GT08 Smart Watch Instructions

Smart Watch

User Guide

Please read this manual before using

V1.2

Attention before using:

1. Watchband tightness standards: cross the watchband,can be added into an index finger as the standard;
2. Pairing connection for the first time, without using bluetooth pairing method, only need close NFC on the watchband to mobile phone NFC antenna location nearly .Smart Watch NFC antenna position ,please reference the overview products (diagram).
3. Use watchband for the first time, will be tight, hard to buckle into , pls follow as below methods: Put right index finger inside of the watchband ,from the top push button in.

Use watchband

1. Safe instructions and main precautions

1.1 The company reserves the right to revised the manual without any prior notice.
1.2 Please charge more than 2 hours before using
1.3 Security Code

To prevent others use your product without authorization,the original password is 1122.In order to ensure the security of your personal information, please modify the original password and remember it.

2. Product Introduction

2.1 Introduction

Components of Smart Watch

Power button: Turn on/off, Wake up, Shut down,Back;

USB:Charging and data function;

Touch screen: capacitive touch screen, the function can be operationed in capacitive touch screen.

2.2 Enter Quickly

After turn on,finger drag left enter the next menu, drag right to return back the menu;Finger drag from the top to
down, enter into the notification bar,from the bottom to top, back to the main menu.
Drag distance need drag over half of the screen,if drag too short, will be mistaken for a click.
The function icon can be place the position freely according to your ideas , click ok to sure.

2.3 Using the Clock screen

While using the Watch, press the Power button to open the Clock screen.Then click the central of screen to change clock type.

Clock screen

Setup ways:

method 1:turn on,on the Clock screen,click the central of screen to change clock type.,there are 3 types can be selected.
method 2:turn on,enter the menu :setup–phone setup–Standby menu–Unlock type selection.

2.4 Theme Settings

Setting Method:

Go into the smart watch menu: themes-theme Settings-select your theme

3. Operation Quickly

3.1 Download the synchronous software

Methods 1、turn on the menu of watches – enter into QR Codes directory, using mobile phone QR code scanning
software scan the QR code on the watch.。
Methods 2、Using mobile phone scan below QR code to download

QR code

Method 3,using mobile browser, enter the following URL to download
http://c3.cli.im/FT5K1A
After download,according the prompts to install the application. This Program only support synchronization
between watch and android smart phone,will not charge mobile phone network traffic.
If you have downloaded relevant software from other channels , please check the software version,
please use the latest version of the synchronization software, to ensure the normal use of function.
If software version has upgraded, please update synchronization software.

3.2 Installation and use synchronization software

Android application software installation:

On smartphone, according to the normal android software installation, when installation complete,
can be stored into the phone memory or synchronization assistant software installation can be used.

Android applications use method: ( installed software already)

(smartphone)Enter the Settings –auxiliary Settings–bluetooth notice (services) click enter,
enable the service.
(when start using, there will be a warning, please select “ok”) software can be automatically run in the background,
synchronizing function can be used .as following:

synchronizing function

Click on the bluetooth notice, choose “notification service”,
in the “notice”,choose to push personal application or system application you need;
Telephone service function, including text messages and telephone;Looking for watch。

Note:when you use the back-end to clean up or close the back-end application software,
please do not close this bluetooth notification service,
if closed, sync will influence the watch with a mobile phone.

