1. Introduction
This manual provides essential information for the safe and efficient use of your AZHAR G26 Electric Mountain Bicycle. Please read this manual thoroughly before assembly and operation to ensure proper function and to prevent injury or damage. The AZHAR G26 is designed for adults and teenagers, featuring a powerful motor, long-range battery, and versatile riding modes suitable for various terrains.
2. Safety Guidelines
Always prioritize safety when operating your electric bicycle. Adhere to local traffic laws and regulations. Wearing a helmet is strongly recommended. Perform a pre-ride inspection before each use, checking brakes, tire pressure, and battery level. Avoid riding in adverse weather conditions or under the influence of substances.
- Always wear a helmet and appropriate safety gear.
- Ensure all components are securely fastened before riding.
- Familiarize yourself with the brake system and practice stopping in a safe area.
- Do not exceed the maximum weight recommendation of 300 pounds.
- Be aware of your surroundings and other road users.
3. Setup and Assembly
Your AZHAR G26 electric bicycle arrives 95% pre-assembled. Minimal installation is required to prepare it for use. Please follow these general steps:
- Unpacking: Carefully remove all components from the packaging.
- Handlebar Installation: Attach the handlebars to the stem and tighten the bolts securely.
- Front Wheel Installation: Install the front wheel, ensuring the quick-release skewer or axle nuts are properly tightened.
- Pedal Installation: Attach the pedals. Note that pedals are typically marked 'L' for left and 'R' for right, and the left pedal has a reverse thread.
- Seat Post Installation: Insert the seat post into the frame and adjust the seat height for comfortable riding, then secure it with the quick-release lever.
- Fender Installation: Attach the front and rear mudguards using the provided hardware.
- Battery Installation: Ensure the battery is correctly seated and locked into the frame.
- Pre-Ride Check: Before your first ride, double-check all bolts, connections, and tire pressure.
Included Components:
- 26" Electric Bike x1
- Tool Kit x1
- User Manual x1
- Charger x1
- Bike lock x1
- Fender x2 (front and rear)
4. Operating Instructions
4.1 Battery Charging
The 48V 10Ah removable lithium battery provides power for your ebike. To charge the battery:
- Ensure the bike is turned off.
- Locate the charging port on the battery. The battery can be charged while installed on the bike or removed.
- Connect the charger to the battery's charging port, then plug the charger into a standard electrical outlet.
- The charging indicator on the charger will show the charging status (typically red for charging, green for fully charged).
- Charging typically takes 4-5 hours for a full charge. Do not overcharge.
- Once fully charged, disconnect the charger from the outlet first, then from the battery.
4.2 Powering On/Off and Display
To power on the bike, press and hold the power button on the LCD display. The display will illuminate, showing real-time cycling data such as speed, mileage, and current mode. To power off, press and hold the power button again.
4.3 Riding Modes
The AZHAR G26 offers three riding modes:
- Pure Electric Mode: Engage the throttle for motor-only propulsion. No pedaling required.
- Pedal Assist Mode (PAS): The motor provides assistance as you pedal. There are 5 levels of pedal assist, adjustable via the display controls. Higher levels provide more motor power.
- Pedal Mode: Ride the bike like a traditional bicycle with no motor assistance.
4.4 Gear Shifting
The bike is equipped with a 7-speed gear system. Use the twist grip shifter on the handlebar to change gears. Shift to lower gears for climbing hills and higher gears for flat terrain or downhill riding to maintain an efficient pedaling cadence.
4.5 Braking System
The AZHAR G26 features dual disc brakes for reliable stopping power. Apply both brake levers simultaneously for optimal and controlled braking. Avoid sudden, hard braking, especially at high speeds, to prevent skidding.
4.6 Headlight Operation
The integrated 400-lumen headlight can be turned on or off via the controls on the handlebar, typically integrated with the display unit. Use the headlight for improved visibility during low-light conditions or at night.
5. Maintenance
Regular maintenance ensures the longevity and safe operation of your electric bicycle.
5.1 General Cleaning
Clean the bike regularly with a damp cloth and mild soap. Avoid using high-pressure washers directly on electrical components, bearings, or the motor.
5.2 Tire Care
- Check tire pressure before each ride. Maintain pressure within the recommended range printed on the tire sidewall.
- Inspect tires for wear, cuts, or embedded objects.
5.3 Brake System
- Regularly check brake pads for wear and replace them when necessary.
- Ensure brake levers operate smoothly and provide adequate stopping power. Adjust brake cable tension if needed.
5.4 Chain and Drivetrain
- Keep the chain clean and lubricated to ensure smooth gear changes and prevent premature wear.
- Inspect gears and derailleur for proper alignment and function.
5.5 Battery Care
- Store the battery in a cool, dry place when not in use.
- If storing for extended periods, charge the battery to approximately 50-70% and recharge every 1-2 months to maintain battery health.
- Avoid fully discharging the battery frequently.
6. Troubleshooting
This section addresses common issues you might encounter with your AZHAR G26 electric bicycle.
| Problem | Possible Cause | Solution |
|---|---|---|
| Bike does not power on | Battery not charged or not properly seated; loose electrical connection. | Charge the battery; ensure battery is fully inserted and locked; check all visible electrical connections. |
| Motor not assisting | PAS level set to 0; battery low; motor connection issue. | Increase PAS level on the display; charge the battery; inspect motor cable connections. |
| Brakes feel weak | Worn brake pads; loose brake cable; air in hydraulic system (if applicable). | Inspect and replace brake pads; adjust brake cable tension; consult a bike mechanic for hydraulic brake issues. |
| Gears not shifting smoothly | Dirty or unlubricated chain; misaligned derailleur; damaged shifter cable. | Clean and lubricate the chain; adjust derailleur; inspect shifter cable for damage. |
| Unusual noises during riding | Loose components; rubbing brakes; worn bearings. | Check all bolts and fasteners; ensure brake pads are not rubbing; inspect wheel and pedal bearings. |
If you encounter issues not listed here or cannot resolve a problem, please contact customer support for assistance.
7. Specifications
Key technical specifications for the AZHAR G26 Electric Mountain Bicycle:
- Motor: 1500W Peak Brushless Motor (750W Continuous)
- Top Speed: Up to 25 MPH
- PAS Range: Up to 65 miles (Pedal Assist Mode)
- Battery: 48V 10Ah Removable Lithium Battery (480 Watt Hours)
- Charging Time: 4-5 hours
- Wheel Size: 26 Inches
- Frame Material: Alloy Steel
- Suspension Type: Front Hydraulic Suspension
- Brake Style: Dual Disc Brakes
- Number of Speeds: 7-Speed Gear Shifting
- Display: Smart LCD Digital Display
- Headlight: 400-lumen integrated headlight
- Maximum Load Capacity: 300 Pounds
- Recommended Age Range: Adults, Teenagers
- Assembly Required: Yes (95% pre-assembled)
8. Warranty and Support
8.1 Warranty Information
The AZHAR G26 Electric Mountain Bicycle comes with a 3-year limited warranty from the date of purchase. This warranty covers manufacturing defects in materials and workmanship. It does not cover damage resulting from misuse, accidents, unauthorized modifications, or normal wear and tear. Please retain your proof of purchase for warranty claims.
Additionally, we offer a 30-day easy return policy for eligible products.
8.2 Customer Support
For any questions, technical assistance, or warranty claims, please contact AZHAR customer support through the retailer where you purchased the product. Provide your model number (G26) and purchase details to expedite service.
