Cylance MDR Pro Managed Detection and Response
Product Information
The CylanceMDR Pro is a comprehensive integration guide designed to help users integrate third-party log sources into the CylanceMDR system. It provides detailed steps for setting up the Windows Server Sensor and installing modular sensors for efficient data collection.
Specifications
- Product: CylanceMDR Pro
- Type: Integration Guide
- Support: Third-party Log Sources
- Date: 2024-12-05Z
Product Usage Instructions
- Installing the Windows Server Sensor
The Windows Server Sensor is a Windows service that captures events within the Windows Server system and sends data records to CylanceMDR. Follow these steps to install the Windows Server Sensor: - Windows Server Sensor Requirements
- OS Version: Windows Server 2008 R2 or later
- OS Updates: Ensure all Windows updates are complete before installation
- Firewall Ports: Open TCP port 8889 to receiver-cylancemdr.stellarcyber.cloud
- Other Software Considerations
To avoid conflicts with antivirus or EDR software, exclude the server sensor installation directories from scanning. Follow these steps before installation:- Right-click the .msi file > Properties
- In the Security section, click Unblock
- Click OK
- Integrating Third-Party Log Sources
To integrate third-party log sources, configure devices to forward log messages to the Modular Sensor and set up CylanceMDR to collect logs from third-party sources using API connectors. - Installing a Modular Sensor
To install a modular sensor, follow the provided guidelines for forwarding log messages and collecting logs from third-party sources using API connectors. Ensure compatibility with supported third-party log sources for telemetry data ingestion.
FAQ
- What are the key capabilities of the Windows Server Sensor?
The Windows Server Sensor captures events within the Windows Server system and sends data records to CylanceMDR. It provides real-time monitoring and data collection capabilities for enhanced security. - How can I ensure a smooth installation of the Windows Server Sensor?
To ensure smooth installation, make sure the host Windows Server meets the minimum requirements specified, update the OS, open the necessary firewall ports, and exclude installation directories from antivirus or EDR software scanning.
Integrating third-party log sources
When you integrate third-party log sources with CylanceMDR, you unify endpoint detection and response (EDR) with other security and business tools for improved visibility and control of security incidents across the business in a single console. Related telemetry data from various tools across the environment are automatically associated with a single incident, reducing manual effort and unnecessary context switching. Based on the efficacy, correlation, and actions of incidents from the various telemetry sources, CylanceMDR can be optimized to automatically take action against security incidents in real time.
A CylanceMDR Pro subscription is required to support the integration of third-party log sources. For more information about integrating third-party log sources with CylanceMDR so that suspicious activities can be reported and tracked from the Cylance console, see Integrating third-party log sources.
Steps for integrating third-party log sources
| Step Action |
| 1) If you have a Windows Server and you want to forward its event data to CylanceMDR, you need to install the sensor.
• Review the Windows Server Sensor requirements • Install the Windows Server Sensor |
| 2) If you want to forward logs from the third-party application (such as from a firewall or VPN application) to CylanceMDR, you need to install a modular sensor.
• Review the Modular Sensor requirements • Install a Modular Sensor in VMware • Install a Modular Sensor in Azure • Install a Modular Sensor in Hyper-V |
| 3) Configure devices to Forward log messages to the Modular Sensor. |
| 4) Configure CylanceMDR to Collect logs from third-party sources using API connectors. |
Installing the Windows Server Sensor
The Windows Server Sensor (agent) runs as a Windows service in a compatible Windows Server system. It observes events within the Windows Server system and sends data records to CylanceMDR. The sensor captures the following events:
- Hardware
- Security
- System
- Windows Firewall
- Windows Defender
- PowerShell
- File Integrity Monitoring
The Windows Server Sensor provides the following key capabilities:
- If the sensor is installed on the same network as the domain controller, CylanceMDR enriches data with the relationship between users and IP addresses.
- If the sensor is installed on the same network as the DHCP server, CylanceMDR enriches data with the relationship between hostnames and IP addresses, so assets can be tracked even when the IP address changes.
Windows Server Sensor requirements
The host Windows Server into which the Windows Server Sensor is installed must meet the following minimum requirements, regardless of whether it is a physical or virtual server:
| Component Specification |
| Host Requirements
• CPU: Xeon Core 2 virtual cores (2.0 GHz or more) • RAM: 8 GB • Disk space (SSD): 64 GB |
| OS version Windows Server 2008 R2 (or later) |
| OS updates
As a best practice, use Windows Update to ensure that the Windows Server software is up-to-date and all pending updates are complete before installing the Windows Server Sensor. The Windows Server Sensor includes the AI_ChainedPackageFile.vc_redist.x64.exe redistributable from Microsoft which requires the following packages: • KB2919355 • KB2999226 |
| Firewall ports Open TCP port 8889 to receiver-cylancemdr.stellarcyber.cloud |
| Other software considerations
To avoid potential conflicts with antivirus or EDR software, configure any such software that’s installed on the same host as the Windows Server Sensor to exclude the server sensor installation directories from scanning. Exclude the following directories on the Windows Server Sensor host: • C:\ProgramData\Stellarcyber • C:\Program Files\Aella |
Install the Windows Server Sensor
Before you begin:
- Review the Windows Server Sensor requirements.
- Obtain the token for the Windows Server Sensor from the CylanceMDR onboarding team.
- Download the Windows Server Sensor installation (.msi) file.
- Some Windows systems automatically block files you download from running. To unblock the .msi file:
- Right-click the .msi file > Properties.
- In the Security section, click Unblock.
- Click OK.
- To start the installation, double-click the .msi file. If you see a dialog box asking you to verify that you want to run this file, click Run.
- Choose the following installation path for the agent installation: C:\Program Files\Aella. An error message occurs if you try to install at a different path.
- Specify the following:
- Token: Specify the installation token that is provided by the CylanceMDR onboarding team to register your Windows Server Sensor with your CylanceMDR tenant.
- Click Install.
The installer installs the Windows Server Sensor. - When the installation completes, click Finish. The sensor is installed as a service.
After you finish:
- To verify the installation, on the Windows Server Sensor host, open the Services app and look for Windows Agent Sensor Ctrl.
- To verify the connection to the tenant, open Windows Agent Sensor CLI and enter show cm in the command line.
