SONGMICS LGS733KD01

SONGMICS BELLAH Collection 7-Drawer Dresser with LED Lighting and Power Strip

Model: LGS733KD01 | Brand: SONGMICS

1. Introduction

Thank you for choosing the SONGMICS BELLAH Collection 7-Drawer Dresser. This manual provides essential information for the safe assembly, operation, and maintenance of your new furniture. Please read these instructions thoroughly before beginning assembly and retain them for future reference.

2. Safety Instructions

  • Anti-Tipping Kit: Always install the included anti-tipping kit to prevent serious injury from furniture tip-over. Securely fasten the dresser to a wall according to the instructions.
  • Weight Limits: Do not exceed the specified weight limits for the top surface, open shelf, or individual drawers. Refer to the specifications section for details.
  • Electrical Safety: The integrated power strip contains electrical components. Ensure the power cord is not pinched or damaged. Do not expose the power strip to water or excessive moisture. Unplug the unit before cleaning or if any electrical issue occurs.
  • Assembly: Assemble the unit on a soft, clean surface to prevent scratches. Ensure all parts are correctly installed and fasteners are tightened before use.
  • Children: Keep small parts and packaging materials away from children during assembly. Do not allow children to climb on or play with the dresser.

3. Package Contents

Please verify that all components listed below are present before starting assembly. If any parts are missing or damaged, contact customer support.

  • Metal Frame Components
  • Engineered Wood Top Panel and Shelf
  • Fabric Drawers (4 small, 3 large)
  • LED Light Strip with Controller
  • Integrated Power Strip (2 AC outlets, 1 USB-A, 1 USB-C)
  • Hardware Pack (screws, bolts, anti-tipping kit)
  • Assembly Tool (e.g., Allen key)
  • Instruction Manual

4. Assembly Instructions

Follow the numbered steps in the provided assembly diagram. All parts are labeled for easy identification.

  1. Prepare the Area: Clear a spacious area and lay down a soft cloth or carpet to protect the furniture and floor.
  2. Assemble the Frame: Connect the metal frame components using the provided screws and the included tool. Do not overtighten initially.
  3. Attach Panels: Secure the engineered wood top panel and the internal shelf to the metal frame.
  4. Install Power Strip: Integrate the power strip into its designated slot on the top panel.
  5. Install LED Strip: Adhere the LED light strip to the underside of the top panel or shelf as indicated in the diagram. Connect it to the power source.
  6. Assemble Drawers: Unfold the fabric drawers and insert the reinforced MDF bottom panels. Attach handles if separate.
  7. Insert Drawers: Place the assembled drawers into their respective compartments within the frame.
  8. Final Tightening: Once all components are in place, carefully tighten all screws to ensure stability.
  9. Install Anti-Tipping Kit: Securely attach the anti-tipping device to the back of the dresser and to a wall stud using appropriate hardware. This step is crucial for safety.
Diagram showing the dimensions of the SONGMICS BELLAH 7-drawer dresser and individual drawer weight capacities.
Figure 1: Product Dimensions and Weight Capacities. Top surface: 20 kg (44 lbs), Open shelf: 30 kg (66 lbs), Small drawer: 5 kg (11 lbs), Large drawer: 8 kg (17.6 lbs).
Image showing the dresser's reinforced steel frame and anti-tipping device for enhanced stability and safety.
Figure 2: Stability Features. The dresser features a reinforced steel frame and an anti-tipping device for secure installation.

5. Operating Instructions

5.1 LED Lighting

The integrated LED lighting can be controlled via a manual switch or a dedicated smartphone application.

  • Manual Control: Use the inline switch on the LED strip cable to turn the lights on/off.
  • App Control: Download the compatible app (refer to the LED controller instructions for app name). Connect your smartphone to the LED lighting via Bluetooth. The app allows you to:
    • Choose from over 60,000 colors.
    • Adjust brightness levels.
    • Select dynamic lighting modes.
    • Synchronize lights with music or microphone input.
    • Set timers for automatic on/off schedules.
Image illustrating the LED lighting features of the dresser, including app control, color options, music sync, and timer function.
Figure 3: LED Lighting Control. Features include manual control and app-based customization for color, brightness, music sync, and timers.
Screenshots of the mobile application interface showing lighting control functionalities with starry night themes and color customization options.
Figure 4: App Interface for LED Customization. The app provides extensive options for personalizing the lighting effects.

