Introduction
This manual provides detailed instructions for the safe and effective use of your Beeman Protect BP50 .50 Caliber CO2 Powered Air Pistol. Designed for non-lethal home and personal defense, this semi-automatic projectile launcher offers reliable performance. Please read this manual thoroughly before operating the device to ensure proper handling and to understand all safety precautions.
Keywords: Beeman Protect BP50, .50 Caliber, Projectile Launcher, CO2 Air Pistol, Non-Lethal, Home Defense, Personal Defense, Pepper Balls, Steel Balls, 026785060534
What's in the Box
- Beeman Protect BP50 Air Pistol
- 8 Pepper Balls
- 8 Steel Balls
- Installed 8-Round Magazine
- Instruction Manual
Setup
1. Installing the CO2 Cartridge
The Beeman Protect BP50 utilizes a 12-gram CO2 cylinder for power, featuring CO2 Pierce Technology for quick activation. Ensure the device is unloaded and the safety is engaged before proceeding.
- Locate the CO2 cartridge compartment at the base of the grip.
- Unscrew the cap at the bottom of the grip.
- Insert a 12-gram CO2 cylinder into the compartment with the narrow end facing upwards.
- Screw the cap back on firmly. The CO2 Pierce Technology allows for tool-free quick activation. To activate the CO2, firmly strike the bottom of the grip against a hard surface or press the cap in until you hear the CO2 cartridge being pierced. This prepares the launcher for firing.
Image: Beeman Protect BP50 showing the CO2 cartridge installation point at the base of the grip.
2. Loading Projectiles
The BP50 comes with an installed 8-round magazine. It can fire .50 caliber pepper balls or steel balls.
- Press the magazine release button, typically located near the trigger guard, to remove the magazine from the grip.
- Carefully load up to 8 .50 caliber projectiles (pepper balls or steel balls) into the magazine. Ensure they are seated correctly to prevent feeding issues.
- Insert the loaded magazine back into the grip until it clicks securely into place.
Video: Demonstrates the loading process of the Streetwise The Heat Pepper Launcher 2, which shares similar loading mechanisms with the Beeman Protect BP50. This video illustrates how to load projectiles into the magazine and insert the magazine into the device.
Operating Instructions
The Beeman Protect BP50 is a semi-automatic launcher with an automatic trigger safety.
- Safety First: Always ensure the safety mechanism is engaged until you are ready to fire. The BP50 features an automatic trigger safety, which means the trigger must be fully depressed to disengage the safety and fire.
- Aiming: Point the launcher at your intended target.
- Firing: With the CO2 activated and the magazine loaded, firmly pull the trigger to fire a projectile. The semi-automatic action will prepare the next round for firing.
- Reloading: After 8 shots, the magazine will be empty. Follow the loading instructions to reload the magazine.
The effective range of the BP50 is up to 150 feet, with a velocity of 385 feet per second (fps).
Maintenance
Regular maintenance ensures the longevity and reliable performance of your Beeman Protect BP50.
- Cleaning: Periodically clean the exterior of the launcher with a soft, damp cloth. Avoid using harsh chemicals.
- Barrel Cleaning: If residue builds up in the barrel, use a cleaning rod and appropriate cleaning patches. Ensure no foreign objects obstruct the barrel.
- Storage: Store the launcher in a cool, dry place, unloaded and with the CO2 cartridge removed. Keep it out of reach of children and unauthorized users.
- CO2 Cartridge Removal: Always remove spent or unused CO2 cartridges before storing the device for extended periods to prevent seal damage.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Launcher does not fire. | CO2 cartridge not pierced or empty. Safety engaged. Magazine empty or improperly seated. | Ensure CO2 cartridge is new and properly pierced. Check if the magazine is loaded and securely inserted. Confirm the trigger is fully depressed to disengage the automatic safety. |
| Projectiles not feeding correctly. | Improperly loaded magazine. Damaged projectiles. | Remove and re-load the magazine, ensuring projectiles are seated correctly. Inspect projectiles for damage and replace if necessary. |
| Loss of power/velocity. | Low or empty CO2 cartridge. | Replace the CO2 cartridge. |
Specifications
- Brand: Beeman
- Model: BP50
- Caliber: .50 Caliber
- Power Type: CO2 (12-gram cylinder)
- Velocity: 385 fps
- Length: 7.32 inches
- Magazine Capacity: 8 Rounds
- Shot Capacity: 20+ shots per CO2 cylinder
- Effective Range: Up to 150 feet
- Safety: Automatic trigger safety
- Frame Material: Plastic
- Barrel Material: Metal
- Item Weight: 1.7 Pounds
- Color: Black
- UPC: 026785060534
Warranty & Support
The Beeman Protect BP50 comes with a 1-year warranty from the date of purchase. For warranty claims, technical support, or any inquiries regarding your product, please contact Beeman customer service. Keep your proof of purchase for warranty validation.
For further assistance, please refer to the official Beeman website or contact their authorized service centers.