Installing a Modular Sensor
You can install a Modular Sensor to collect and forward logs to CylanceMDR. For example, you can set up your organization’s firewall syslogs, DHCP/DNS/IP network syslogs, and syslogs from other applications to forward log entries to the Modular Sensor. The sensor collects the entries and forwards them to CylanceMDR.
Modular Sensor requirements
| Item Description |
| Host Requirements
• CPU: 4 cores • RAM: 8 GB • Disk space (SSD): 64 GB |
| Firewall ports
Open TCP port 8889 to receiver-cylancemdr.stellarcyber.cloud |
Install a Modular Sensor in VMware
When you install a Modular Sensor in VMware, you also need to create and specify a port group as well as apply a token to associate it with your CylanceMDR tenant.
Before you begin:
- Review the Modular Sensor requirements.
- Obtain a token for the Modular Sensor from the CylanceMDR onboarding team.
- Download the .ova file for the Modular Sensor.
- Log in to the vSphere client.
- Right-click the VM host on which you want to install the port group and click Add Networking.
- Select the Virtual Machine Port Group for a Standard Switch option.
- Click Next.
- Enter the following:
- Name: The name of this port group.
- vLAN ID: 4095
- Virtual switch: Select an existing virtual switch that you want to use.
- Promiscuous mode: Accept
- MAC Address changes: Inherit from vSwitch
- Force transmits: Inherit from vSwitch
- In the vSphere client, on the VM host where you want to install and deploy the Modular Sensor, specify the following settings.
- OVF template: Specify the Modular Sensor .ova file.
- Virtual machine name: Specify a name for the Modular Sensor VM.
- Compute resource: Specify the compute resource to use for the Modular Sensor VM.
- Storage: Specify the datastore drive to use for VM storage and its configuration.
- Provisioning type: Specify Thick.
- Network mappings: Select the VM network that you want to use.
- Power On automatically: Deselected.
- Verify the settings and click Finish.
The deployment is completed. This might take several minutes. - After successful deployment, click the VM.
- Click Edit.
- Click Add network adapter.
- Besides the New adapter field, select the port group that you created earlier.
- Click Save.
- Power on the VM.
- Do the following to set a static IP address for the Modular Sensor and apply the token to associate it with CylanceMDR:
- Open the VM for your Modular Sensor. A command line appears.
- Enter your login information. The default username/password is aella/change me. You are prompted to change the password immediately.
- Set a static IP address for the modular sensor using the following commands:
- set interface management ip <ip_address>
- set interface management gateway <gateway_ip_address>
- set interface management dns <dns_ip_address>
- Enter set token string <token>, where <token> is the token provided by the CylanceMDR onboarding team. The message “Sensor token is successfully set” appears.
After you finish:
- To verify the connection with CylanceMDR use the following commands:
- show interface
- show cm
- show version
- The CylanceMDR onboarding team completes the configuration for your CylanceMDR tenant to receive logs from your Modular Sensor.
Install a Modular Sensor in Azure
Depending on your Microsoft Azure subscription, installing and using the Modular Sensor in Azure may incur additional costs. After you install the sensor, you need to apply a token to associate it with your CylanceMDR tenant.
Before you begin:
- Review the Modular Sensor requirements.
- Obtain a token for the Modular Sensor from the CylanceMDR onboarding team.
- Log in to your Azure portal at https://portal.azure.com/.
- On the Dashboard screen, Click Azure Active Directory.
- Click Properties.
- Copy the Tenant ID field.
- Copy and paste the following URL into your browser address bar and replace <tenant_id> with the Tenant ID that you copied.
https://login.microsoftonline.com/<tenant_id>/oauth2/authorize?client_id=58238038-43b4-4446-8260-0fa97ace1085&response_type=code&redirect_uri=https%3A%2F%2Fwww.microsoft.com%2F. - In the Permissions Requested dialog, select Consent on behalf of your organization.
- Click Accept.
- Click Enterprise Applications.
- On the Enterprise applications | All applications screen, search for Stellar.
A list of applications appears. If you don’t see a list of applications, contact CylanceMDR support. - If necessary, create a new resource group. If you want to use an existing resource group, proceed to the next step.
- Click Resource Groups.
- Click Add.
- In the Subscription field, choose your subscription.
- In the Resource group field, enter the name of your group.
- In the Region field, choose the region where you want to deploy the resource.
- Click Review + Create.
- Click Create.
- On the Resource Groups screen, click the name of the resource group where you want to deploy the sensor.
- Click Access Control (IAM).
- Click Add role assignments.
- Click the privileged administrator roles tab.
- Select the Contributor option.
- In the Assign access to drop-down list, keep the default selection of User, group, or service principal.
- In the Select field, type Stellar.
- Choose Stellar Cyber Software Packages.
- Click Save.
- In the left pane, click Home. The Azure services screen appears.
- On the Azure services screen, click Subscriptions.
- Click the subscription that you want to use.
Note: Depending on your Azure subscription, you may incur additional costs. - Click Resource Providers.
- Click Microsoft.Network.
- Click Register.
- Click Microsoft. Compute.
- Click Register.
- On the top right of the screen, click the Cloud Shell icon.
- Enter the following commands to retrieve an access token (each command should be one line):
- az account clear
- az login –service-principal -u ‘58238038-43b4-4446-8260-0fa97ace1085’-p ‘3238Q~KMtVAIyuC6gDVMhboKEW7w6W~bXYQhFcZx’ –tenant ‘2f580e30-1cc1-4c08-9e80-704999508e1a’
- az account get-access-token
- Enter the following commands to retrieve and access the token using the Tenant ID that you copied earlier (each command should be one line).
