ATOTONA X10 Touch Screen Radio User Manual

1. Introduction

The ATOTONA X10 Touch Screen Radio is a state-of-the-art car infotainment system designed to provide a superior driving experience. With its powerful QCM SD665 SoC, ample memory, and a vibrant 10.1-inch QLED floating display, it offers seamless navigation, high-fidelity audio, and advanced connectivity options. This manual provides detailed instructions for installation, operation, and maintenance to ensure optimal performance and longevity of your device.

2. Package Contents

Please verify that all items listed below are included in your package. If any items are missing or damaged, please contact customer support.

• Backup Camera
• Car Recorder
• External Noise Cancelling Microphone
• 20P Wire Harness
• USB1 Recording Storage Cable
• USB2 External Storage Cable
• RCA 16P Combination Cable
• 4-in-1 Antenna (for WiFi, GPS & Cellular Network)
• Tri-band Audio with Remote
• DIN Pocket
• Movable Mounting Brackets
• DIN Sleeve 1
• DIN Sleeve 2
• Mounting Screws
• Online References (Quick Guide & Product Care)

Visual representation of the ATOTONA X10 Touch Screen Radio's package contents.

3. Setup and Installation

Proper installation is crucial for the performance and safety of your ATOTONA X10. It is recommended to have the unit installed by a qualified professional.

3.1 Physical Dimensions and Mounting

The X10 features a 10.1-inch QLED floating display with adjustable height, tilt, and angle for optimal viewing. The main unit dimensions are 165mm (width) x 42mm (height) x 155mm (depth), and the display measures 264mm (width) x 168mm (height). A tolerance of 1mm applies to these dimensions.

Detailed dimensions of the X10 display and main unit.

3.2 FlexView Pro Mount Adjustment

The exclusive FlexView Pro mount allows for 9-way adjustment to achieve maximum viewing comfort. Adjustments include up/down (27mm), left/right (24mm), forward (18mm), swivel (driver tilt 30), and tilt (up/down 10). Adjustments should be made during installation, and screws must be reattached firmly to secure the display while driving.

The ATOTONA X10 with its FlexView Pro mount, demonstrating its adjustability for optimal viewing.

Illustrations of the FlexView Pro mount's extensive adjustment capabilities.

3.3 Installation Types and Obstruction Reminder

The X10 supports both Standard Double-DIN and Single-DIN opening installations. Ensure that the display's full adjustment range (forward, backward, up, down, left, right) does not block any essential vehicle controls, vents, or buttons. Verify there is enough space to reach all essential functions.

Examples of Double-DIN and Single-DIN installation configurations.

Important considerations for avoiding obstruction of vehicle controls during installation.

3.4 Wiring Diagram

Refer to the following diagram for proper wiring connections. This includes power, speaker outputs, camera inputs, and other auxiliary connections. Ensure all connections are secure before powering on the unit.

Comprehensive wiring diagram for the ATOTONA X10 unit.

3.5 Vehicle Data Integration

The X10 is designed to support integration with steering wheel controls, factory amplifiers, and vehicle information systems (e.g., gauges, climate data) for cars with complex data systems. Check your vehicle's compatibility before installation. Data interfaces like AC-ADSX10 are not included and may be required.

The ATOTONA X10's capability for seamless integration with vehicle data and controls.

4. Key Features

4.1 Powerful Performance and QLED Display

The X10 is powered by a QCM SD665 SoC with 8GB RAM and 128GB storage, ensuring snappy response times, effortless app launches, and smooth multi-tasking. The 10.1-inch QLED panel offers 550 nits brightness and strong light suppression, providing crisp 1280720 resolution for navigation, video, and app experiences.

The ATOTONA X10's powerful hardware and high-resolution QLED display.

4.2 Evolved Audio Suite

Experience studio-quality sound with the X10's advanced audio features:

• DSP with 36-band EQ: Fine-tune your audio with precision.
• Time Alignment: Optimize sound staging for a perfect listening position.
• 3-Way Crossover: Dedicated outputs for tweeters, midrange, and dual subwoofers.
• HD 24-bit DAC: Delivers clarity and dynamic range.
• Optical Out (SPDIF): For connecting external DACs or DSP units.
• 10 Assignable Channels: Craft a true 7.1.2 surround stage without extra gear.
• 4V RCA Preamp Outputs: Connect external amplifiers effortlessly.
• Hi-Res Audio: Supports aptX HD for better sound quality via Bluetooth.
• Dual Built-in Noise-Cancelling Mics + External Mic Support: For clear communication and voice commands.

