LAUNCH Creader Elite BMW OBD2 Scanner Instruction Manual

Model: Creader Elite | Brand: LAUNCH

1. Einleitung

The LAUNCH Creader Elite is a professional-grade OBD2 diagnostic scanner designed specifically for BMW, MINI, and Rolls-Royce vehicles manufactured between 1996 and 2023. This powerful bi-directional scan tool offers comprehensive full system diagnostics, a wide range of reset services, ECU coding capabilities, and lifetime free updates to ensure continuous compatibility and functionality.

The device features a 4-inch LCD touchscreen, Wi-Fi connectivity for updates, and supports 11 languages for user convenience. It is built with a robust, orange-colored body with rubberized ends for durability and a secure grip.

LAUNCH Creader Elite main screen showing various diagnostic functions

Image: The LAUNCH Creader Elite diagnostic tool displaying its main menu with options like Diagnose, OBD II, Reset, Upgrade, Mall, and Settings. This image provides an overview of the device's user interface.

2. Einrichtung

2.1. Gerät überview

The Creader Elite features a 4-inch high-resolution color touchscreen and three physical buttons at the bottom for navigation. The device's body is rubberized for enhanced durability. On the bottom of the tool, a dust cover protects a USB-C connector and a slot for a memory card.

LAUNCH Creader Elite device with OBD2 cable and USB-C cable

Image: The LAUNCH Creader Elite diagnostic tool, showcasing its robust orange casing, 4-inch screen, and the attached OBD2 cable. A separate USB-C cable is also visible, highlighting the device's connectivity options.

2.2. Ersteinrichtung und Registrierung

  1. Einschalten: Schließen Sie das Gerät an den OBD2-Anschluss Ihres Fahrzeugs an. Das Gerät schaltet sich automatisch ein.
  2. Sprachauswahl: Folgen Sie den Anweisungen auf dem Bildschirm, um Ihre bevorzugte Sprache auszuwählen.
  3. Zeitzone: Stellen Sie die korrekte Zeitzone für Ihren Standort ein.
  4. Wi-Fi-Verbindung: Connect the device to a stable Wi-Fi network. This is crucial for software updates and device registration.
  5. Anmeldung: The device requires registration to access full diagnostic and update features. Use the provided QR code or visit the LAUNCH website to register your device using its serial number.
  6. Software-Update: After successful registration and Wi-Fi connection, navigate to the 'Upgrade' section to download and install the latest software for BMW, MINI, and Rolls-Royce.

3. Bedienung des Geräts

The main menu provides six primary functions: Diagnose, OBD II, Reset, Upgrade, Mall, and Settings.

3.1. Diagnostizieren

This function is used for in-depth vehicle diagnostics. It offers several options:

  • AutoDetect: The device attempts to automatically identify the vehicle's VIN and model.
  • Gesundheitsbericht: Performs a comprehensive scan of all modules in the vehicle, identifies fault codes, and generates a full status report. This report can be shared.
  • Systemscan: Scans the vehicle to determine which modules are present and equipped.
  • Systemauswahl: Allows direct access to specific vehicle modules (e.g., PCM, TCM, ABS, IMMO) to read fault codes, clear codes, or view Live-Datenströme.

Video: Demonstration of the Health Report function on the LAUNCH Creader Elite, showing how it scans various vehicle modules and displays diagnostic trouble codes (DTCs).

3.2. OBD-II

This mode provides standard OBD II diagnostic functions, compatible with various vehicle brands (not limited to BMW/MINI/Rolls-Royce). While it may not offer full bi-directional control or all service functions for non-BMW brands, it allows access to basic and advanced OBD II functionalities:

  • Read I/M Readiness: Checks if the vehicle is ready for a smog inspection.
  • Live-Daten lesen: Displays real-time data from various sensors (e.g., engine coolant temperature, oxygen sensor voltage). This data can be viewed in numerical format or as a graph, and can also be recorded for later review.
  • Standbild lesen: Erfasst eine Momentaufnahme der Sensordaten zum Zeitpunkt des Auftretens eines Fehlercodes.
  • Read Fault Code (Mode $03/$07/$0A): Retrieves diagnostic trouble codes.
  • Clear Fault Code (Mode $04): Erases diagnostic trouble codes and turns off the Check Engine Light.
  • Test Results: O2 Sensor Monitor (Mode $05): Zeigt die Testergebnisse der Sauerstoffsensorüberwachung an.
  • Test Results: On-Board Monitoring Test (Mode $06): Greift auf die Ergebnisse von On-Board-Diagnoseüberwachungstests für bestimmte Komponenten/Systeme zu.
  • Read Vehicle Information (Mode $09): Ruft Fahrzeuginformationen wie VIN, Kalibrierungs-IDs und Kalibrierungsprüfnummern ab.

3.3. Dienste zurücksetzen

The device supports a wide array of maintenance reset services for BMW, MINI, and Rolls-Royce vehicles:

  • Öl zurücksetzen
  • Transmission Reset
  • EPB (Elektronische Parkbremse) zurücksetzen
  • SAS (Steering Angle Sensor) Service Reset
  • Airbag Service Reset
  • ABS-Blutung
  • DPF (Dieselpartikelfilter) Regeneration
  • Battery Replacement/Registration
  • TPMS (Reifendruckkontrollsystem) zurücksetzen
  • IMMO (Immobilizer) Service
  • Injektorkodierung
Image showing various maintenance service functions like Oil Reset, ABS Bleeding, Battery Register

Image: A visual representation of the 'All Maintenance Service Functions' available on the LAUNCH Creader Elite, including Oil Reset, Transmission Reset, EBP Reset, SAS Service Reset, Airbag Service Reset, ABS Bleeding, DPF Regeneration, Battery Replacement, TPMS Reset, IMMO Service, and Injector Coding.