- az login –service-principal -u ‘58238038-43b4-4446-8260-0fa97ace1085′ -p’3238Q~KMtVAIyuC6gDVMhboKEW7w6W~bXYQhFcZx’ –tenant ‘<Tenant ID>’
- az account get-access-token
- Use the following one-line command to output a list of Azure subscriptions:
- az account list –output table
- Make sure that the subscription that you want to deploy the sensor to is the default (i.e. IsDefault=True). Use the following one-line command to set it:
- az account set –subscription <subscription>
- Enter the following one-line command to create a Modular Sensor VM. Replace <resource-group> with an existing resource group in your deployment and <version> with the version of software you want to install (for example, 5.2.0)
- az vm create –size Standard_B12ms –resource-group <resource-group> –name StellarModularSensor –image “/subscriptions/0e28f851- f477-4f2d-94bc-35c00d3d5fd8/resource groups/Stellar/providers/ Microsoft.Compute/galleries/StellarCyberSoftwares/images/Stellar-ModularSensor/ versions/<version>” –admin-username azure-user –admin-password P@ssw0rd#2022 –os-disk-size-gb 128
Note that you can specify the virtual network and subnet by including the –vnet-name <vnet-name> and –subnet <subnet-name> parameters. The networks must exist in the same resource group as the VM.
- az vm create –size Standard_B12ms –resource-group <resource-group> –name StellarModularSensor –image “/subscriptions/0e28f851- f477-4f2d-94bc-35c00d3d5fd8/resource groups/Stellar/providers/ Microsoft.Compute/galleries/StellarCyberSoftwares/images/Stellar-ModularSensor/ versions/<version>” –admin-username azure-user –admin-password P@ssw0rd#2022 –os-disk-size-gb 128
- Do the following to set a static IP address for the Modular Sensor and apply the token to associate it with CylanceMDR:
- Open the VM for your Modular Sensor. A command line appears.
- Enter your login information. The default username/password is aella/change me. You are prompted to change the password immediately.
- Set a static IP address for the modular sensor using the following commands:
- set interface management ip <ip_address>
- set interface management gateway <gateway_ip_address>
- set interface management dns <dns_ip_address>
- Enter set token string <token>, where <token> is the token provided by the CylanceMDR onboarding team. The message “Sensor token is successfully set” appears.
After you finish:
The CylanceMDR onboarding team completes the configuration for your CylanceMDR tenant to receive logs from your Modular Sensor.
Install a Modular Sensor in Hyper-V
When you install a modular sensor in a Hyper-V environment, you need to create a virtual switch with a physical network interface that supports promiscuous mode. Promiscuous mode allows the sensor to monitor all traffic. During the setup, you will specify the number of cores, the amount of memory, and disable processor compatibility mode.
Before you begin:
- Review the Modular Sensor requirements.
- Download the Hyper-V virtual disk image.
- In the Hyper-V manager, in the right pane, click Virtual Switch Manager.
- In the left pane, under the Virtual Switches section, click New virtual network switch.
- Select External.
- Click Create Virtual Switch.
A switch is created and listed in the Virtual Switches section. - In the left pane, under the Virtual Switches section, select the switch that was created in the previous step.
- Type a name for the switch and make note of it.
- In the Connection Type section, select External network and the appropriate network interface to connect to external networks.
- Click OK.
- Open Windows PowerShell and use the following commands to set promiscuous mode.
- $a = Get-VMSystemSwitchExtensionPortFeature -FeatureId 776e0ba7-94a1-41c8-8f28-951f524251b5
- $a.SettingData.MonitorMode = 2
- add-VMSwitchExtensionPortFeature -ExternalPort -SwitchName <name of the switch>
– VMSwitchExtensionFeature $a
Replace <name of the switch> with the name you set in the previous step.
- In the Hyper-V manager, in the Action menu, click New > Virtual Machine.
- Specify a name for the new sensor. It is recommended to use a site naming convention so that the type of sensor can be easily identified by its name.
- Click Next.
- Select Generation 1 for the generation type. The guest operating system is a 64-bit OS, so you can select “Generation 1”.
- Specify the amount of memory (in megabytes) to assign to the VM.
It is recommended that you assign at least 1.5 times the number of CPU cores for the memory in gigabytes. For example, if you plan to use 8 virtual cores, assign 12 GB of RAM (8 * 1.5 = 12). You can adjust the number of cores at a later step. - Configure the Management network interface. You can either enter a static IP or configure using a DHCP server. This is the interface that will be used for the sensor to send its Interflow data records to the data processor.S
- Select Use an existing virtual hard disk to attach the virtual disk image that you downloaded. You need to specify its location.
- Click Finish.
In the Hyper-V manager, the virtual machine that you created is listed. - Select the virtual machine in the list.
- In the right pane, click Settings.
- In the left pane, click Processor.
- Specify the number of virtual cores for this VM.
- Click Apply.
- In the left pane, expand the processor entry and select Compatibility.
- Ensure that the Migrate to a physical computer with a different processor version option is disabled.
- Click OK.
- Do the following to set a static IP address for the Modular Sensor and apply the token to associate it with CylanceMDR:
- Open the VM for your Modular Sensor. A command line appears.
- Enter your login information. The default username/password is aella/changeme. You are prompted to change the password immediately.
- Set a static IP address for the modular sensor using the following commands:
- set interface management ip <ip_address>
- set interface management gateway <gateway_ip_address>
- set interface management dns <dns_ip_address>
- Enter set token string <token>, where <token> is the token provided by the CylanceMDR onboarding team.
The message “Sensor token is successfully set” appears.
After you finish:
- To verify the connection with CylanceMDR use the following commands:
- show interface
- show cm
- show version
- The CylanceMDR onboarding team completes the configuration for your CylanceMDR tenant to receive logs from your Modular Sensor.
Forwarding log messages to the Modular Sensor
- You can configure devices (for example, firewall) in your environment to forward log messages (for example, syslog) to the Modular Sensor so that CylanceMDR analysts can track suspicious activity.
- You need to forward log messages from your device (for example, firewall) to the Modular Sensor from a specific port so that the Modular Sensor receives the messages successfully. Follow the instructions from your vendor to set up your device to forward the logs messages. For the list of ports that you need to open in your environment, see Supported third-party log sources for telemetry data ingestion.
Collect logs from third-party sources using API connectors
- You can allow CylanceMDR to collect logs from various sources by providing the necessary information to the CylanceMDR onboarding team to configure it in your tenant.
