1. Introduction and Overview
This manual provides essential instructions for the safe and efficient operation of your Toshiba Stone Kiln Dome Superheated Steam Oven Range, model ER-D4000B. This compact premium model features advanced cooking technologies designed to simplify your daily meal preparation.
Figure 1.1: Toshiba ER-D4000B Oven Range with key specifications.
Key features include a High-angle infrared sensor for precise temperature detection, specialized cooking modes like 'Stone Kiln Omakase Baking' and 'Easy Bowl Pasta/Curry Plus', and 'Superheated Steam Cooking' for healthier meals. The oven also boasts a space-saving design and a Smart Damper for quiet door closure.
Video 1.1: Product Introduction Video. This video provides a general overview of the Toshiba Stone Kiln Dome Superheated Steam Oven Range's features and capabilities.
2. Setup
2.1 Unpacking
Carefully remove the oven range from its packaging. Retain all packaging materials for future transport or service needs. Inspect the appliance for any damage. Do not operate if damaged.
2.2 Placement
Place the oven range on a stable, level surface. Due to its slim depth of 39.9 cm (excluding the handle), it can be installed flush against walls on the left, right, and back, optimizing kitchen space. Ensure adequate ventilation around the appliance as specified in the full instruction manual.
2.3 Power Connection
Connect the power cord to a grounded electrical outlet. Ensure the voltage matches the specifications listed on the appliance's rating label.
3. Operating Instructions
3.1 Basic Microwave Heating
The oven range offers a maximum microwave output of 1000W for short-duration heating (up to 3 minutes). For continuous operation, the power automatically switches to 600W. Use the control panel to select the desired power level and heating time.
Figure 3.1: Speed heating mode, demonstrating time reduction with 'Rush Mode'.
3.2 Sensor Heating
The integrated High-angle infrared sensor accurately detects the surface temperature of food, allowing for precise and thorough heating. This feature helps prevent uneven heating and ensures optimal results.
Figure 3.2: Sensor heating in action, ensuring food is heated thoroughly.
3.3 Automatic Menus
Access 210 pre-programmed automatic menus for a wide variety of dishes. Simply select the desired menu, and the oven will automatically adjust cooking time and temperature for optimal results. This includes 'Speed Menus' for quick preparation.
Figure 3.3: Examples of dishes prepared using the automatic menu function.
3.4 Superheated Steam Cooking
Utilize the superheated steam cooking function to reduce oil and salt content in your meals, promoting healthier eating without compromising flavor.
3.5 Oven Functions
The 'Stone Kiln Omakase Baking' feature allows you to simply arrange your favorite ingredients, and the oven will automatically bake them to perfection, adjusting heat based on quantity and ingredient type. The 'Easy Bowl Pasta/Curry Plus' function simplifies cooking by allowing all ingredients to be placed in a bowl and cooked with a single course selection.
Figure 3.4: Stone Kiln Omakase Baking for versatile and automatic cooking.
Figure 3.5: Easy Bowl Pasta/Curry Plus for simplified meal preparation.
You can also bake dishes directly from frozen, eliminating the need for defrosting on busy days. This ensures delicious results with minimal preparation time.
Figure 3.6: Baking from frozen, demonstrating convenience for busy schedules.
3.6 Convenient Heating Functions
The oven offers various heating options, including 'Fluffy Bread' mode to make store-bought bread taste freshly baked, custom temperature heating from -10°C to 90°C for tasks like softening butter or preparing raw chocolate, 'Crispy Heating' to restore the texture of freshly made fried foods, and 'Steam Heating' for moist and warm results without plastic wrap.
Figure 3.7: Overview of convenient heating functions.
4. Maintenance
Regular cleaning is essential to maintain the performance and longevity of your oven range. Always ensure the appliance is unplugged and cooled before cleaning.
4.1 Interior Cleaning
The oven interior features a special coating designed for easy cleaning. Wipe down the interior surfaces with a soft, damp cloth after each use to remove food splatters and grease. For stubborn stains, use a mild detergent specifically designed for oven interiors, following the product instructions.
Video 4.1: Torechau Coat Demonstration. This video demonstrates the easy-to-clean properties of the oven's interior coating, simplifying maintenance.
4.2 Exterior Cleaning
Wipe the exterior surfaces with a soft, damp cloth. Avoid abrasive cleaners or scouring pads, as they can damage the finish.
4.3 Accessories
Clean the baking tray, wire rack, and other accessories with warm, soapy water. Rinse thoroughly and dry completely before reinserting them into the oven.
5. Troubleshooting
If you encounter any issues with your Toshiba ER-D4000B oven range, please refer to the comprehensive troubleshooting section in the full instruction manual. Common issues and their solutions are typically covered there. If the problem persists, contact customer support.
6. Specifications
| Feature | Specification |
|---|---|
| Model Number | ER-D4000B |
| External Dimensions (W x D x H) | 493 mm x 399 mm x 357 mm (excluding handle) |
| Weight (Main Unit Only) | Approx. 21 kg |
| Total Oven Capacity | 26 Liters |
| Maximum Microwave Output | 1000W (short-time, max 3 minutes) |
| Continuous Microwave Output | 600W |
| Automatic Menus | 210 |
| Color | Black |
7. Warranty and Support
7.1 Warranty Information
The Toshiba ER-D4000B oven range comes with a 1-year manufacturer's warranty from the date of purchase. Please retain a copy of your purchase receipt or donation certificate as proof of purchase for warranty claims. The warranty period remains unchanged even if the product is unopened or unused. Repairs for malfunctions caused by improper use or disasters will incur charges for repair costs and shipping.
7.2 Customer Support
For technical assistance, inquiries, or service requests, please contact Toshiba Customer Support:
- Free Dial: 0120-03-1048
- Navi Dial: 0570-07-1048 (Call charges apply for IP phones and mobile phones)
Business: Toshiba Consumer Marketing Corporation
