DEVAISE 71-inch Metal Storage Cabinet Instruction Manual

Introduction

This manual provides comprehensive instructions for the assembly, operation, maintenance, and safety of your DEVAISE 71-inch Metal Storage Cabinet. Please read all instructions carefully before beginning assembly and retain this manual for future reference.

Image: The DEVAISE 71-inch Metal Storage Cabinet in its closed state, showcasing its white finish and dual-door design with two lower drawers.

Important Safety Information

• Anti-Tip Kit: Ensure the cabinet is securely anchored to the wall using the provided anti-tip kit to prevent accidental tipping. This is especially important when storing heavier items or in households with children or pets.
• Load Limits: Adhere to the specified load limits for shelves (up to 150 lbs per shelf) and drawers (up to 55 lbs per drawer) to avoid overloading, which can lead to structural damage or injury.
• Assembly: Follow all assembly steps precisely. Incorrect assembly can compromise the stability and safety of the cabinet.
• Placement: Place the cabinet on a level, stable surface. Avoid placing it in areas with high humidity or direct sunlight to prevent material degradation.
• Children: Do not allow children to climb on or play with the cabinet, especially when drawers or doors are open.

Product Specifications

Image: Visual representation of the cabinet's dimensions (71" H, 32" W, 16" D) and weight capacities for shelves (150 lbs) and drawers (50 lbs).

Parts List

Before assembly, verify that all components are present and undamaged. Refer to the assembly video for visual identification of parts.

Cabinet Panels

• A, B: Base Panels
• C, D: Side Panels
• E, G, Q: Crossbars (Top, Middle)
• F, H: Shelves (Middle, Top)
• I: Adjustable Shelves (2 pieces)
• J, K: Doors

Drawer Components

• R, Z, X, Y: Drawer Panels (for two drawers)
• P: Hanging File Bars (for two drawers)

Hardware & Accessories

• N: Screws (various sizes for panels)
• V: Screws (for support brackets and feet)
• W: Adjustable Feet (4 pieces)
• a: Support Brackets
• GG, HH, FF: Drawer Slides (various parts for left and right)
• O: Shelf Pins (8 pieces)
• S, T: Screws (for shelf pins)
• U: Door Magnets
• L, M: Anti-Tip Kit (screws and wall anchors)
• Gloves and Screwdriver (included for assembly)

Setup and Assembly

Follow these steps to assemble your DEVAISE Metal Storage Cabinet. It is recommended to have a second person assist with assembly for stability and ease of handling larger panels.

Assembly Video Guide

Step-by-Step Assembly Instructions

1. Unpack and Identify Parts: Carefully unpack all components and lay them out. Refer to the parts list and the assembly video (0:01-0:05) to identify each piece.
2. Assemble Base Panels: Connect base panels A and B using screws N. (Video: 0:05-0:17)
3. Attach Side Panels: Attach side panel C to the assembled base panels A and B. Secure with screws N. Repeat for side panel D. (Video: 0:17-0:39)
4. Install Crossbars: Attach crossbar E to the top front section of the cabinet. (Video: 0:39-0:46)
5. Attach Support Brackets: Secure support brackets 'a' to the cabinet frame using screws V. (Video: 0:46-1:01)
6. Install Adjustable Feet: Attach the adjustable feet W to the bottom corners of the cabinet using screws V. (Video: 1:01-1:16)
7. Install Top Crossbar: Attach crossbar G to the top rear section of the cabinet. (Video: 1:16-1:27)
8. Attach Top Panel: Place and secure the top panel H using screws N. (Video: 1:27-1:47)
9. Install Middle Crossbar: Attach middle crossbar Q and secure it with the spring pin mechanism. (Video: 1:47-2:17)
10. Attach Middle Panel: Place and secure the middle panel F using screws N. (Video: 2:17-2:35)
11. Secure Back Panels: Ensure all back panels are properly aligned and secured with screws N. (Video: 2:35-2:41)
12. Assemble Drawers: Assemble the drawer panels R, Z, X, Y to form the drawer boxes. (Video: 2:41-3:11)
13. Attach Drawer Slides to Drawers: Attach the FF drawer slide components to the sides of each assembled drawer. (Video: 3:11-3:45)
14. Attach Drawer Slides to Cabinet: Attach the GG and HH drawer slide components to the interior sides of the cabinet where the drawers will be installed. (Video: 3:45-4:20)
15. Insert Drawers: Carefully slide the assembled drawers into the cabinet, aligning them with the installed drawer slides. (Video: 4:20-4:42)
16. Install Adjustable Shelves: Insert shelf pins O into the desired height holes on the cabinet sides. Place the adjustable shelves I onto the pins. (Video: 4:42-4:58)
17. Attach Doors: Mount doors J and K to the cabinet hinges. (Video: 4:58-5:29)
18. Install Door Magnets: Attach the door magnets U to ensure the doors close securely. (Video: 5:29-5:56)
19. Install Anti-Tip Kit: Secure the anti-tip kit (L and M) to the top rear of the cabinet and to a wall stud to prevent tipping. (Video: 5:56-6:15)

Operating Instructions

Adjustable Shelves

The upper cabinet section features two adjustable shelves. To adjust their height:

1. Empty the shelf of all contents.
2. Remove the shelf by lifting it off its support pins.
3. Relocate the shelf pins to the desired height holes on the cabinet's side panels. Ensure pins are level on both sides.
4. Carefully place the shelf back onto the pins.

Image: The cabinet interior showing adjustable shelves and their height adjustment mechanism.

Locking Mechanism

The cabinet features a dual locking system for both the upper doors and the lower drawers.

• Upper Doors: Insert the key into the lock on the right door and turn to secure both doors. The left door is secured by a latch that engages with the right door when locked.
• Lower Drawers: Each drawer has an independent lock. Insert the key and turn to lock or unlock. The interlocking mechanism allows simultaneous locking of both drawers for enhanced security.

Drawer Operation

The two lateral file drawers are designed for smooth operation and can accommodate A4 and Letter-sized files using the adjustable hanging bars.

• To open, pull the drawer handle. To close, push the drawer until it is fully seated.
• The adjustable hanging bars can be repositioned within the drawer to fit different file sizes.

Image: The cabinet's drawers configured for A4 and Letter-sized file storage.

Maintenance

Regular maintenance will help prolong the life and appearance of your DEVAISE Metal Storage Cabinet.

• Cleaning: Wipe surfaces with a soft, damp cloth. For stubborn marks, use a mild soap solution and dry immediately with a clean cloth. Avoid abrasive cleaners or harsh chemicals, as these can damage the powder-coated finish.
• Moving the Cabinet: If you need to move the cabinet, empty all contents first. If possible, lift the cabinet rather than dragging it to prevent damage to the adjustable feet and floor.
• Hardware Check: Periodically check all screws and fasteners to ensure they are tight. Retighten as necessary.
• Drawer Slides: If drawers become stiff, a small amount of silicone-based lubricant can be applied to the drawer slides.

Image: Features of the cabinet's construction, including durable steel, scratch resistance, waterproof, and rustproof properties.

Troubleshooting

Warranty and Support

For warranty information or technical support, please refer to the documentation included with your purchase or contact DEVAISE customer service directly. Keep your purchase receipt and product model number (AWJG016) handy when contacting support.