- The following table lists some example log sources that can use API connectors. For more information, contact the CylanceMDR onboarding team.
| Log source Required information |
| Cato Networks Provide the following information to the CylanceMDR team:• Your Cato Networks account ID. • A Cato Networks API key that you created for CylanceMDR. • Make sure that you enable events integration for your Cato Networks account. To obtain this information: 1. Log in to your Cato Networks account. 2. In your user profile (profile icon > My Profile), verify that you have the Editor role. 3. Obtain the account ID from the URL on the browser address bar. For example, if the URL is https://myorganization.cc.catonetworks.com/#/account/1234/topology, the account ID is 1234. 4. To create an API key, navigate to Administration > API Management. 5. Click the New key. 6. Type a name to easily identify this key, for example, “CylanceMDR Pro”. 7. Click Apply. The API key is created and a dialog appears with the option to copy it. 8. Click Copy to copy the API key from the dialog and save it to a secure location. 9. Click OK to close the dialog. 10. To enable events integration, navigate to Administration > API & Integrations. 11. In the Events Integration tab, turn on the Enable Integration with Cato Events option. |
| HIBUN Provide the following information (obtained from Hitachi Solutions) to the CylanceMDR team:• Customer Code • Username • Password The password should not contain non-ASCII special characters. |
| Microsoft Active Directory Provide the following information to the CylanceMDR team:• The Active Directory domain to be monitored • The fully qualified domain name (FQDN) or IP address for an Active Directory Server configured as a Domain Controller • The protocol type (LDAP, LDAPS, or LDAPS with certificate validation disabled) • Active Directory username and passwords with appropriate permissions • If you want to collect Active Directory logs from the Modular Sensor, you need to add the Active Directory server domain and domain controller to the same DNS where the Modular Sensor is installed. For Collect-only configurations, the username and password need to be a standard Active Directory user who is a member of the domain to be monitored. The password should not include non-ASCII special characters. For Respond configurations (if you want to also allow CylanceMDR to respond to a detected threat by disabling an Active Directory user account), do the following: 1. Launch Active Directory Users and Computers with administrative credentials. 2. Right-click on the Organizational Unit with the user account for which you want to enable the respond action authority, and select Delegate Control. 3. Select the user or group to which you want to delegate the authority, then click Next. 4. Select Create Custom Task to Delegate and click Next. 5. In the Delegation of Control Wizard, select Only the following objects in the folder radio button. 6. Select User objects and click Next. 7. In the Show These Permissions section, select only the Property-specific option. Select the General and Creation/Deletion of specific child objects options. 8. In the specific permissions section, select the checkboxes for Read userAccountControl and Write userAccountControl. 9. Click Next. 10. Click Finish. |
| Microsoft Azure Active Directory / Provide the following information to the CylanceMDR team: Entra ID • Application (client) ID
• Directory (tenant) ID • Secret Key (password) To obtain this information for configuring CylanceMDR, you need to: • In the Azure AD portal, register the CylanceMDR application. • In the AD manifest, set allowPublicClient to “true”. • Create a new client secret (password) for CylanceMDR. • Set the API permissions (application permissions) for Microsoft Graph and specify the logs that you want to collect. A super admin must grant admin consent. For more information, see the Microsoft documentation. |
| Microsoft Azure Event Hub Event Hub Name: The name of the Event HubConnection String: Find the connection string in Azure. You must use a unique connection string for each instance Consumer Group: The consumer group for the Event Hub Event Source: The source of the events you want to collect from Event Hub. You must configure log sources to send data to the Event Hub. • AzureActivityLog • AzureBastion • AzureFirewall • AzureKeyVault • AzureSecurityCenter • AzureSecurityGroups • AzureSQLServer (includes AuditEvent log ) • AzureStorage • AzureSynapseWorkspace • AzureWebApplicationFirewall |
| Netskope Provide an API token from the Netskope Admin Console to the CylanceMDR team.To obtain the API token, do the following: 1. Log in to the Netskope Admin Console as an administrative user. 2. Navigate to Settings > Tools. 3. Click Rest API v2 > New Token. 4. Click Add Endpoint and select the API endpoints to use with the token. • /api/v2/events/data/alert (supports data types: policy, dlp, watchlist) • /api/v2/events/data/application (supports data type: application) • /api/v2/events/data/page (supports data type: page) • /api/v2/steering/ipsec/pops (supports data type: pops) • /api/v2/steering/ipsec/tunnels (supports data type: tunnels) 5. Select the privileges for each of the endpoints. You must select Read at a minimum. 6. Click Save. The API key is created and a dialog appears with the option to copy it. 7. Click COPY TOKEN to copy the API token and save it to a secure location. 8. When you are done, click OK. |
Supported third-party log sources for telemetry data ingestion
The following table lists the third-party products that can be integrated with CylanceMDR as a log source for telemetric data ingestion. Beside each log source is the port that needs to be opened in your organization’s environment so that CylanceMDR can collect and ingest the log data, and the data fields that will be collected and indexed in CylanceMDR.
