Important Safety Instructions
Please read and understand all instructions before assembling and using this product. Failure to follow these instructions may result in electric shock, fire, or serious injury.
- Indoor Use Only: This lamp is designed for indoor use in dry locations. Do not use in wet or damp areas.
- Electrical Safety: Ensure the power supply is disconnected before assembly, disassembly, or bulb replacement. Use only with a 120V AC power supply.
- Bulb Compatibility: Use only the provided 10W A19 LED bulb or an equivalent E26 base LED bulb with a maximum wattage of 60W. Do not exceed the recommended wattage.
- Proper Handling: Do not operate the lamp with a damaged cord or plug. If the cord or plug is damaged, contact customer support for assistance.
- Stability: Place the lamp on a flat, stable surface to prevent tipping.
- Cleaning: Unplug the lamp before cleaning. Use a soft, dry cloth. Do not use liquid or abrasive cleaners.
Product Overview
The GOEBLESON P17LD05 Dimmable Floor Lamp offers versatile lighting with modern design. It features dual control options, adjustable brightness and color temperature, and a space-saving profile.
Figure 1: Key components of the floor lamp including the removable shade, foot switch, A19 bulb, and magnetic remote.
Key Features:
- Magnetic Remote & Foot Switch: Convenient dual control for power and settings. The remote can be magnetically attached to the lamp pole.
- Smooth Dimming & Color Tuning: Adjust brightness from 10% to 100% and color temperature from 3000K (Warm White) to 6500K (Daylight).
- Modern Corner Design: Space-saving and suitable for various room layouts.
- ETL Certified: Meets rigorous safety standards.
- Easy Assembly: Designed for quick and straightforward setup.
- DIY Shade: Double-layer pleated shade is removable for cleaning and allows for personalization.
Package Contents
Verify that all components are present before beginning assembly:
- Lamp Pole Sections (multiple)
- Lamp Base
- Pleated Lamp Shade
- 10W A19 LED Bulb
- Remote Control (with batteries)
- Foot Switch (integrated into power cord)
- User Manual (this document)
Setup Instructions
Follow these steps to assemble your GOEBLESON floor lamp:
- Attach the Lamp Base: Carefully screw the lowest lamp pole section into the lamp base. Ensure it is tightened securely to provide stability.
- Assemble Lamp Pole: Connect the remaining lamp pole sections by screwing them clockwise. Ensure each section is firmly connected to prevent wobbling.
- Install the Lamp Shade: The pleated shade comes flat. Gently expand it and align the pleated edges. Secure the shade to the top lamp frame using the provided clips or fasteners, ensuring it is evenly distributed for soft light without shadows.
- Insert the Bulb: Screw the provided 10W A19 LED bulb into the E26 socket at the top of the lamp pole. Do not overtighten.
- Connect to Power: Plug the power cord into a standard 120V AC electrical outlet.
Figure 2: Visual guide for quick and easy lamp setup.
Operating Instructions
Using the Foot Switch:
- Press the foot switch once to turn the lamp ON.
- Press the foot switch again to turn the lamp OFF.
Using the Remote Control:
The remote control provides full functionality for the lamp. Ensure the remote has batteries installed (typically 2x AAA, included).
Figure 3: Remote control functions for the floor lamp.
- Power Button (On/Off): Press to turn the lamp on or off.
- Brightness Adjustment (C+/C-): Use these buttons to increase or decrease the brightness from 10% to 100%.
- Color Temperature Adjustment (K+/K-): Use these buttons to cycle through or adjust the color temperature settings: 3000K (Warm White), 4500K (Cool White), and 6500K (Daylight).
- 1-Hour Auto-Off Timer: Press the timer button to activate a 1-hour countdown, after which the lamp will automatically turn off.
- Magnetic Attachment: The remote can be magnetically attached to the lamp pole for convenient storage.
Figure 4: The lamp offers three distinct color temperatures and smooth dimming.
Maintenance
Cleaning:
- Always unplug the lamp from the power outlet before cleaning.
- Use a soft, dry cloth to wipe the lamp pole and base.
- The pleated shade is removable for cleaning. Hand wash gently with mild soap and water, then air dry completely before reattaching. Do not machine wash or tumble dry.
- Avoid using abrasive cleaners, solvents, or polishing agents as they may damage the finish.
Bulb Replacement:
- Ensure the lamp is unplugged and the bulb has cooled down before attempting to replace it.
- Unscrew the old bulb counter-clockwise.
- Screw in a new E26 base LED bulb, not exceeding 60W. The recommended replacement is a 10W A19 LED bulb.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Lamp does not turn on. | No power, loose bulb, faulty bulb, remote batteries dead. | Check power outlet. Ensure plug is fully inserted. Tighten bulb. Replace bulb. Replace remote batteries. |
| Remote control not working. | Dead batteries, remote out of range, obstruction. | Replace remote batteries. Ensure remote is within range and pointed towards the lamp. Remove any obstructions. |
| Lamp flickers or dims unexpectedly. | Loose bulb, incompatible bulb, unstable power. | Tighten bulb. Ensure correct bulb type (E26 LED, max 60W). Try a different power outlet. |
| Lamp pole is wobbly. | Loose pole sections or base connection. | Ensure all pole sections and the base are screwed together tightly. |
Specifications
| Feature | Detail |
|---|---|
| Model Number | P17LD05 |
| Dimensions (H x W x D) | 64.2" x 7.9" x 7.9" (163cm x 20cm x 20cm) |
| Item Weight | 4.85 Pounds |
| Material | Metal (Base), Linen (Shade) |
| Finish Type | Painted |
| Bulb Base | E26 |
| Included Bulb | 10W A19 LED (Dimmable) |
| Max Wattage (Compatible) | 60W |
| Light Source Type | LED |
| Color Temperature | 3000K (Warm White), 4500K (Cool White), 6500K (Daylight) |
| Brightness Adjustment | 10% - 100% |
| Switch Type | Remote Control, Foot Switch |
| Special Features | 1-Hour Auto-Off Timer, Magnetic Remote |
| Certifications | ETL Listed |
| Indoor/Outdoor Usage | Indoor |
Figure 5: Product dimensions and bulb compatibility details.
Warranty and Support
GOEBLESON products are designed for quality and reliability. This product comes with a standard manufacturer's warranty covering defects in materials and workmanship under normal use. Please refer to the product packaging or contact customer service for specific warranty duration and terms.
Customer Support:
If you have any questions, require assistance, or encounter issues with your GOEBLESON P17LD05 Dimmable Floor Lamp, please contact our customer support team:
- Email: [Insert Customer Support Email Here, if available]
- Phone: [Insert Customer Support Phone Number Here, if available]
- Website: Visit the GOEBLESON Store on Amazon
Please have your model number (P17LD05) and purchase date ready when contacting support.