5.2 Power Strip

The dresser includes an integrated power strip for convenient charging and powering of devices.

  • AC Outlets: Two standard AC outlets (250V/16A) are available for plugging in electronic devices.
  • USB-A Port: One USB-A port (5V/2A) is provided for charging compatible devices.
  • USB-C Port: One USB-C port (5V/2A) is provided for charging compatible devices.

Ensure the dresser's main power cord is plugged into a functional wall outlet for the power strip to operate.

Close-up of the integrated power strip on the dresser, showing two AC outlets, one USB-A port, and one USB-C port.
Figure 5: Integrated Power Strip. Conveniently charge and power devices with 2 AC outlets, 1 USB-A, and 1 USB-C port.

5.3 Drawers and Storage

The dresser features 4 small and 3 large fabric drawers, along with an open shelf and a top surface for storage and display.

  • Fabric Drawers: Designed for organizing clothing, accessories, and other household items. The drawers are reinforced with MDF to maintain their shape.
  • Open Shelf: Ideal for books, decorative items, or frequently accessed essentials.
  • Top Surface: Suitable for lamps, plants, or a television up to 50 inches (ensure weight limits are respected).
Image demonstrating the storage capacity of the 7-drawer dresser, showing various clothing items organized within the drawers.
Figure 6: Ample Storage Space. The dresser offers generous capacity for various items, including 10+ T-shirts, 7+ pants, 27+ ties, 9+ shirts, 40+ socks, and 3+ scarves.
Detailed view of a dresser drawer, highlighting its spacious design, easy access, and quality textile material.
Figure 7: Spacious and Quality Drawers. The drawers are designed for easy storage and feature quality textile construction.
Diagram illustrating the robust construction of the dresser drawers with MDF reinforcement, non-woven fabric, and textile.
Figure 8: Reinforced Drawers. Drawers are reinforced with MDF to maintain their shape and durability.

6. Maintenance

  • Cleaning the Frame and Panels: Wipe the metal frame and engineered wood panels with a soft, damp cloth. Avoid harsh chemicals or abrasive cleaners.
  • Cleaning Fabric Drawers: Spot clean fabric drawers with a mild detergent and a damp cloth. Do not machine wash or tumble dry. Allow to air dry completely.
  • Dusting: Regularly dust all surfaces with a dry, soft cloth.
  • Inspection: Periodically check all screws and fasteners to ensure they remain tight. Retighten if necessary.
  • Avoid Direct Sunlight: Prolonged exposure to direct sunlight may cause fading or damage to the materials.

7. Troubleshooting

ProblemPossible CauseSolution
LED lights not turning on.Power cord unplugged; LED strip not connected; faulty LED strip.Ensure power cord is securely plugged in. Check all LED connections. If issues persist, contact support.
Power strip not providing power.Dresser power cord unplugged; overloaded circuit; faulty power strip.Verify the dresser's main power cord is plugged in. Reduce the number of devices connected. Contact support if problem continues.
Drawers are difficult to open/close or stick.Overloaded drawer; incorrect assembly; foreign object.Reduce contents in the drawer. Check if the drawer is assembled correctly. Inspect for any obstructions.
Dresser feels unstable.Loose fasteners; anti-tipping kit not installed or improperly installed; uneven floor.Tighten all screws. Ensure the anti-tipping kit is correctly installed and secured to a wall stud. Adjust the leveling feet on the bottom of the dresser.

8. Specifications

FeatureDetail
BrandSONGMICS
Model NumberLGS733KD01
ColorRustic Brown + Ink Black
Number of Drawers7 (4 small, 3 large)
MaterialMetal frame, Engineered wood panels, Fabric drawers with MDF reinforcement
Item Weight13.5 Kilograms (29.7 lbs)
Power Strip2 AC Outlets (250V/16A), 1 USB-A Port (5V/2A), 1 USB-C Port (5V/2A)
LED LightingApp-controlled, adjustable color and brightness, music sync, timer functions
UPC194343517780
GTIN194343517780
Country of OriginChina
Close-up of the dresser's surface, showcasing the combination of steel and engineered wood for durability.
Figure 9: Material Combination. The dresser is constructed from durable steel and engineered wood.

9. Warranty and Support

This product comes with a standard manufacturer's warranty. For specific warranty details, please refer to the documentation included with your purchase or contact SONGMICS customer support directly. If you encounter any issues or have questions regarding assembly, operation, or parts, please reach out to the manufacturer's support team for assistance.