| Device Port Index |
| HTTP JSON 5200 (TCP only) Syslog |
| JSON 5142 Syslog |
| (OpnSense) Zenarmor plugin logs 5604 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| AAA – Core (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Accops 5526 Traffic (srcip), Syslog (otherwise) |
| Ahnlab AIPS 5647 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Ahnlab EMS 5657 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Ahnlab EPP 5640 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| AhnLab Policy Center 5571 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| AhnLab TrusGuard 5558 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| AirGap Ransomware Kill Switch 5602 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| AIX 5523 Traffic (event_time: time format of hour:minute:second), Syslog (otherwise) |
| Alcatel Lucent Switch 5677 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Aliyun / AliCloud 5545 ML IDS/Malware (threat), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Android 5605 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Apache HTTP Server (httpd) 5663 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| AQTRONiX WebKnight 5658 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Aqua Cloud Native Application Protection 5656 Traffic (srcip, srcport, dstip, dstport, and
Platform (CNAPP 2022.4) proto), Syslog (otherwise) |
| Arbor Peakflow SP 5598 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Array Networks APV Series Load 5680 Traffic (srcip, srcport, dstip, dstport, and
Balancing & App Delivery proto), Syslog (otherwise) |
| Array Networks ASF 1800 5675 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Array Networks Secure Access Gateway 5537 Traffic (srcip), Syslog (otherwise) |
| Aruba ClearPass Policy Manager (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Aruba Switch 5577 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Automox 5183 Syslog |
| Avanan 5681 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Avanan (HTTP JSON) 5200 (TCP only) Syslog |
| Avaya Switch 5607 Traffic (srcip, srcport, dstip, dstport, and proto) Syslog (otherwise) |
| AWS WAF 5200 (TCP only) Syslog |
| Azure ATP (CEF) 5143 Traffic (srcip, srcport, dstip, dstports, and proto), Syslog (otherwise) |
| Azure MFA 5528 Traffic (srcip), Syslog (otherwise) |
| Barracuda email 5559 ML IDS/Malware (threat), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Barracuda firewall 5524 ML IDS/Malware (sub_dev_type: fw_threat or fw_av), Traffic (srcip), Syslog (otherwise) |
| Barracuda WAF 5524 ML IDS/Malware (sub_dev_type: fw_threat or fw_av), Traffic (srcip), Syslog (otherwise) |
| BeyondTrust BeyondInsight 5621 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| BeyondTrust PasswordSafe 5692 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Bitdefender (HTTP JSON) 5200 (TCP only) Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| BlackBerry CylancePROTECT 5177 Traffic (srcip), Syslog (otherwise)
& CylanceOPTICS |
| BlueCoatProxySG 5576 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Brocade switch (system & admin logs) 5548 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Calyptix UTM 5161 ML IDS/Malware (ids.signature), Traffic (srcip), Syslog (otherwise) |
| Centos Audit 5673 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Centrify 5165 Syslog |
| Cerberus FTP Logs 5635 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Check Point – Application Control (CEF) 5143 ML IDS/Malware (threat, normalized
from attack_information), Traffic (srcip, srcport,dstip,dstport, and proto), Syslog (otherwise) |
| Check Point – URL Filtering (CEF) 5143 ML IDS/Malware (threat, normalized
from attack_information), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| CheckPoint appliance 5174 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| CheckPoint firewall 5519 Traffic (srcip), Syslog (otherwise) |
| CheckPoint Harmony EP 5618 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| CheckPoint VPN-1 & FireWall-1 (CEF) 5143 ML IDS/Malware (threat, normalized
from attack_information), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Cisco ASA 5518 Traffic (srcip), Syslog (otherwise) |
| Cisco CUCM 5532 Syslog |
| Cisco ESA 5562 ML IDS/Malware (threat), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Cisco ESA 5164 (deprecated) Syslog |
| Cisco Firepower 5168 Traffic (srcip), Syslog (otherwise) |
| Cisco IKE 5176 Syslog |
| Cisco IronPort 5163 Syslog |
| Cisco ISE 5157 Syslog |
| Cisco MDS 5563 ML IDS/Malware (threat), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Cisco Meraki 5172 Traffic (srcip), Syslog (otherwise) |
| Cisco Netflow 2055 (UDP only) Traffic |
| Cisco routers and switches 5158 Syslog |
| Cisco UCS 5579 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Cisco Umbrella 5521 Syslog |
| Cisco VPN 5156 Syslog |
| Cisco WLC 5531 Syslog |
| Citrix Access Gateway 5688 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Citrix NetScaler 5166 Syslog |
| Citrix NetScaler (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Comodo- CIS CCS (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| CoreLight Sensor 5575 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| CoSoSys Endpoint Protection 5654 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Cribl / NXLog 5142 Windows Events |
| Cribl default (Syslog JSON) 5142 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| CrowdStrike (beats) 5044 Syslog |
| CrowdStrike (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| CyberArk PTA (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Cynet (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| D-Link 5189 Traffic (srcip), Syslog (otherwise) |
| DBSafer 5181 Syslog |
| Deep Instinct 5628 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Dell EMC Powerstore 5683 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Dell iDRAC 5566 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Dell Switch 5578 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| DHCP (beats) 5044 Traffic (srcmac), Syslog (otherwise) |
| DHCPD (IS DHCP) 5554 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| DNSVault RPZdb 5639 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Dragos (CEF) 5539 Traffic (srcip), Syslog (otherwise) |
| DrayTek Firewall 5593 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| eDictionary – eDictionary (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Egnyte (Syslog JSON) 5142 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Ericom ZTEdge 5603 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| ESET PROTECT 5655 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| ExtraHop (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Extreme AirDefense 5612 Traffic (srcip, srcport, dstip, dstport, and proto) Syslog (otherwise) |
| Extreme Controller 5666 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| ExtremeCloud IQ Site Engine 5614 Traffic (srcip, srcport, dstip, dstport, and
proto) Syslog (otherwise) |
| F5 – ASM (CEF) 5143 ML IDS/Malware (threat, normalized from attack_type), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| F5 BIG-IP 5162 ML IDS/Malware (IDS signature), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| F5 BIG-IP Telemetry (HTTP JSON) 5200 (TCP only) Syslog |
| F5 IPI 5536 ML IDS/Malware (dev_type: /threat/), Traffic (dstip), Syslog (otherwise) |
| F5 iRule 5536 ML IDS/Malware (dev_type: /threat/), Traffic (dstip), Syslog (otherwise) |
| F5 L7 DDOS 5536 ML IDS/Malware (dev_type: /threat/), Traffic (dstip), Syslog (otherwise) |
| F5 Mitigation 5536 ML IDS/Malware (dev_type: /threat/), Traffic (dstip), Syslog (otherwise) |
| F5 NGINX 5151 Syslog |
