PeakPursuit 59-inch Fireplace TV Stand with 24-inch Electric Fireplace Insert User Manual

Introduction

Thank you for purchasing the PeakPursuit 59-inch Fireplace TV Stand. This entertainment center combines a stylish TV stand with a functional 24-inch electric fireplace insert, offering both aesthetic appeal and practical heating. This manual provides essential information for safe assembly, operation, and maintenance of your new product.

Important Safety Information

• Read all instructions before using this appliance.
• Do not operate any fireplace with a damaged cord or plug, or if the heater has malfunctioned or been dropped or damaged in any manner.
• Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9 m) from the front of the heater and keep them away from the sides and rear.
• Always unplug the fireplace when not in use.
• Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage the heater.
• Use this fireplace only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, or injury to persons.

Product Dimensions

The PeakPursuit Fireplace TV Stand measures 63.39 inches in depth, 9.45 inches in width, and 22.64 inches in height. The design accommodates TVs up to 59 inches. The electric fireplace insert is 24 inches wide.

Figure 1: Product Dimensions. Note that this item may be delivered in two packages on different days.

Key Features

• Various Flame and LED Colors: The electric fireplace features multiple flame and LED light colors with adjustable brightness, creating a customizable ambiance. A remote control is included for convenient adjustments. The fireplace operates at 1400 watts, providing 5000 BTU per hour and heating an area up to 400 square feet.


Figure 2: Customizable Flame and LED Colors.

• Versatile Storage: This TV stand includes three open shelves and two spacious cabinets, ideal for media gadgets, decorative items, books, or CDs. The design promotes a neat and organized media console.


Figure 3: Versatile Storage Options.

• Durable Construction: Constructed from wood with a glass finish, this entertainment center is designed for durability. It features gold alloy handles, a unique base, and an anti-tip device for enhanced stability and safety.


Figure 4: Premium Materials and Construction.

• Elegant Design: The TV stand features an elegant and stylish design, with a high-gloss top and front paired with a matte white body, offering a modern and luxurious feel that complements various living room decors.
• Powerful Heating: The electric fireplace provides 5000 BTU output, capable of heating up to 400 sq. ft. It offers 750W / 1500W settings for flexible comfort.


Figure 5: Powerful Heating Feature.

• Safety Certified: The fireplace is ETL certified and includes built-in overheat protection for safe daily use.


Figure 6: Safety Certifications.

Setup and Assembly

Your PeakPursuit Fireplace TV Stand comes with detailed installation instructions. It is recommended that two adults assemble the unit to ensure proper and safe construction. All necessary hardware is included. Please follow the step-by-step guide provided in the packaging for a smooth assembly process.

Ensure all parts are present and undamaged before beginning assembly. If any parts are missing or damaged, please contact customer support immediately.

Operating Instructions

Electric Fireplace Operation

The electric fireplace insert can be operated using the control panel on the unit or the included remote control. Ensure the unit is properly plugged into a grounded outlet.

1. Power On/Off: Press the power button to turn the fireplace on or off.
2. Flame Color Adjustment: Use the flame color button to cycle through various flame and LED light colors.
3. Brightness Control: Adjust the flame brightness using the dedicated button.
4. Heat Settings: Select between 750W or 1500W heating modes. The heater can be used independently of the flame effect.
5. Timer Function: Set the operational timer for 1 to 8 hours.
6. Temperature Control: Adjust the desired temperature setting.

For detailed instructions on each function, refer to the specific fireplace insert manual included with your product.

Remote Control

The remote control allows for convenient operation of all fireplace functions from a distance. Ensure the remote has working batteries and is pointed towards the fireplace unit.

Figure 7: Fireplace Control Panel and Remote.

Maintenance

Regular maintenance ensures the longevity and optimal performance of your TV stand and electric fireplace.

• Cleaning the TV Stand: Wipe surfaces with a soft, damp cloth. Avoid harsh chemicals or abrasive cleaners that may damage the finish.
• Cleaning the Fireplace Insert: Ensure the fireplace is turned off and unplugged before cleaning. Use a soft, damp cloth to clean the glass and exterior surfaces. Do not spray water directly onto the unit.
• Ventilation: Periodically check that the air intake and exhaust vents of the fireplace are clear of dust and obstructions to ensure proper airflow.

Troubleshooting

If you encounter any issues with your PeakPursuit Fireplace TV Stand, refer to the following common troubleshooting tips:

• Fireplace Not Turning On: Check if the power cord is securely plugged into a working electrical outlet. Ensure the main power switch on the unit is in the 'ON' position.
• No Heat Output: Verify that the heat function is activated and the temperature setting is higher than the ambient room temperature. Check for any obstructions in the air vents.
• Remote Control Not Working: Replace the batteries in the remote control. Ensure there are no obstructions between the remote and the fireplace sensor.
• Unusual Noises: If you hear unusual noises, turn off the unit immediately and unplug it. Contact customer support for assistance.

For more complex issues, consult the detailed troubleshooting section in the fireplace insert manual or contact PeakPursuit customer support.

Specifications

Warranty and Support

For warranty information or technical support, please refer to the documentation included with your product or contact PeakPursuit customer service. Keep your purchase receipt for warranty claims.