The ATOTONA X10's comprehensive audio suite for audiophiles.

Visual explanation of the 36-Band EQ and Time Alignment.

Illustration of the 24-Bit HD DAC and Active 3-Way Crossover.

The Optical SPDIF output for enhanced audio customization.

Details on Hi-Res Audio support and microphone performance.

The 4V RCA Preamp Outputs for connecting external amplifiers.

4.3 Dual-Camera Recording & Safety Features

Connect two 1080P cameras (front and rear or interior) to record footage simultaneously. The X10 includes features like parking monitoring, emergency video lock, and GPS-linked playback. Approaching OmniGuard Pro technology will add further safety capabilities, such as sending footage and GPS to emergency contacts if a crash is detected.

The ATOTONA X10's dual-camera recording functionality.

Overview of the X10's safety and monitoring features, including OmniGuard Pro Tech.

4.4 Seamless Connectivity

Stay connected on the go with the X10's versatile connectivity options:

• Cellular Network & Dual-Band Wi-Fi: Stream music, get map updates, and install apps.
• Built-in Hotspot: Supports passengers devices.
• Wireless CarPlay/Android Auto/MirrorLink: Seamless smartphone integration.
• Dual Phone Connection: Seamlessly switch between two phones for calls or music.
• HDMI Input: For gaming and streaming with HDMI 1.4 and older devices.

The ATOTONA X10's connectivity features, including HDMI input for external devices.

Advanced Bluetooth and tethering capabilities for seamless connection.

The built-in cellular network modem for continuous streaming and sharing.

4.5 AI and User Interface

The X10 features a refined, custom AICE 13 UI and integrates AI capabilities. It supports G00gle Play and Findapps for endless infotainment options. The UI allows for resizable widgets and dynamic wallpapers to tailor your experience.

The ATOTONA X10's AI capabilities and customizable user interface.

Overview of the exclusive built-in digital apps for the ATOTONA X10.

5. Operating Instructions

5.1 Basic UI Navigation

The ATOTONA X10 features an intuitive touch-screen interface. Swipe left or right to navigate between home screens, tap icons to open applications, and use the bottom navigation bar for quick access to common functions like home, back, and recent apps.

5.2 Wireless CarPlay/Android Auto/MirrorLink

Connect your smartphone wirelessly to access navigation, music, calls, and messages directly on the X10 display. Follow the on-screen prompts for initial setup and pairing.

5.3 Voice Control

Utilize the built-in voice control feature for hands-free operation. Activate voice commands by saying the designated wake-up phrase or pressing the voice control button (if available). Commands include navigation, music playback, and calling contacts.

5.4 App Installation

Access G00gle Play Store or Findapps to download and install a wide range of applications. Ensure a stable internet connection via Wi-Fi or cellular network for app downloads.

6. Maintenance

6.1 General Care and Cleaning

To maintain the display and unit, use a soft, lint-free cloth for cleaning. For stubborn smudges, slightly dampen the cloth with water or a screen-safe cleaner. Avoid abrasive materials or harsh chemicals that could damage the screen or finish.

6.2 Firmware Updates (OTA)

The ATOTONA X10 supports Over-The-Air (OTA) firmware upgrades. These updates provide new functions, performance improvements, and bug fixes. Ensure your device is connected to a stable internet connection (Wi-Fi or cellular) to receive and install updates. Follow the on-screen prompts when an update is available.

7. Troubleshooting

If you encounter issues with your ATOTONA X10, please refer to the following common troubleshooting steps:

• No Power: Check all power connections and ensure the vehicle's ignition is on. Verify the fuse is intact.
• No Sound: Check speaker connections, volume levels, and audio source selection. Ensure the amplifier (if external) is powered on.
• Display Not Responding: Try restarting the unit. If the issue persists, perform a soft reset (refer to the online manual for specific instructions).
• GPS Signal Lost: Ensure the GPS antenna is properly installed and has a clear view of the sky.
• Bluetooth/Wi-Fi Connectivity Issues: Ensure Bluetooth/Wi-Fi is enabled on both the X10 and the connecting device. Try re-pairing devices.
• App Crashing/Freezing: Clear the app's cache or reinstall the app. Ensure the system firmware is up to date.

For more detailed troubleshooting or persistent issues, please contact ATOTONA customer support.