| F5 Silverline 5536 ML IDS/Malware (dev_type: /threat/), Traffic (dstip), Syslog (otherwise) |
| F5 VPN 5187 Syslog |
| F5 WAF 5536 ML IDS/Malware (dev_type: /threat/), Traffic (dstip), Syslog (otherwise) |
| FatPipe Networks SD-WAN 5583 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| FluentD (HTTP JSON) 5200 (TCP only) Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Forcepoint 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Forcepoint – Firewall (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Forcepoint -DLP (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Forcepoint -Firewall (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Forcepoint Web Security (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| ForeScout 5154 Syslog |
| Fortinet FortiAnalyzer 5542 ML IDS/Malware (vendor.attack_name), Traffic (dstip), Syslog (otherwise) |
| Fortinet FortiAuthenticator 5671 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Fortinet Forticloud FortiClient EMS Cloud 5682 Traffic (srcip, srcport, dstip, dstport, and
Endpoint Management Services proto), Syslog (otherwise) |
| Fortinet FortiEDR 5661 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Fortinet FortiGate 5517 Traffic (action), Syslog (otherwise) |
| Fortinet Fortigate (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Fortinet FortiMail 5616 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Fortinet FortiSandbox 5648 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Fortinet FortiWeb 5642 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| FutureSystems WeGuardia SSL plus (SSL 5651 Traffic (srcip, srcport, dstip, dstport, and
VPN) proto), Syslog (otherwise) |
| Graylog format 5569 Windows Events (winlogevent), ML IDS/Malware (threat), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Guardicore (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| HanDreamnet VIPM 5676 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Hewlett Packard UNIX 5585 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Hillstone 5514 ML IDS/Malware log_type: threat), Traffic (log_type: traffic), |
| HPE Switch 5595 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| IBM AS400 5632 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Impero ContentKeeper 5670 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Imperva – SecureSphere (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Incapsula SIEM Integration (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Indusface Web Application Firewall 5582 ML IDS/Malware (threat), Traffic (srcip,
srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Infoblox Data Connector (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Infoblox Network Identity OS (NIOS) 5587 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Infocyte HUNT (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| IPFIX 4739 (UDP only) Traffic (srcip, srcport, dstip, dstport, and proto) |
| IronScales (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Jsonar Database Security Tool 5586 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Juniper SRX 5173 Traffic (srcip), Syslog (otherwise) |
| Juniper SSG 5516 Traffic (srcip), Syslog (otherwise) |
| Juniper Switch 5591 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| KasperskyLab (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Kemp Technologies Load Master LB 5695 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Keycloak 5653 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Lancope – StealthWatch (LEEF) 5522 Traffic (srcip), Syslog (otherwise) |
| LanScope Cat 5588 Syslog |
| Lepide 5607 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Linux Syslog 5555 ML IDS/Malware (threat), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Logstash Suricata 5629 ML IDS/Malware (threat), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Mailboarder Agent 5580 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Mako Networks firewall 5547 Traffic (dstip), Syslog (otherwise) |
| ManageEngine ADAudit Plus 5679 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| ManageEngine ADAuditPlus (CEF) 5143 Windows Events |
| McAfee (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| McAfee Advanced Threat Defense 5584 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| McAfee ePolicy Orchestrator 5533 Traffic (srcip), Syslog (otherwise) |
| McAfee Firewall 5169 Traffic (srcip), Syslog (otherwise) |
| McAfee Network Security 5527 Traffic (srcip), Syslog (otherwise) |
| MCAS SIEM Agent (CEF) 5143 Windows Events |
| Medigate 5631 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Menlo Security MS-XL50M 5630 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Microsoft IIS 5636 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Microsoft IIS (Syslog JSON) 5142 Syslog |
| Microsoft Office 365 5627 Windows Events |
| Microsoft Windows Event 5646 Windows Events (winlogevent), Syslog
(otherwise) |
| Microsoft Windows via Graylog 5569 Windows Events (winlogevent) |
| MicroWorld eScan 5645 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| MikroTik firewall and router 5553 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| MONITORAPP AI WAF 4.1 5613 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| MONITORAPP WAF 1.0 5535 Traffic (srcip), Syslog (otherwise) |
| Nasuni 5592 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| NetApp 5608 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Netfilter 5544 Traffic (dstip), Syslog (otherwise) |
| NetIQ – Identity Manager (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| NetIQ Access Manager 5167 Syslog |
| NetIQ SSO 5171 Syslog |
| Netman Smart NAC 5650 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| NetMotion 5641 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| NXLog 5601 Windows Events (winlogevent), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| OneLogin 5581 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Open LDAP 5164 Syslog |
| OpenCanary 5638 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| OpenShift 5573 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| OpenVPN 5643 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| OPNsense 5660 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Oracle DB 5170 Traffic (srcip), Syslog (otherwise) |
| Oracle Solaris 5664 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Ordr Connected Device Security 5622 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| PacketFence 5686 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Palo Alto Networks – Next Generation 5522 Traffic (srcip), Syslog (otherwise)
Firewall (LEEF) |
| Palo Alto Networks – Traps Agent (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Palo Alto Networks firewall 5515 Traffic (type: traffic), ML IDS/Malware
(type: threat), Syslog (otherwise) |
| Palo Alto Networks Firewall via Graylog 5569 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Penta Security WAPPLES WAF 5560 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Peplink XDR 5665 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Perception Point X-Ray 5667 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| pfSense Firewall 5543 Syslog |
| PIOLINK WEBFRONT-K 5617 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| PrintChaser 5179 Syslog |
| Privacy-i 5178 Syslog |
| Proofpoint 5596 Syslog |
| Pulse Secure 5534 Syslog |
| Radware DefensePro 5619 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Rapid7 5153 Syslog |
| RazLeeSecurity – Audit (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| RSA Authentication Manager 5184 Syslog |
| Ruckus ZoneDirector 5662 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| RuiJie Switch 5689 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| SafePC 5180 Syslog |