Video: This video demonstrates the 'All Systems All Maintenance Service' capabilities of the LAUNCH BMW Scanner, highlighting its ability to perform various reset and service functions across different vehicle systems.

3.4. Upgrade

This function allows you to update the device's software. Ensure the device is connected to Wi-Fi or a computer via USB-C for updates.

3.5. Einkaufszentrum

The 'Mall' section typically allows users to purchase additional software packages or functionalities for other vehicle brands, if available.

3.6. Einstellungen

Configure various device settings, including units of measurement, brightness, sound, network connection, time zone, and language.

4. Sonderfunktionen

The LAUNCH Creader Elite offers advanced special functions beyond standard diagnostics:

4.1. Steuergerätecodierung

This feature allows for customization and improvement of vehicle comfort and functionality. It can be used to:

  • Refresh hidden functions (e.g., fold/unfold mirrors automatically, unlock doors automatically).
  • Disable annoying functions (e.g., auto start-stop, seat belt warning sounds).
  • Perform retrofits (e.g., installing fog lights, retrofitting headlamps, changing battery type).
Image showing ECU Coding options like Acoustical confirmation, Active Rear Spoiler, SiriusXM coding

Image: The LAUNCH Creader Elite displaying 'Coding Made Professional' options, including Acoustical confirmation, Active Rear Spoiler, SiriusXM coding, Digital speedometer coding, Start & Stop button coding, Remote window control unlocking, Acoustic pedestrian protection, Active Cruise Control, Air conditioning setting memory, Automatic Air Recirculation, and Ambient lighting brightness.

Video: This video illustrates the 'Coding/Program' function of the LAUNCH BMW Full Diagnostic Tool, demonstrating how users can access and modify vehicle settings.

4.2. Bidirektionale Steuerung (Aktive Tests)

This feature allows the diagnostic tool to send commands to vehicle ECUs and control specific components, helping to accurately locate issues. ExampDie Dateien umfassen:

  • Den Kühlerlüfter einschalten
  • Modulieren der Drosselklappe
  • Bedienspiegel
  • Turning ON/OFF lights
  • Turning ON/OFF the horn
  • Activating door lock actuators
  • Aktivierung des Klimakompressors
  • Activation radiator shutter
  • AGR-Test
  • Einspritzdüsen-Summtest
  • IMRC-Test
  • Kraftstoffverteilerrohr-Druckprüfung
Image showing Key Immobilizer and Bi-directional (Active Test) functions

Image: The 'All-in-One Bidirectional Scan Tool' interface, detailing Key Immobilizer functions (Add/Disable & Reprogram Keys, Rewrite Smart Keys, Replace Smart Key ECU, Reset/Relearn Key, Replace Knob Ignition) and Bi-directional (Active Test) capabilities.

Video: This video demonstrates the 'Special Function' capabilities of the LAUNCH BMW Full Diagnostic Tool, showcasing various advanced diagnostic and control features.

4.3. Key Immobilizer

This function assists with key-related operations, including:

  • Adding, disabling, and reprogramming keys.
  • Rewriting smart keys.
  • Replacing smart key ECUs.
  • Resetting and relearning keys.
  • Replacing knob ignition components.

5. Spezifikationen

  • Marke: START
  • Modell: Creader Elite
  • Energiequelle: Batteriebetrieben
  • Produktabmessungen: 3.46 Zoll L x 1 Zoll B x 6.3 Zoll H
  • Betriebssystem: Android
  • Bildschirmgröße: 4 Zoll
  • Interner Speicher: 16 GB
  • Konnektivität: USB-C, WLAN
  • Unterstützte Sprachen: 11 (including English, French, Spanish, German, Italian, Russian, Portuguese, Korean, Japanese, Polish, Chinese)

6. Wartung

6.1. Software-Updates

Regular software updates are provided free for life. To ensure optimal performance and compatibility with the latest vehicle models, it is recommended to update the device regularly. Connect the device to a Wi-Fi network or a computer via the USB-C cable and navigate to the 'Upgrade' section in the main menu.

6.2. Datenverwaltung

The device allows for recording and playback of live data streams, as well as generating and sharing diagnostic reports. These features are useful for tracking vehicle performance over time and for sharing information with technicians or other users.

7. Fehlerbehebung

  • Gerät lässt sich nicht einschalten: Ensure the device is securely connected to the vehicle's OBD2 port. Check the vehicle's battery voltage.
  • Verbindungsprobleme: Verify the OBD2 cable is properly connected. For Wi-Fi issues, ensure the network is stable and the device is within range.
  • VIN Auto-Detection Failure: If the device fails to automatically detect the VIN, manually enter the vehicle information for diagnosis.
  • Fault Codes Persist After Clearing: If fault codes reappear immediately after clearing, it indicates an underlying issue that requires repair. Clearing codes only resets the warning light; it does not fix the problem.
  • Probleme mit Software-Updates: Ensure a stable internet connection during updates. If issues persist, try connecting the device to a computer for a wired update.

8. Garantie und Support

For any service problems, suggestions, or inquiries regarding this product, please contact LAUNCH customer support. You can reach them via email at:

  • Overseas Service: Übersee.service@cnlaunch.com
  • Verkaufsanfragen: sales@cnlaunch.com

Please refer to your local dealer for specific warranty information and support procedures.
