iTRUSOU Food Warming Mat BWP01 User Manual

Introduction

The iTRUSOU Food Warming Mat BWP01 is an innovative solution designed to keep food warm for extended periods. This versatile device features a modular design, allowing for flexible configurations to suit various needs, from daily meals to large gatherings. Constructed from food-grade nano-coated silicone, it offers durability, ease of cleaning, and advanced safety features including 7 temperature settings, a 99-hour timer, and a child lock.

Safety Information

Important Safety Precautions:

• Always place the warming mat on a heat-insulating pad to protect countertops, especially those made of ordinary glass, quartz, marble, or granite, from heat damage.
• Ensure the mat is used only for keeping food warm; it is not designed for reheating cold food.
• Do not touch the heating surface immediately after use as it remains hot.
• Keep out of reach of children and pets when in use, utilizing the built-in child lock feature.
• Do not rinse the control panel directly with water.

Package Contents

• Main Warming Panel (Panel A)
• Extension Panels (Panels B & C, sold separately)
• Power Cord
• Storage Strap
• User Manual

Setup

1. Unpacking: Carefully remove all components from the packaging.
2. Placement: Place the main warming panel (Panel A) on a stable, heat-resistant surface. If using on sensitive countertops, place a heat-insulating pad underneath.
3. Connecting Extension Panels (Optional): If additional warming surface is required, align the patented safety connectors of Panel B or C with Panel A. Gently slide them together until they securely interlock. The system ensures safe power transfer without additional cords between connected panels.


   Illustration of the modular and expandable design, showing how Panel A can be combined with optional Panels B and C to create various sizes for different occasions.



   A close-up of the patented safety connection interface, highlighting its seamless power transfer and safe-to-touch design, even when panels are used individually.

4. Power Connection: Insert the power cord into the designated port on the main control panel and then plug it into a 120V electrical outlet.

Operating Instructions

1. Power On/Off: Press the power button (Temperature Adjustment: The mat offers 7 temperature settings, ranging from 104°F (40°C) to 212°F (100°C) in 18°F/10°C increments.
   • Use the '+' button to increase the temperature.
   • Use the '-' button to decrease the temperature.
2. Switching Temperature Units (°C/°F): The default display is Fahrenheit. To switch to Celsius, press and hold both the '+' and '-' buttons simultaneously for 3 seconds.
3. Timer Function: The default timer setting is 1-8 hours, suitable for daily use.
   • Press the timer button (Child Lock: To prevent accidental changes to settings, activate the child lock.
     • Press the lock button (

       A detailed view of the smart control panel, illustrating the 7-level temperature flexibility with switchable Celsius/Fahrenheit display and the child safety lock feature.



       The warming mat in use with a variety of dishes, emphasizing the flexible 1-99 hour smart timer for short meals or extended events.

Versatile Uses

The iTRUSOU Food Warming Mat is designed primarily for keeping food warm, but its consistent and even heat distribution makes it suitable for other applications:

• Dough Proofing: Provides a stable warm environment for yeast dough to rise.
• Gentle Defrosting: Safely defrosts frozen items at a controlled temperature.
• Drying Clothes: Can be used for gently drying small garments or accessories.
• Melting Chocolate: Offers a controlled low heat for melting chocolate without scorching.
• Warming Milk/Baby Bottles: Maintains a safe temperature for liquids.

This image highlights the versatile applications of the warming mat beyond just keeping food warm, including defrosting, dough fermentation, and warming milk.

Maintenance & Cleaning

1. Disconnect Power: Always unplug the warming mat from the power outlet before cleaning.
2. Allow to Cool: Ensure the mat has completely cooled down before handling or cleaning.
3. Wipe Clean: The nano-coated silicone surface is stain-resistant. Use a damp cloth and mild detergent to wipe away spills and food residue. Avoid abrasive cleaners or scouring pads.
4. Drying: Ensure the mat is completely dry before storing or reconnecting to power.
5. Storage: Roll up the mat and secure it with the provided storage strap for compact storage. Store in a dry place.

Troubleshooting

Mat Not Heating:

• Ensure the power cord is securely plugged into both the mat and a working electrical outlet.
• Check if the power button is pressed and the display is active.

Temperature Not Changing:

• Verify that the child lock is not engaged. If it is, press the lock button to deactivate it.
• Ensure you are pressing the '+' or '-' buttons firmly.

Uneven Heating:

• The mat is designed for even heat distribution. Ensure the mat is placed on a flat, stable surface and not obstructed.
• Avoid placing directly on ordinary glass, quartz, marble, or granite countertops without a heat-insulating pad.

Specifications

Warranty & Support

The iTRUSOU Food Warming Mat BWP01 comes with a one-year quality warranty. In case of any issues, we offer seamless replacement instead of repair for a truly worry-free experience. Please contact iTRUSOU customer support for assistance.

Product Overview

The iTRUSOU Food Warming Mat BWP01 in its full setup, showcasing its capacity to hold multiple dishes. A rolled-up mat is visible in the background, highlighting its compact storage.

A family enjoying a meal with food kept warm on the modular warming mat, illustrating its suitability for various dining moments.

Official Product Video

An official product video demonstrating the iTRUSOU BWP01 warming mat's expandable design and various features, including temperature control and timer, suitable for parties and gatherings.
