1. Product Overview
The LEZOE 18W IP65 LED Ceiling Light is designed for versatile indoor and outdoor use, offering high energy efficiency and adjustable lighting options. Its robust construction ensures durability and protection against water and dust.
Key Features:
- Super Bright & Energy Saving: Delivers 2700 lumens at 18W (150 lm/W), offering significant energy savings compared to conventional lighting.
- IP65 Waterproof & Dustproof: Provides superior protection against dust and strong water jets, suitable for bathrooms, kitchens, balconies, and outdoor areas.
- Adjustable Wattage & 3 Color Temperatures: Features a slide switch to select between 12W (1800lm) or 18W (2700lm) and color temperatures of 3000K (warm white), 4000K (natural white), or 6500K (cool white).
- Non-Dazzling & Flicker-Free: Designed for eye comfort, providing uniform and soft light, ideal for reading and extended use.
- Easy Installation: Simple mounting process with included accessories, no need to remove the lampshade.
- Durable Construction: Made from high-quality V2 fire-retardant, insulating polycarbonate.
2. Safety Information
- Always disconnect power before installation, maintenance, or cleaning.
- Ensure the mounting surface is structurally sound and can support the weight of the fixture.
- Do not attempt to modify the product. Any modifications may void the warranty and pose safety risks.
- Keep packaging materials away from children.
- If you are unsure about the installation process, consult a qualified electrician.
3. Package Contents
Verify that all components are present before beginning installation:
- 1x LEZOE LED Ceiling Light (Model 18W, IP65 Waterproof)
- Mounting Hardware (screws, wall plugs)
- Instruction Manual
4. Installation Guide
Follow these steps for a safe and correct installation:
- Prepare for Installation: Turn off the main power supply at the circuit breaker before starting any electrical work.
- Select Settings: Before mounting, use the slide switches on the back of the lamp to select your desired wattage (12W or 18W) and color temperature (3000K, 4000K, or 6500K).
- Mount the Base: Secure the mounting bracket to the ceiling using the provided screws and wall plugs. Ensure the bracket is firmly attached.
- Connect Wiring: Connect the electrical wires from your ceiling to the corresponding terminals on the lamp's wiring block. Ensure all connections are secure and properly insulated.
- Attach the Lamp: Align the LED ceiling light with the mounted bracket and twist or slide it into place until it locks securely. The design allows for installation without removing the lampshade.
- Restore Power: Once the lamp is securely installed and all connections are checked, restore power at the circuit breaker.
Installation Video:
5. Operating Instructions
Adjusting Wattage and Color Temperature:
The LEZOE LED Ceiling Light features adjustable wattage and color temperature settings, which must be selected using the slide switches located on the back of the fixture before installation. Once installed, these settings are fixed until the fixture is unmounted.
- Wattage Options: Choose between 12W (1800 lumens) for lower brightness or 18W (2700 lumens) for maximum brightness.
- Color Temperature Options: Select 3000K (warm white), 4000K (natural white), or 6500K (cool white) to suit your environment and preference.
Radar Motion Sensor Settings:
The integrated 5.8G radar motion sensor offers customizable settings for optimal performance. The default settings are 18W, 100% motion sensor sensitivity, 50 Lux light sensor, and 30 seconds hold time.
6. Maintenance
To ensure the longevity and optimal performance of your LEZOE LED Ceiling Light, follow these simple maintenance guidelines:
- Cleaning: Regularly wipe the surface of the lamp with a soft, dry or slightly damp cloth. Avoid using abrasive cleaners, solvents, or harsh chemicals, as these can damage the finish or electronic components.
- Inspection: Periodically check for any loose connections or visible damage. If any issues are found, disconnect power and consult a qualified technician.
- No User-Serviceable Parts: The LED components are permanently installed. Do not attempt to open or repair the fixture yourself.
7. Troubleshooting
If you encounter any issues with your LEZOE LED Ceiling Light, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Light does not turn on | No power supply Loose wiring connection Incorrect switch setting | Check circuit breaker and wall switch Verify wiring connections (ensure power is off) Confirm wattage/color temperature switches are set correctly |
| Light flickers | Unstable power supply Loose wiring Incompatible dimmer (if applicable) | Consult an electrician to check power stability Check wiring connections (ensure power is off) Ensure no dimmer is used or use a compatible LED dimmer |
| Motion sensor not working | Incorrect sensor settings Obstruction Ambient light too high | Adjust radar sensor settings (sensitivity, daylight sensor) Ensure no objects are blocking the sensor's detection area Check daylight sensor setting; if ambient light is above threshold, the sensor may not activate |
| Light is too dim/bright | Incorrect wattage setting | Adjust the wattage switch on the back of the lamp (requires unmounting) |
If the problem persists after trying these solutions, please contact customer support.
8. Specifications
| Feature | Detail |
|---|---|
| Brand | LEZOE |
| Model Number | 18W (LZ2505) |
| Product Dimensions | 22 x 22 x 6 cm |
| Weight | 500 Grams |
| Material | Polycarbonate |
| Style | Modern, Square |
| Voltage | 220 Volt |
| Light Source Type | LED |
| Luminous Flux | 1800 Lumen (12W) / 2700 Lumen (18W) |
| Wattage | 12W / 18W (Selectable) |
| Color Temperature | 3000K / 4000K / 6500K (Selectable) |
| Special Features | Motion Sensor, Energy Efficient, Adjustable Color Temperature, Waterproof (IP65) |
| Certification | CE, RoHS |
| Energy Efficiency Class | D |
| Average Lifespan | 30,000+ hours |
For more detailed product information, please refer to the EPREL database: https://eprel.ec.europa.eu/qr/2391215
9. Warranty and Support
LEZOE stands behind the quality of its products. Your LED ceiling light comes with the following guarantees:
- 90-Day Refund Guarantee: If you are not satisfied with your purchase, you may be eligible for a full refund within 90 days.
- 2-Year Replacement Warranty: The product is covered by a 2-year replacement warranty against manufacturing defects.
For any issues, questions, or support needs, please contact LEZOE customer service directly. Provide your purchase details and a description of the problem for prompt assistance.
