InnovaGoods Hannde Extendable Walking Cane User Manual

Indledning

This manual provides detailed instructions for the safe and effective use of your InnovaGoods Hannde Extendable Walking Cane. This multifunction mobility aid features an LED light, an alarm, a mechanical grabber, and an adjustable height for enhanced comfort and safety during walking.

Image: The InnovaGoods Hannde Extendable Walking Cane, showcasing its overall design with the main handle, adjustable shaft, and 4-point base.

Sikkerhedsoplysninger

• The cane is designed to support a maximum weight of 70 kg (154 lbs)Overskrid ikke denne grænse.
• The bag hook on the lower handle supports a maximum weight of 35 kg (77 lbs).
• Ensure all height adjustment pins are fully engaged and locked before use.
• Regularly check the cane for any signs of damage or wear. Do not use if any part is compromised.
• Replace batteries for the LED light and alarm promptly when they show signs of weakening.
• Consult a healthcare professional for guidance on proper cane usage and posture.
• Opbevares utilgængeligt for børn.

Pakkens indhold

• 1 x InnovaGoods Hannde Extendable Walking Cane (Model V0103837)

Opsætning

1. Battery Installation (for LED Light and Alarm)

1. Locate the battery compartment on the main handle of the cane.
2. Åbn dækslet til rummet.
3. Indsæt 2 x AAA batterier (not included), ensuring correct polarity (+/-).
4. Luk dækslet til batterirummet forsvarligt.

2. Højdejustering

1. Press the adjustment button located on the cane's shaft.
2. While holding the button, extend or retract the lower section of the shaft to your desired height. The cane offers 6 height levels, ranging from 80 cm to 93 cm.
3. Release the button, ensuring it clicks securely into one of the adjustment holes. Verify that the shaft is firmly locked in place before use.
4. For proper ergonomic use, the top of the cane handle should be at your wrist level when you stand upright with your arms relaxed at your sides.

Image: A person standing with the cane, demonstrating appropriate height adjustment for comfortable use.

Betjeningsvejledning

1. Brug af LED-lyset

Press the dedicated button on the main handle to activate the integrated LED light. The light can be tilted up to 45 degrees, allowing you to direct illumination precisely where needed, which is useful in dimly lit environments or for finding objects.

Billede: Et nærbillede view of the main handle, highlighting the LED light at the front.

Image: A user utilizing the cane's LED light to illuminate a keyhole in a dark setting.

2. Aktivering af alarmen

To activate the audible alarm, press the alarm button on the main handle. The alarm emits an 80 dB sound, which can be used to alert others in case of an emergency or potential danger.

Image: A user pressing the alarm button on the cane's handle, indicated by a sound icon.

3. Using the Mechanical Grabber

The cane features a mechanical grabber at its lower end. To use it, pull the grabber mechanism out from the bottom of the cane. Squeeze the lever on the main handle to open and close the grabber claws. This allows you to pick up objects from the floor, high shelves, or other hard-to-reach areas without bending. The grabber tips are equipped with magnets to assist in picking up metallic items. After use, retract the grabber back into the cane for storage.

Image: A user demonstrating the mechanical grabber function, picking up an object from the ground while seated.

4. Using the Double Handle and Bag Hook

In addition to the main upper handle, the cane includes a lower assistance handle. This handle can be folded out 90 degrees to provide extra support when transitioning between sitting and standing positions. It also features a convenient slot for hanging bags or other items, supporting up to 35 kg.

Image: A user gripping the lower assistance handle for additional support.

Image: A user utilizing the lower handle's slot to hang a small bag.

5. Stability and Self-Standing Feature

The cane is designed with a stable 4-point non-slip rubber base, providing firm support and allowing it to stand upright independently. To lift the cane from the ground without bending, you can gently press down on the base with your foot, causing the cane to tilt and become easily accessible.

Image: The cane standing independently on its stable 4-point rubber base.

Image: A user demonstrating how to lift the cane using their foot, avoiding the need to bend over.

Opretholdelse

1. Rensning

Tør spanskrøret regelmæssigt af med en blød kludamp cloth. Do not use abrasive cleaners, solvents, or harsh chemicals, as these may damage the materials.

2. Udskiftning af batteri

Replace the 2 x AAA batteries when the LED light dims significantly or the alarm sound weakens. Always ensure correct polarity during installation.

3. Opbevaring

Store the cane in a dry place, away from direct sunlight and extreme temperatures, to prolong its lifespan.

Fejlfinding

Specifikationer

Garanti og support

This InnovaGoods product is covered by a standard manufacturer's warranty. For warranty claims, technical support, or any inquiries regarding your product, please contact InnovaGoods customer service through their official channels or the retailer from whom you purchased the item. Please retain your proof of purchase for warranty purposes.