| Sangfor NGAF 5637 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| SECUI Firewall 5561 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| SECUI MF2 Firewall 5570 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| SECUI MFD 5611 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Secureki APPM 6 5693 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Security Strategy Research (SSR) Metieye 5572 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Secuway SSLVPN 5652 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| SentinelOne (CEF2) 5175 Traffic (srcip), Syslog (otherwise) |
| SentinelOne Mgmt (CEF) 5143 ML IDS/Malware (threat, normalized from
classification), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| SentinelOne Security Center (CEF) 5143 ML IDS/Malware (threat, normalized from
classification), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| SentinelOne Singularity Mobile 5623 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| ServiceNow Now Platform 5668 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| ShareTech Firewall 5609 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Snare Agent 5590 Windows Events (winlogevent), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Sniper IPS 5182 Traffic (srcip), Syslog (otherwise) |
| SonicWall – NSA 2400 (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| SonicWall (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| SonicWall Firewall 5152 ML IDS/Malware (IDS signature), Traffic (srcip), Syslog (otherwise) |
| SonicWall VPN 5556 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Sophos (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Sophos (JSON) 5530 Traffic (endpoint_type: traffic), ML IDS/ Malware (endpoint_type: threat), Syslog (endpoint_type: computer) |
| Sophos endpoint 5565 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Sophos endpoint (beats) 5044 Traffic (srcip), Syslog (otherwise) |
| Sophos firewall 5520 Data goes to the indicated index based on the log_type: |
| Sophos Web Appliance 5626 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Splunk Heavy Forwarder 5188 Syslog |
| Stormshield Net Security Firewall 5625 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Symantec (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Symantec Endpoint Protection 5525 Traffic (dstip), Syslog (otherwise) |
| Symantec Firewall 5155 Syslog |
| Symantec Messaging Gateway 5567 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Synology Directory Server 5597 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Thales Group CipherTrust Manager 5674 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Trellix FireEye HX 5644 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Trend Micro – Deep Security Agent (LEEF) 5522 Traffic (srcip), Syslog (otherwise) |
| Trend Micro (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Trend Micro Apex Central (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Trend Micro Interscan Messaging 5678 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Trend Micro Proxy 5540 Traffic (dstip), Syslog (otherwise) |
| Trend Micro TippingPoint Intrusion 5672 Traffic (srcip, srcport, dstip, dstport, and
Prevention System (IPS) proto), Syslog (otherwise) |
| Tripwire Enterprise 5186 Syslog |
| Ubiquiti 5552 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Unix 5633 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Untangle Firewall (Syslog JSON) 5142 ML IDS/Malware (threat), Traffic (srcip,
srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Varonis DatAdvantage (CEF) 5143 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Versa Networks Firewall 5568 ML IDS/Malware (threat), Traffic (srcip,
srcport, dstip, dstport, and proto), Syslog (otherwise) |
| VMware – Carbon Black (LEEF) 5522 Traffic (srcip), Syslog (otherwise) |
| VMware ESXi 5600 Syslog |
| VMWare Horizon 5687 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| VMware NSX-T Data Center 5574 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| VMware UAG 5620 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| VMware Vcenter 5615 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| VMWare VeloCloud SD-WAN 5685 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| WatchGuard – XTM (LEEF) 5522 Traffic (srcip), Syslog (otherwise) |
| WatchGuard firewall security appliance 5557 Traffic (srcip, srcport, dstip, dstport, and
proto), Syslog (otherwise) |
| Wazuh 5634 Windows Events (winlogevent) , Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Windows DNS Server 5599 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Windows Event NXLog 5601 Windows Events (winlogevent), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Windows System Security 5610 Windows Events (winlogevent), Traffic
(srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Wins IPS ONE-1 / Wins DDX 5538 ML IDS/Malware (vendor.attack_name),
Syslog (otherwise) |
| WINS Sniper NGFW 5649 Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Zix Mail 5185 Traffic (srcip), Syslog (otherwise) |
| Zscaler NSSWeblog (CEF) 5143 Syslog |
| Zscaler ZIA Firewall 5549 ML IDS/Malware (threat), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Zscaler ZIA Web 5550 ML IDS/Malware (threat), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Zscaler ZPA | 5551 | ML IDS/Malware (threat), Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
| Zyxel Firewall | 5594 | Traffic (srcip, srcport, dstip, dstport, and proto), Syslog (otherwise) |
Legal notice
©2024 BlackBerry Limited. Trademarks, including but not limited to BLACKBERRY, BBM, BES, EMBLEM Design, ATHOC, CYLANCE, and SECUSMART are the trademarks or registered trademarks of BlackBerry Limited, its subsidiaries and/or affiliates, used under license, and the exclusive rights to such trademarks are expressly reserved. All other trademarks are the property of their respective owners. Patents, as applicable, are identified at: www.blackberry.com/patents.
This documentation including all documentation incorporated by reference herein such as documentation provided or made available on the BlackBerry website provided or made accessible “AS IS” and “AS AVAILABLE” and without condition, endorsement, guarantee, representation, or warranty of any kind by BlackBerry Limited and its affiliated companies (“BlackBerry”) and BlackBerry assumes no responsibility for any typographical, technical, or other inaccuracies, errors, or omissions in this documentation. To protect BlackBerry’s proprietary and confidential information and/or trade secrets, this documentation may describe some aspects of BlackBerry technology in generalized terms. BlackBerry reserves the right to periodically change information that is contained in this documentation; however, BlackBerry does not commit to providing any such changes, updates, enhancements, or other additions to this documentation to you promptly or at all.
This documentation might contain references to third-party sources of information, hardware or software, products or services including components and content such as content protected by copyright and/or third-party websites (collectively the “Third Party Products and Services”). BlackBerry does not control, and is not responsible for, any Third Party Products and Services including, without limitation the content, accuracy, copyright compliance, compatibility, performance, trustworthiness, legality, decency, links, or any other aspect of Third Party Products and Services. The inclusion of a reference to Third Party Products and Services in this documentation does not imply endorsement by BlackBerry of the Third Party Products and Services or the third party in any way.
