Viugreum 80cm Dimmable LED Wall Lamp Instruction Manual

1. Setup

1.1 Package Contents

Before installation, please verify that all components are present in the package:

• LED Wall Lamp (80cm)
• Mounting Bracket
• Screws and Wall Plugs
• Remote Control
• USB-C Charging Cable
• User Manual

Image: All components included in the Viugreum LED Wall Lamp package.

1.2 Wall Mounting

Follow these steps to securely mount your LED wall lamp:

1. Select a suitable location on the wall for installation.
2. Use the mounting bracket as a template to mark the drill holes.
3. Drill holes and insert wall plugs.
4. Secure the mounting bracket to the wall using the provided screws.
5. Attach the lamp base to the mounted bracket. Ensure it is securely fastened.

Image: Securing the mounting bracket to the wall.

Image: The lamp base being attached to the wall-mounted bracket.

1.3 Battery Charging

The lamp features a removable 8000 mAh battery. For initial use, fully charge the battery.

1. Gently slide the battery compartment out from the lamp base.
2. Connect the provided USB-C cable to the battery pack and a suitable USB power adapter (not included).
3. The charging indicator will show the charging status (e.g., red for charging, green for fully charged).
4. Once fully charged, reinsert the battery pack into the lamp base.

Image: Detailed view of the lamp's components, including the removable battery compartment and USB-C charging port.

2. Operating Instructions

The Viugreum LED Wall Lamp can be operated using both the integrated touch control and the included remote control.

2.1 Touch Control

The touch switch is located on the lamp base:

• Click: Turn the lamp ON/OFF.
• Long Press: Adjust brightness (10% to 100%).
• Short Press: Change color temperature (3000K Warm, 4500K Natural, 6500K Cold).

Image: Demonstrating the touch control functions for power, brightness, and color temperature adjustments.

2.2 Remote Control

The remote control offers comprehensive adjustments for brightness, color temperature, and timer settings.

• ON/OFF: Power button.
• Brightness Adjustment: Use '+' and '-' buttons to increase or decrease brightness (10% to 100%).
• Color Temperature Adjustment: Cycle through 3000K (Warm), 4500K (Natural), and 6500K (Cold) settings.
• Timer Function: Set the lamp to turn off automatically after 0.5, 1, 2, or 4 hours.

Image: The remote control unit for the Viugreum LED Wall Lamp, showing various control buttons.

Image: Visual representation of the four color temperatures (3000K, 4000K, 5000K, 6500K) and five dimming levels (20% to 100%).

2.3 350° Rotation Feature

The lamp head can be rotated 350 degrees, allowing you to direct the light precisely where needed. Gently rotate the LED tube to adjust the light direction.

Image: The lamp's flexible 350-degree rotation, allowing for precise light positioning.

2.4 Product Overview Video

3. Maintenance

3.1 Cleaning

To maintain the appearance and performance of your lamp:

• Ensure the lamp is turned off and disconnected from any power source before cleaning.
• Wipe the surface with a soft, dry cloth.
• Do not use abrasive cleaners, solvents, or harsh chemicals, as these may damage the finish.

3.2 Battery Care

Proper battery care ensures longevity and optimal performance:

• Charge the battery fully before first use.
• Avoid completely draining the battery frequently. Recharge when the light output becomes noticeably dim.
• If storing the lamp for an extended period, charge the battery to approximately 50% and store in a cool, dry place. Recharge every 3-6 months to prevent deep discharge.
• The battery is designed for easy removal and charging, eliminating the need to disassemble the entire lamp.

4. Troubleshooting

5. Specifications

6. Warranty and Support

For warranty information and customer support, please refer to the documentation provided with your purchase or contact the retailer/manufacturer directly.

Manufacturer: Zhongshan Haijixing Electric Lighting Co.,Ltd.

Brand: Viugreum
