BCAN 51" Mini Hexagon Trampoline Instruction Manual

Introduction

Thank you for choosing the BCAN 51" Mini Hexagon Trampoline. This manual provides essential information for safe and effective use of your new fitness equipment. This trampoline is designed for low-impact workouts, helping to tone muscles, boost heart rate, burn calories, and ease pressure on joints. Its spacious 51-inch frame offers 20% more jump space than standard models, providing freedom for wider movements and dynamic cardio. The trampoline is equipped with 36 elastic cords, offering gentler cushioning and low-noise performance.

Safety Information

Always consult with a healthcare professional before starting any new exercise program. Ensure the trampoline is assembled correctly and placed on a flat, stable surface. Do not use the trampoline if any parts are damaged or missing. Only one person should use the trampoline at a time. Keep children and pets away from the trampoline during use. The trampoline frame is not foldable and should not be attempted to be folded.

Parts List

Before assembly, ensure all parts are present and in good condition. Refer to the image below for a visual representation of all components included in your package.

Image: All components of the BCAN 51-inch Hexagon Trampoline laid out on grass, including frame sections, jump mat, bungee cords (green and black), feet, screws, and tools.

• Frame Sections (6 pieces)
• Jump Mat (1 piece)
• Bungee Cords (Green 8mm, Black 9mm)
• Legs (6 pieces, with one having two holes for the handle)
• Feet Caps (6 pieces, one larger for handle leg)
• Handle Bar (T-shaped, adjustable)
• Screws and Washers
• Allen Wrenches (2 sizes)
• Labor-saving tool (for bungee installation)

Setup and Assembly

Follow these steps for quick and easy assembly. Key components are pre-installed for a smooth, frustration-free experience.

Image: A circular diagram illustrating the six main steps for assembling the trampoline frame, from individual pieces to the fully assembled base.

1. Assemble the Frame

   Connect the curved frame sections by inserting the male end into the female end until they click into place. Ensure the holes on each section align. There will be six such connections around the frame. Use the provided Allen wrenches and screws to secure these connections. Hand-tighten initially, then fully tighten once all sections are in place. Be careful not to strip the screws.

2. Attach the Legs

   The trampoline comes with six sturdy legs. One leg has two holes for the handle attachment. Position this leg at the front of your desired setup. The legs are welded onto the frame for this model, ensuring stability.

3. Lay Out the Jump Mat

   Place the jump mat face down within the assembled frame. Ensure the