EXCEPT TO THE EXTENT SPECIFICALLY PROHIBITED BY APPLICABLE LAW IN YOUR JURISDICTION, ALL CONDITIONS, ENDORSEMENTS, GUARANTEES, REPRESENTATIONS, OR WARRANTIES OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY CONDITIONS, ENDORSEMENTS, GUARANTEES, REPRESENTATIONS, OR WARRANTIES OF DURABILITY, FITNESS FOR A PARTICULAR PURPOSE OR USE, MERCHANTABILITY, MERCHANTABLE QUALITY, NON-INFRINGEMENT, SATISFACTORY QUALITY, OR TITLE, OR ARISING FROM A STATUTE OR CUSTOM OR A COURSE OF DEALING OR USAGE OF TRADE, OR RELATED TO THE DOCUMENTATION OR ITS USE, OR PERFORMANCE OR NON-PERFORMANCE OF ANY SOFTWARE, HARDWARE, SERVICE, OR ANY THIRD PARTY PRODUCTS AND SERVICES REFERENCED HEREIN, ARE HEREBY EXCLUDED. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY BY STATE OR PROVINCE. SOME JURISDICTIONS MAY NOT ALLOW THE EXCLUSION OR LIMITATION OF IMPLIED WARRANTIES AND CONDITIONS. TO THE EXTENT PERMITTED BY LAW, ANY IMPLIED WARRANTIES OR CONDITIONS RELATING TO THE DOCUMENTATION TO THE EXTENT THEY CANNOT BE EXCLUDED AS SET OUT ABOVE, BUT CAN BE LIMITED, ARE HEREBY LIMITED TO NINETY (90) DAYS FROM THE DATE YOU FIRST ACQUIRED THE DOCUMENTATION OR THE ITEM THAT IS THE SUBJECT OF THE CLAIM.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW IN YOUR JURISDICTION, IN NO EVENT SHALL BLACKBERRY BE LIABLE FOR ANY TYPE OF DAMAGES RELATED TO THIS DOCUMENTATION OR ITS USE,
OR PERFORMANCE OR NON-PERFORMANCE OF ANY SOFTWARE, HARDWARE, SERVICE, OR ANY THIRD-PARTY PRODUCTS AND SERVICES REFERENCED HEREIN INCLUDING WITHOUT LIMITATION ANY OF THE FOLLOWING DAMAGES: DIRECT, CONSEQUENTIAL, EXEMPLARY, INCIDENTAL, INDIRECT, SPECIAL, PUNITIVE, OR AGGRAVATED DAMAGES, DAMAGES FOR LOSS OF PROFITS OR REVENUES, FAILURE TO REALIZE ANY EXPECTED SAVINGS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, LOSS OF BUSINESS OPPORTUNITY, OR CORRUPTION OR LOSS OF DATA, FAILURES TO TRANSMIT OR RECEIVE ANY DATA, PROBLEMS ASSOCIATED WITH ANY APPLICATIONS USED IN CONJUNCTION WITH BLACKBERRY PRODUCTS OR SERVICES, DOWNTIME COSTS, LOSS OF THE USE OF BLACKBERRY PRODUCTS OR SERVICES OR ANY PORTION THEREOF OR OF ANY AIRTIME SERVICES, COST OF SUBSTITUTE GOODS, COSTS OF COVER, FACILITIES OR SERVICES, COST OF CAPITAL, OR OTHER SIMILAR PECUNIARY LOSSES, WHETHER OR NOT SUCH DAMAGES WERE FORESEEN OR UNFORESEEN, AND EVEN IF BLACKBERRY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW IN YOUR JURISDICTION, BLACKBERRY SHALL HAVE NO OTHER OBLIGATION, DUTY, OR LIABILITY WHATSOEVER IN CONTRACT, TORT, OR OTHERWISE TO YOU INCLUDING ANY LIABILITY FOR NEGLIGENCE OR STRICT LIABILITY.
THE LIMITATIONS, EXCLUSIONS, AND DISCLAIMERS HEREIN SHALL APPLY: (A) IRRESPECTIVE OF THE NATURE OF THE CAUSE OF ACTION, DEMAND, OR ACTION BY YOU INCLUDING BUT NOT LIMITED TO BREACH OF CONTRACT, NEGLIGENCE, TORT, STRICT LIABILITY OR ANY OTHER LEGAL THEORY AND SHALL SURVIVE A FUNDAMENTAL BREACH OR BREACHES OR THE FAILURE OF THE ESSENTIAL PURPOSE OF THIS AGREEMENT OR OF ANY REMEDY CONTAINED HEREIN; AND (B) TO BLACKBERRY AND ITS AFFILIATED COMPANIES, THEIR SUCCESSORS, ASSIGNS, AGENTS, SUPPLIERS (INCLUDING AIRTIME SERVICE PROVIDERS), AUTHORIZED BLACKBERRY DISTRIBUTORS (ALSO INCLUDING AIRTIME SERVICE PROVIDERS) AND THEIR RESPECTIVE DIRECTORS, EMPLOYEES, AND INDEPENDENT CONTRACTORS. IN ADDITION TO THE LIMITATIONS AND EXCLUSIONS SET OUT ABOVE, IN NO EVENT SHALL ANY DIRECTOR, EMPLOYEE, AGENT, DISTRIBUTOR, SUPPLIER, INDEPENDENT CONTRACTOR OF BLACKBERRY OR ANY AFFILIATES OF BLACKBERRY HAVE ANY LIABILITY ARISING FROM OR RELATED TO THE DOCUMENTATION.
Before subscribing for, installing, or using any Third Party Products and Services, it is your responsibility to ensure that your airtime service provider has agreed to support all of their features. Some airtime service providers might not offer Internet browsing functionality with a subscription to the BlackBerry® Internet Service. Check with your service provider for availability, roaming arrangements, service plans, and features. Installation or use of Third Party Products and Services with BlackBerry’s products and services may require one or more patents, trademarks, copyright, or other licenses to avoid infringement or violation of third-party rights. You are solely responsible for determining whether to use Third Party Products and Services and if any third-party licenses are required to do so. If required you are responsible for acquiring them. You should not install or use Third Party Products and Services until all necessary licenses have been acquired. Any Third Party Products and Services that are provided with BlackBerry’s products and services are provided as a convenience to you and are provided “AS IS” with no express or implied conditions, endorsements, guarantees, representations, or warranties of any kind by BlackBerry and BlackBerry assumes no liability whatsoever, in relation thereto. Your use of Third Party Products and Services shall be governed by and subject to you agreeing to the terms of separate licenses and other agreements applicable thereto with third parties, except to the extent expressly covered by a license or other agreement with BlackBerry.
The terms of use of any BlackBerry product or service are set out in a separate license or other agreement with BlackBerry applicable thereto. NOTHING IN THIS DOCUMENTATION IS INTENDED TO SUPERSEDE ANY EXPRESS WRITTEN AGREEMENTS OR WARRANTIES PROVIDED BY BLACKBERRY FOR PORTIONS OF ANY BLACKBERRY PRODUCT OR SERVICE OTHER THAN THIS DOCUMENTATION.
BlackBerry Enterprise Software incorporates certain third-party software. The license and copyright information associated with this software is available at http://worldwide.blackberry.com/legal/thirdpartysoftware.jsp.
- BlackBerry Limited
2200 University Avenue East Waterloo, Ontario Canada N2K 0A7 - BlackBerry UK Limited
Ground Floor, The Pearce Building, West Street, Maidenhead, Berkshire SL6 1RL United Kingdom
Published in Canada.
Documents / Resources
 |
Cylance MDR Pro Managed Detection and Response [pdf] Installation Guide MDR Pro Managed Detection and Response, MDR Pro, Managed Detection and Response, Detection and Response, Response |
