Introduction
Thank you for choosing the Genérico EB-007 Bluetooth 5.4 TWS Earbuds. This manual provides essential information for setting up, operating, and maintaining your new earbuds. Please read it carefully to ensure optimal performance and longevity of your device.
Image: Genérico EB-007 Bluetooth 5.4 TWS Earbuds and their charging case.
Product Overview and Key Features
The Genérico EB-007 earbuds are designed for a superior audio experience with advanced features:
- Bluetooth 5.4 Connectivity: Ensures a stable, fast, and energy-efficient wireless connection with minimal latency.
- High-Quality Audio: Delivers clear sound with balanced bass, suitable for music, videos, and calls.
- IPX4 Water Resistance: Protected against sweat and splashes, making them ideal for workouts, running, and daily use.
- Noise Reduction Microphone: Provides clearer calls even in noisy environments, enhancing professional and personal communication.
- Ergonomic Design: Lightweight and comfortable for prolonged wear, ensuring a secure fit.
- Broad Compatibility: Easily pairs with iOS and Android smartphones, tablets, and other Bluetooth-enabled devices.
- Extended Battery Life: Offers up to 6 hours of continuous playback, extendable to 20 hours with the portable charging case.
- Smart Touch Controls: Intuitive touch controls for managing music, calls, and voice assistant functions without needing to access your device.
Image: Key features of the earbuds, including noise reduction, powerful bass, IPX4 water resistance, and ergonomic design.
Image: A man exercising, highlighting the IPX4 water and sweat resistance of the earbuds.
Package Contents
Upon opening the package, ensure all the following items are present:
- Genérico EB-007 TWS Earbuds (Left and Right)
- Charging Case
- USB Charging Cable
- User Manual
Image: The Genérico EB-007 earbuds securely placed within their charging case.
Setup Instructions
1. Initial Charging
Before first use, fully charge the earbuds and the charging case.
- Place both earbuds into the charging case.
- Connect the USB charging cable to the charging port on the case and to a power source (e.g., USB wall adapter, computer USB port).
- The LED indicator on the case will show charging status. Once fully charged, the indicator will change or turn off.
Image: The charging case connected via USB-C cable, illustrating the charging process and battery capacity.
2. Pairing with Your Device
Follow these steps to pair your earbuds with a Bluetooth-enabled device:
- Ensure the earbuds are charged and inside the charging case.
- Open the charging case lid. The earbuds will automatically enter pairing mode, indicated by a flashing LED light on the earbuds or case.
- On your smartphone or other device, go to Bluetooth settings and turn Bluetooth on.
- Search for available devices. Select "EB-007" (or similar name) from the list.
- Once connected, the LED indicator on the earbuds/case will stop flashing or show a solid light, and your device will confirm the connection.
Image: The earbuds in their charging case, emphasizing Bluetooth 5.4, broad device compatibility, and intelligent touch controls.
Operating Instructions
Power On/Off
- Power On: Open the charging case lid, or take the earbuds out of the case. They will power on automatically.
- Power Off: Place the earbuds back into the charging case and close the lid. They will power off automatically.
Music Playback
- Play/Pause: Tap either earbud once.
- Next Track: Double-tap the right earbud.
- Previous Track: Double-tap the left earbud.
Call Management
- Answer/End Call: Tap either earbud once.
- Reject Call: Press and hold either earbud for 2 seconds.
Voice Assistant
- Activate Voice Assistant: Triple-tap either earbud.
Maintenance
Proper maintenance ensures the longevity and optimal performance of your earbuds:
- Cleaning: Regularly clean the earbuds and charging case with a soft, dry, lint-free cloth. Do not use harsh chemicals or abrasive materials.
- Storage: When not in use, store the earbuds in their charging case to protect them from dust and damage.
- Avoid Extreme Conditions: Do not expose the earbuds to extreme temperatures, humidity, or direct sunlight for extended periods.
- Water Exposure: While IPX4 rated, avoid submerging the earbuds in water. Dry them thoroughly if they get wet from sweat or splashes.
Troubleshooting
If you encounter issues with your earbuds, try the following solutions:
| Problem | Solution |
|---|---|
| Earbuds not pairing | Ensure earbuds are charged. Turn off and on your device's Bluetooth. Place earbuds back in case, close, then reopen to re-enter pairing mode. Try pairing again. |
| No sound from one earbud | Ensure both earbuds are charged. Try resetting the earbuds (refer to specific reset instructions if available in a separate guide). Re-pair with your device. |
| Charging case not charging | Check the USB cable and power adapter. Ensure connections are secure. Try a different cable or power source. |
| Low volume or poor sound quality | Adjust the volume on your connected device. Ensure earbuds are clean and free of debris. Check if the earbuds are properly seated in your ears. |
| Earbuds disconnect frequently | Ensure you are within the 10-meter Bluetooth range. Avoid obstacles between the earbuds and your device. Reduce interference from other wireless devices. |
Specifications
Detailed technical specifications for the Genérico EB-007 Bluetooth 5.4 TWS Earbuds:
| Feature | Detail |
|---|---|
| Brand | Genérico |
| Model Number | EB-007 |
| Color | Black |
| Ear Placement | In-Ear |
| Form Factor | True Wireless |
| Impedance | 32 Ohms |
| Frequency Response | 20 Hz |
| Sensitivity | 115 dB |
| Noise Control | Active Noise Cancellation |
| Connectivity Technology | Wireless |
| Bluetooth Version | 5.4 |
| Bluetooth Range | 10 Meters |
| Battery Life (Earbuds) | 6 Hours |
| Battery Life (with Case) | Up to 20 Hours |
| Charging Case Battery | 320 mAh |
| Water Resistance | IPX4 |
| Compatible Devices | Android, Cell Phones, Notebooks, Tablets, iPhone |
| Included Components | Cable, Wireless Charging Case |
| Country of Origin | China |
| External Certification | ANATEL: 10153-23-15069 |
Warranty and Support
Your Genérico EB-007 Bluetooth 5.4 TWS Earbuds come with a 1-month manufacturer's warranty. For any technical support, warranty claims, or further assistance, please contact the retailer or refer to the contact information provided with your purchase documentation.
