Important Safety Instructions
Please read and understand all instructions before using this heater. Failure to follow these instructions may result in electric shock, fire, or serious injury.
- Always keep combustible materials (furniture, bedding, paper, clothes, curtains) at least 3 feet (0.9 m) from the front, sides, and rear of the heater.
- Never place towels or any objects on top of the heater.
- Do not use the heater in bathrooms, laundry areas, or similar indoor locations where water is present.
- Do not operate any heater with a damaged cord or plug, or after the heater malfunctions or has been dropped or damaged in any manner.
- Always unplug the heater when not in use.
- Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage the heater.
- To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on soft surfaces, like a bed, where openings may become blocked.
- This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
- Extreme caution is necessary when any heater is used by or near children or invalids and whenever the heater is left operating and unattended.
- Use this heater only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, or injury to persons.
Product Overview
The Aidoly 24-inch 1500W Oscillating Space Heater is designed for rapid and even heating in both indoor and outdoor environments. It features smart temperature control, multi-layer safety protections, ambient light modes, and quiet operation.
Image: The Aidoly 24-inch 1500W Oscillating Space Heater in a cozy living room, demonstrating its compact design and ambient lighting.
Package Contents
- Aidoly 24-inch 1500W Oscillating Space Heater
- Remote Control (with battery)
- User Manual
Setup
Follow these steps to assemble and prepare your space heater for first use.
- Unpack the Heater: Carefully remove all packaging materials from the heater and its components. Ensure all parts listed in the package contents are present.
Image: A person carefully removing the space heater from its packaging.
- Assemble the Base: The heater base comes in two halves. Snap them together securely.
Video: Demonstrates how to assemble the two halves of the heater base. This video is from a seller-created review and shows the assembly process clearly.
- Attach Heater to Base: Unscrew the knob at the bottom of the heater. Feed the power cord through the slot in the assembled base. Align the heater with the base and screw the knob back in from underneath to secure it.
Image: The base being attached to the main body of the heater, with the power cord routed through the base.
- Remote Control Setup: Remove the battery protector tab from the remote control before first use.
Video: Shows the remote control and how to remove the battery protector tab. This video is from a seller-created review and demonstrates remote setup.
- Placement: Place the heater on a firm, level surface. Ensure it is at least 3 feet (0.9 m) away from any walls, furniture, or other combustible materials.
- Power Connection: Plug the heater directly into a 120V AC, 60Hz electrical outlet. Do not use extension cords or power strips.
Operating Instructions
Your Aidoly space heater can be operated using the touch control panel on top of the unit or the included remote control.
Control Panel & Remote Overview
Image: Close-up of the heater's top control panel, showing various function buttons.
- Power Button: Turns the heater ON/OFF.
- Mode Button: Cycles through heating modes (High, Low, Fan Only, ECO).
- Temperature Adjustment (+/-): Increases or decreases the target temperature (60°F to 99°F).
- Oscillation Button: Activates or deactivates the 60° oscillation function.
- Timer Button: Sets the auto-off timer (up to 12 hours).
- Flame Effect Button: Changes the color of the ambient flame light. Press and hold for 3-5 seconds to cycle colors automatically.
- Child Lock Button: Press and hold for 3-5 seconds to activate/deactivate the child lock, preventing accidental operation.
Initial Power On
- Press the Power button on the control panel or remote. The heater will default to 72°F.
- The heater will begin emitting warm air within 3 seconds.
Image: The heater displaying "3s Fast heating" to indicate quick warmth.
Adjusting Temperature and Mode
- Use the '+' or '-' buttons to set your desired temperature between 60°F and 99°F.
- Press the Mode button to switch between 1500W High Heating, 900W Low Heating, Fan Only (Cooling), and ECO mode for energy efficiency.
Image: The heater's display showing temperature settings and icons for different modes (High, Low, Cooling, ECO).
Oscillation Function
- Press the Oscillation button to activate the 60° wide-angle oscillation, distributing heat evenly across the room. Press again to stop.
Image: The heater shown oscillating, with arrows indicating the 60° heat distribution.
Ambient Light Modes
- Press the Flame Effect button to cycle through 3 adjustable flame colors. Press and hold the button for 3-5 seconds to enable automatic color cycling.
Image: The heater displaying its ambient flame effect in a bedroom, with icons showing different light modes.
Timer Function
- Press the Timer button to set the heater to automatically turn off after a set number of hours (1-12 hours).
Child Lock
- To prevent accidental changes to settings, press and hold the Child Lock button for 3-5 seconds to activate. Repeat to deactivate.
Maintenance
Regular maintenance ensures optimal performance and longevity of your heater.
- Cleaning: Always unplug the heater and allow it to cool completely before cleaning. Use a soft, damp cloth to wipe the exterior surfaces. Do not use abrasive cleaners or solvents.
- Storage: When not in use, store the heater in a cool, dry place. It is recommended to store it in its original packaging to protect it from dust and damage.
- No User-Serviceable Parts: Do not attempt to open or repair the heater yourself. Refer to qualified service personnel for any repairs.
Troubleshooting
If your heater is not operating correctly, refer to the following common issues and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Heater does not turn on. | No power, power cord not fully inserted, or tip-over switch activated. | Check power outlet, ensure plug is fully inserted. Ensure heater is on a flat, stable surface. |
| Heater stops operating unexpectedly. | Overheat protection activated or tip-over protection activated. | Unplug the heater, let it cool down for 30 minutes. Check for obstructions. Ensure heater is upright on a stable surface. |
| Heat output is low. | Heater is in Low Heat or ECO mode, or thermostat set too low. | Switch to High Heat mode. Increase the target temperature. |
| Remote control not working. | Battery tab not removed, battery drained, or remote out of range. | Ensure battery tab is removed. Replace battery if necessary. Use remote within close proximity to the heater. |
Specifications
- Brand: Aidoly
- Model Number: AIDO-KB-NFJ24-BK
- Power: 1500W
- Voltage: 120V AC, 60Hz
- Dimensions: 6.69"D x 8.46"W x 24.21"H
- Weight: 4.63 pounds
- Temperature Range: 60°F - 99°F
- Oscillation: 60°
- Timer: Up to 12 hours
- Safety Features: Tip-Over Protection, Overheat Shut-off, Child Lock, Flame-Retardant Materials
Warranty and Support
For warranty information or technical support, please contact Aidoly customer service. Refer to the product packaging or the official Aidoly website for contact details.
