Hikity Android 15 Car Stereo User Manual for Toyota Yaris/Vitz/Platz 2005-2011

Introduction

This manual provides detailed instructions for the installation, operation, and maintenance of your Hikity Android 15 Car Stereo. This unit is designed specifically for Toyota Yaris, Vitz, and Platz models manufactured between 2005 and 2011, offering advanced features such as a 7-inch touchscreen, wireless CarPlay, Android Auto, GPS navigation, Bluetooth connectivity, and support for a backup camera.

Please read this manual thoroughly before installation and use to ensure proper functionality and to maximize your experience with the product. Keep this manual for future reference.

Vehicle Compatibility

This car stereo is designed to fit Toyota Yaris, Vitz, and Platz models from 2005 to 2011. Please verify your vehicle's dashboard configuration against the images provided to ensure proper fitment before proceeding with installation.

Diagram showing compatible and incompatible car dashboard configurations for the stereo installation.
Figure 1: Car Models Attention - This image illustrates compatible (A: Fit) and incompatible (B: Not Fit) dashboard layouts for the Hikity Android 15 Car Stereo. Ensure your vehicle's dashboard matches the 'Fit' examples for successful installation.

The 'A: Fit' section displays examples of dashboards where the stereo can be installed. The 'B: Not Fit' section shows dashboards that are not compatible with this unit. If your vehicle's dashboard matches the 'Not Fit' examples, this product is not suitable for your car.

Key Features

  • Android 15 Operating System: Equipped with 2GB RAM and 64GB ROM for smooth operation and ample storage for applications. Supports multiple EQ options and 28 desktop themes.
  • Wireless CarPlay & Android Auto: Seamless integration with iOS and Android smartphones for navigation, music, calls, and messages via voice control or touchscreen.
  • Mirror Link Function: Supports mirroring your smartphone screen (iOS unidirectional, Android bidirectional) onto the car stereo display.
  • GPS Navigation: Built-in GPS module supports both online and offline navigation applications.
  • 5G WiFi Connectivity: Allows access to online maps, streaming apps (e.g., YouTube, TikTok), and internet browsing.
  • Bluetooth: Hands-free calling, music playback, and automatic phonebook loading via built-in and external microphones.
  • FM/RDS Radio: Stable FM/RDS radio with 18 preset stations, supporting manual, semi-automatic, and fully automatic channel search for broadcasting, weather, and traffic updates.
  • AHD Backup Camera Support: Automatically displays reversing image when the car is in reverse gear, enhancing parking safety.
  • Steering Wheel Control (SWC): Compatible with original steering wheel controls for convenient operation.
Image showing Android system, WiFi, and GPS navigation features.
Figure 2: Android System, WiFi Connection, and GPS Navigation. This image highlights the core functionalities of the Android 15 system, including app downloads, WiFi hotspot support, and integrated GPS for both online and offline maps.
Image demonstrating Wireless CarPlay and Android Auto interfaces.
Figure 3: Wireless CarPlay and Android Auto. This visual shows the user interface for both CarPlay and Android Auto, displaying common applications like Maps, Calling, and Music, accessible wirelessly or via wired connection.
Image illustrating Mirror Link, FM/RDS radio, IPS display, and Bluetooth features.
Figure 4: Mirror Link, FM/RDS, IPS Display, and Bluetooth. This image details the Mirror Link capability for iOS and Android devices, the FM/RDS radio interface, the high-definition IPS screen, and Bluetooth connectivity for hands-free communication and audio streaming.
Image showing AHD backup camera functionality and steering wheel control setup.
Figure 5: AHD Backup Camera and Steering Wheel Control. This image demonstrates the AHD backup camera's features, including night vision, HD image, waterproofing, and 170-degree guideline, along with the on-screen interface for configuring steering wheel controls.

Package Contents

Before installation, please ensure all items listed below are present in your package:

Diagram showing the product size and a list of included accessories.
Figure 6: Product Size and Package List. This image displays the dimensions of the car stereo unit and a visual representation of all included accessories, such as power cables, GPS antenna, rear camera, and installation tools.
  • Hikity Android Stereo Unit
  • Power Cable
  • Button Adapter Cable
  • Flat Cable
  • GPS Antenna
  • Rear Camera Input Cable
  • RCA Cable
  • Dual USB Cable
  • Dual Mounting Bracket
  • Screws
  • Instruction Manual
  • Installation Tool
  • Rear Camera (if included in package)
  • Microphone (if included in package)

Installation Guide

Wiring Diagram

Refer to the following diagram for correct wiring connections. Incorrect wiring can damage the unit or your vehicle's electrical system.

Detailed car stereo wiring diagram showing connections for power, RCA, USB, camera, radio, and GPS antennas.
Figure 7: Car Stereo Wiring Diagram. This diagram provides a visual guide for connecting the various cables to the car stereo unit, including the power cable, RCA cables, USB cables, camera input, radio antenna, and GPS antenna.

Backup Camera Wiring

For backup camera functionality, follow these wiring steps:

Diagram showing the wiring for the reversing camera.
Figure 8: Reversing Camera Wiring. This diagram illustrates how to connect the backup camera: the red cable to the positive pole of the car reversing light, the black cable to the negative pole, and the other two extension cables are not typically connected.
  • Red Cable: Connect to the positive pole of the car reversing light cable.
  • Black Cable: Connect to the negative pole of the car reversing light cable.
  • The other two red extension cables (labeled 3 and 4 in the diagram) do not need to be connected.