3.3 Bluetooth connectivity and synchronization function

3.3.1 from the mobile phone to connect Watch

Enter Mobile phone settings – turn on bluetooth – search equipment, when find GT08,
click choose matching, and select “yes” on the watch, matching success, when there is a phone book request,
please click “ok”,
it is better choose “next time no longer prompt” at the same time,
convenient for next time connection, the phone book will sync directly, not prompt again.
Note:If has installed a synchronization software,
pls also turn on this synchronization software on mobile phone in auxiliary function,
after connection,within 2-5 seconds, the mobile phone terminal will show the bluetooth connected;
on smart watch at the same time,will prompts you automatic synchronization cellphone time,
it indicates that the synchronization function is enabled.When mobile phone have a new message coming,
will synchronization to smart watches in timely.
3.3.2From the smart watch to connect mobile phone
On the smart watch,select the bluetooth dialer – click to search bluetooth device –
find your smartphone (such as samsung 9500) – click connection;the continue process operation as 3.3.1
3.3.2From the smart watch to connect mobile phone On the smart watch,
select the bluetooth dialer – click to search bluetooth device – find your smartphone (such as samsung 9500)
– click connection;the continue process operation as 3.3.1
Note: At the same time,the mobile phone need turn on the bluetooth
and allow to be searched by around bluetooth products

3.4 Function menu description

3.4.1 Message mobile phones synchronous message or smart watch message

3.4.2 Bluetooth

3.4.3 Set up the state of the bluetooth, turn on or off.

3.4.4 Call Records

3.4.5 After connecting the bluetooth, you can view your call status of the near term。

Bluetooth Dialer :

From the watches to connect the mobile phone for matching;

3.4.6 Remote Notification

Synchronous Show the message from mobile phone terminal , such as: QQ, WeChat, messages, time, Twitter, Facebook etc.;

3.4.7 Remote Take Photos

Controlling from the watch,using mobile phone camera take pictures;Need turn on the android mobile phone’s camera advance.

3.4.8 Anti-lost

Watch looking for mobile phone or mobile phone looking for watch. Two-way anti lost;

3.4.9 Setup

Note: In the phone setting, you can set the clock type and theme;In the security Settings, the default security code: 1122

3.4.10 Pedometer

In pedometer Settings, drag to left, you can see steps and burn calories, speed, mileage etc.
movement information;
In the process of movement, if want to go back to the main menu, and don’t want to stop step function,
please press the power button.pedometer function will continue to run in the background.
Motion synchronization data, please see the behind dynamic capabilities.

3.4.11 Sleep Monitoring

According to your sleep time to show the quality of your sleep.

3.4.12 Sedentary Remind

Can set up the time, remind you need to take exercise;It is recommended that one time at least per hour;

3.4.13 QR code

Scan the QR code, can download the synchronization software, if have the new version software to upgrade,
please contact with our company, we will provided the new download address;Please do not use WeChat or QQ
,or others browser scanning and download.

3.4.14 Intelligent search

Searching for the relevant information on the watch

3.4.15 Clock

3.4.16 Calendar

3.4.17 Calculator

3.4.18 Profiles

3.4.19 File Manager

3.4.20 Music Player

Can play music on the watch and mobile phone music connected bluetooth;

3.4.21 Theme, as shown in the theme Settings

3.4.22 Camera

3.4.23 Video recording device

3.4.24 Photo

3.4.25 Video Player

3.4.26 Record

4.Precautions for use

4.1 Please charge fully before use, charging time need 1-2 hours.
4.2 Charge line can use android smartphone charge line and authentic charger;
Or use the standard configuration
accessories;
4.3 Bluetooth disconnect if exceeds the distance, after using two-way anti-lost,if do not reconnect again,
it cannot use the search function;
4.4 Using bluetooth,it will be disconnect occasionally,please reconnect(if over 5 minutes not connected,
need connect manually)When connection,
please pay attention to choose agree with the phone book synchronous;Otherwise,
it will not be able to show the calls from phone book;
4.5 Music function, because of there are different android mobile phone,
some will show the name of the song ,some mobile phone is can not show the name of the song, this is normal.

