BIGFLY C29 Ultra Electric Bicycle Instruction Manual

Introduction

The BIGFLY C29 Ultra electric bicycle offers powerful performance with a 250W motor, reaching speeds up to 25 km/h, ideal for urban and outdoor adventures. It features a 48V 720Wh lithium battery for extended range (30-60 km pure electric, 80-100 km pedal assist). Enjoy comfortable riding with a 21-speed system, 29-inch anti-puncture tires, aluminum front fork, LCD display, and hydraulic disc brakes for maximum safety. The full suspension with a lockable front fork adapts to all road types. Three riding modes (pedal assist, full electric, classic bike) provide total flexibility. Comes 85% pre-assembled with a 12-month warranty and lifetime technical support.

What's in the Box

Upon unpacking, please ensure all components are present:

• Mudguards
• Horn
• Pump
• Luggage Rack
• Reflector
• BIGFLY C29 Ultra Electric Bicycle (partially assembled)
• Battery (48V 15Ah)
• Charger
• User Manual (this document)
• Assembly Tools

Setup and Assembly

The BIGFLY C29 Ultra electric bicycle is delivered 85% pre-assembled. Follow these steps for final assembly:

1. Unpacking and Initial Inspection

Carefully remove the bicycle and all components from the packaging. Remove all protective materials. Inspect for any visible damage during transit.

Image: The BIGFLY C29 Ultra Electric Bicycle after being removed from its packaging, showing the main frame, wheels, and various accessories laid out.

2. Handlebar Installation

Attach the handlebar to the stem. Ensure proper alignment with the front wheel before tightening the screws securely.

3. Front Wheel Installation

Insert the front wheel into the fork dropouts, ensuring the brake rotor is correctly positioned within the caliper. Securely tighten the axle nuts.

Image: Close-up of the 29-inch front wheel with disc brake and aluminum suspension fork.

4. Seat and Seat Post Adjustment

Insert the seat post into the frame and adjust the seat height to a comfortable riding position. Secure it using the quick-release clamp.

5. Pedal Installation

Attach the pedals to the crank arms. Note that the left pedal is tightened counter-clockwise and the right pedal is tightened clockwise. Ensure they are securely fastened.

6. Mudguard and Luggage Rack Installation

Install the front and rear mudguards and the luggage rack using the provided screws and brackets. Ensure they are stable and do not interfere with wheel rotation.

7. Battery Installation

Insert the 48V 15Ah lithium battery into its holder on the frame. Ensure it clicks securely into place and is locked with the key.

Image: The 48V 15Ah large capacity portable battery, highlighting its fast charging, longer lifespan, and overcharge protection features.

8. Headlight and Taillight Connection

Connect the headlight cable and adjust the headlight to the proper direction. Ensure the taillight is securely attached to the seat post.

Image: Overview of safety features: bright front light, reflective warning service, and ultra-sensitive dual hydraulic disc brakes.

9. Display and Throttle Setup

Ensure the LCD display and throttle are correctly positioned and connected. The display allows for monitoring speed, battery level, and pedal assist levels.

Operating Instructions

The BIGFLY C29 Ultra offers three distinct riding modes to suit various preferences and terrains:

• Pedal Assist Mode: Provides five levels of motor assistance while you pedal. This mode extends battery range and reduces effort.
• Full Electric Mode: Engages the motor via the throttle for propulsion without pedaling. Ideal for quick boosts or when you need a break from pedaling.
• Classic Bicycle Mode: The motor is disengaged, allowing you to ride the bicycle like a traditional bike, relying solely on pedal power.

Use the LCD display to monitor your speed, battery level, and current assist mode. The 21-speed gear system allows for smooth transitions across different gradients and speeds.

Image: Illustration of the three riding modes: accelerator mode, pedal assist mode, and unlimited (PAS) mode, showing approximate ranges.

Maintenance

• Battery Care: Charge the battery regularly, especially after long rides. Avoid completely draining the battery. Store the battery in a cool, dry place.
• Tire Pressure: Regularly check and maintain the recommended tire pressure for optimal performance and safety.
• Brakes: Inspect hydraulic disc brakes periodically for wear and proper function. Ensure brake levers are responsive.
• Chain and Gears: Keep the chain clean and lubricated. Check the 21-speed gear system for smooth operation.
• General Cleaning: Clean the bicycle regularly with a damp cloth. Avoid using high-pressure water jets directly on electrical components.
• Fasteners: Periodically check all bolts and fasteners for tightness.

Troubleshooting

• No Power: Ensure the battery is fully charged and properly installed. Check that the power button on the battery and display are turned on.
• Motor Not Assisting: Verify that pedal assist mode is selected and the assist level is not set to zero. Check all electrical connections.
• Brakes Squealing/Ineffective: Inspect brake pads for wear. Ensure rotors are clean. If issues persist, professional inspection is recommended.
• Unusual Noises: Check for loose components, chain issues, or debris in moving parts.

For complex issues or repairs, please contact BIGFLY customer support.

Specifications

Warranty and Support

The BIGFLY C29 Ultra electric bicycle comes with a 12-month warranty. We also provide lifetime technical support and 24/7 customer service for all our electric bicycles. For any inquiries, technical assistance, or warranty claims, please contact our dedicated support team.
