaging, a white box featuring the RORIOS brand logo. This is how the watch is presented when unboxed.

The back of the RORIOS watch packaging, displaying various regulatory labels, warnings, and manufacturer information. This includes details about compliance and handling.

RORIOS is committed to providing satisfactory products and services. If you encounter any problems with your watch or have questions not addressed in this manual, please contact RORIOS customer service. We are dedicated to providing a satisfactory resolution.