Note: The reversing input cable must be plugged in even when the reversing camera is not used. Otherwise, it may affect Bluetooth and WiFi signal reception.

Operating Instructions

User Interface and Functions

The Android 15 system provides a customizable interface with various desktop themes and applications. Navigate through the home screens by swiping left or right. Access applications from the app drawer.

Video 1: UI Function & Carplay and Android Auto Connection. This video demonstrates the user interface navigation, various functions like music playback, audio settings (equalizer), Bluetooth calling, video playback, and web browsing. It also shows the connection process for both Apple CarPlay and Android Auto.

Wireless CarPlay & Android Auto

To use Wireless CarPlay or Android Auto, connect your smartphone via Bluetooth. Once paired, the system will prompt you to activate CarPlay or Android Auto. Follow the on-screen instructions and allow necessary permissions on your phone.

Mirror Link

For iOS devices, connect via USB and follow prompts for unidirectional control. For Android devices, enable USB debugging on your phone, connect via USB, and allow permissions for bidirectional control.

GPS Navigation

The unit comes with a built-in GPS module. You can download offline maps from the Play Store for navigation without an internet connection. For online maps, ensure the unit is connected to WiFi or a mobile hotspot.

Bluetooth Connectivity

To pair your phone, go to the Bluetooth settings on the car stereo and your phone. Search for available devices and select 'Car BTo'. Enter the PIN (default is 1234) if prompted. Allow access to contacts and call history for full functionality.

FM/RDS Radio

Access the Radio application to tune into FM stations. Use the search function for automatic scanning or manually select frequencies. RDS (Radio Data System) provides station information where available.

Steering Wheel Control (SWC) Setup

To configure steering wheel controls, follow these steps:

Screenshot of the steering wheel control learning interface.
Figure 9: Steering Wheel Control Learning Interface. This image shows the on-screen menu for programming steering wheel buttons. Users can assign functions like volume, mode, and track skip to their vehicle's existing steering wheel controls.
  • Go to Settings > Car Settings > Factory Setup.
  • Enter the password 1234.
  • Choose Car Settings and select your car's year and model.
  • Access Steering Learning under Factory Settings to complete the setup.

CANBUS Note:

Information regarding CANBUS decoder connection for steering wheel controls.
Figure 10: CANBUS Note. This image provides instructions for connecting steering wheel controls, differentiating between vehicles with and without a CANBUS decoder, and outlining the necessary software configuration steps.
  • Without CANBUS Decoder: Connect the plugs or steering wheel control wires (Key1/Key2) from the power cable to the appropriate ports or wires of your original vehicle. Then, navigate to Settings > Car Settings > General (Enter SWC setting Interface) to manually match and activate the button functions.
  • With CANBUS Decoder: Ensure the CANBUS is connected before powering on the machine. After that, proceed to Settings > Car Settings > Factory (000000) > Car Type Setting to enable SWC to function properly. First, select the brand of the CANBUS decoder, then select the matching model and year according to the actual situation.

Specifications

FeatureSpecification
Operating SystemAndroid 15
RAM2GB
ROM64GB
Screen Size7 Inches
Display TypeIPS Touchscreen
ConnectivityBluetooth, USB, Wi-Fi (5G)
Special FeaturesWireless/Wired CarPlay & Android Auto, GPS, Mirror Link, FM RDS Radio, 28 Desktop Themes, Steering Wheel Control, Backup Camera Input
Audio Output ModeStereo
Voice CommandButtons, Microphone, Touchscreen
Item Weight2.64 pounds
Package Dimensions11.02 x 8.27 x 3.15 inches

Maintenance and Care

To ensure the longevity and optimal performance of your car stereo, follow these maintenance guidelines:

  • Regularly clean the touchscreen with a soft, lint-free cloth. Avoid abrasive cleaners.
  • Keep the unit free from dust and moisture.
  • Avoid exposing the unit to extreme temperatures.
  • Ensure all cables are securely connected to prevent intermittent issues.

Troubleshooting

If you encounter any issues with your Hikity Android 15 Car Stereo, refer to the following common troubleshooting tips:

  • No Power: Check all power connections and fuses. Ensure the vehicle's ignition is on.
  • No Sound: Verify speaker connections, volume levels, and audio settings (EQ, sound field).
  • Bluetooth Connection Issues: Ensure Bluetooth is enabled on both the stereo and your phone. Delete previous pairings and try reconnecting.
  • GPS Signal Loss: Ensure the GPS antenna is properly installed and has a clear view of the sky.
  • CarPlay/Android Auto Not Connecting: Check USB cable connection (if wired), ensure all permissions are granted on your phone, and verify the 'SpeedPlay' app is running on the stereo.
  • Steering Wheel Controls Not Working: Recheck CANBUS connections or manual SWC learning settings as described in the installation section.
  • Backup Camera Not Displaying: Verify the camera's power and video input connections. Ensure the reversing input cable is connected to the stereo.

For persistent issues, please contact customer support.

Warranty and Support

Your Hikity Android 15 Car Stereo comes with a comprehensive warranty and dedicated technical support:

  • Warranty: 30-Days Money-Back Guarantee, 2-Years Replacement.
  • Technical Support: Life-Time Technical Support is provided.

For installation or usage issues, please contact Hikity Flagship Store via the product page on Amazon. Support inquiries are typically answered within 24 hours.