5. Dynamic movement data synchronization function

5.1 Download Dynamic movement back-end service software

QR code

Method one: scan the QR code, installation Dynamic movement
background services software;Installation method as above;
Method Two: Log in background services website: www.fundo.cc download dynamic movement APK;

5.2 Sport data storage and sharing
5.2.1 Registered ID and login dynamic server, to accurate accounting sport data and give you the correct guidance,pls set your parameters, including height, weight, age.
5.2.2 Connect Smart Watch and mobile phone bluetooth,
and connect the bluetooth synchronization software;Same as above
5.2.3 After do exercise, click the “reset” data on the watch, can store multiple data
5.2.4 In the mobile phone, use dynamic software synchronous data,
synchronization data to back-end to share and store.Back-end will record your movement process and data
5.2.5 Please reference the function and use introduction on the website about the other function
and new features for the dynamic movement software.
5.2.6 Dynamic service website:www.fundo.cc

6. NFC Application

6.1 The smart watch with NFC function(Near Filed Communication);
Bluetooth pairing password has been written into the smart watch when production on factory
6.2 Smart Watch paired with mobile phone bluetooth, turn on mobile phones bluetooth,
smart watch NFC antenna position close nearly to the mobile phone NFC antenna position
(the different phone will be on different position,
can be searched by move slowly in mobile phone’s back around),
the phone will automatically prompt the bluetooth pairing;
Then pairing as usual.After the smart watch pairing with mobile phones,
need to connect again,or disconnected,
only need two NFC antenna close nearly to contact, without any manual processing.
6.3 Write the content into smart watch NFC:
6.3.1 Mobile phone download the write NFC software ,
there are too many kinds of software sold on the market,we recommended TagWriter
it can be download easy,please installed like android software after downloading;
6.3.2 Written software instructions ( TagWriter for example):
1) open the software, as following figure (figure 1) View is to read,
to read data for NFC module .Please see the content what has been written.
Create and write is to write documents

2) Click Create and write go into the next interface:(figure 2)
3) Write in a bluetooth address and password, click New, shown as figure 3,
and then select bluetooth, shown as figure 4,
then searching the connected Bluetooth watch (such as M2)

4) click the device name M2, and then go into the next interface (figure 5),
click Next enter the Next step shown as figure 6, tick the write multiple NFC,
click Next ,in the next step, shown as figure 7.
Using mobile phone antenna position close to smart watch NFC antenna position,
wait for 2 seconds, watches and cell phone issued a “tick”at the same time,success shown as figure 8.

5) write other content, steps and methods are same as above, only in
step 3), choose a different content, it can be message or contacts.

7. Common Troubleshooting Guides

If have any problems when using the smart watch, please refer to the following terms and conditions.
If the problem still exists, please contact the dealer or the designated maintenance personnel.

7.1 Can not turn on
Press the power button too short, please press over 3 seconds.
Battery Power too low, please charge.
7.2 Shut down automatic Battery Power too low, please charge.
7.3 Using time is very short
Not fully battery power, please make sure Charging enough time (minimum 2 hours).
Use the SIM card, but the signal is very poor, lead to cell phone use big current.
7.4 can’t normal charge
Check whether the battery is available, the performance of the battery will reduce after a few years.
Check the charger is working correctly, change the new charger to try Check the connect USB charging line interface
try again.
7.5 Not show the caller’s name
When the bluetooth connection, it not choose to upload directory;or not tick uploaded phone book;
Reconnect again, do not sync the contacts, please reconnect again and pairing.
7.6 Voice quality is not good
Smart watch and the mobile phone too far away, please come close;
Or bluetooth signal is bad.
The mobile phone signal is bad, change another place to answer the phone.
7.7 Dynamic data can’t sync, because of not log in the back-end,
movement data can’t save in the back-end,please register and log in.

FCC Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions
(1) This device may not cause harmful interference,
and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

SAR:

The radiated output power of this device is below the FCC
radio frequency exposure limits. Nevertheless, the device
should be used in such a manner that the potential for human
contact is minimized during normal operation.
The exposure standard for wireless devices employs a unit of
measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC is 1.6 W/Kg. Tests for SAR are
conducted using standard operating positions accepted by the
FCC with the device transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR
level of the device while operating can be well below the
maximum value. This is because the device is designed to
operate at multiple power levels so as to use only the power
required to reach the network. In general, the closer you are to
a wireless base station antenna, the lower the power output. To
avoid the possibility of exceeding the FCC radio frequency
exposure limits, human proximity to the antenna should be
minimized.
