Wireless Cat Water Fountain Instruction Manual

1. Introduction

Thank you for choosing the FEELNEEDY Wireless Cat Water Fountain. This innovative pet water dispenser is designed to provide fresh, filtered water for your cats and dogs, promoting better hydration and overall health. Featuring a wireless, battery-operated design, smart working modes, and durable stainless steel construction, this fountain offers convenience and peace of mind.

Figure 1: The FEELNEEDY Wireless Cat Water Fountain, showcasing its sleek stainless steel design and water level indicator.

2. Product Features

• Water-Electric Separation & Detachable Battery: Equipped with a 4000mAh battery, this wireless fountain eliminates the need for constant plugging, reducing tripping hazards and allowing flexible placement. A full charge takes approximately 5 hours and provides up to 60 days of worry-free use. The battery module is easily detachable for charging.


Figure 2: Illustrates the water-electric separation design, highlighting the detachable 4000mAh battery for safe and convenient charging.

• 3 Smart Working Modes: Choose from three intelligent modes to suit your pet's needs:
  • Sensor Mode: Water runs for 20 seconds when a pet is detected within a 120° x 5ft range, conserving energy.
  • Timed Mode: Water runs for 15 seconds every 15 minutes.
  • Continuous Mode: Water flows continuously (only available when plugged in).


Figure 3: Visual representation of the three available water flow modes: Infrared Sensor, Timer, and Continuous Flow.

• 304 Stainless Steel Material & Effortless Cleaning: The water tank and tray are constructed from high-quality 304 stainless steel, ensuring durability, safety, and preventing feline acne. These components are dishwasher-safe for easy cleaning.

Figure 4: Demonstrates the ease of cleaning the stainless steel components, with a note that only the water tank and tray are dishwasher-safe.
• 3.5L/118oz Large Capacity: The generous capacity can meet an adult cat's water needs for 10-13 days, ideal for busy owners or short trips. The water tray holds 200ml, providing a reserve in case of power outages.


Figure 5: Highlights the large 3.5L capacity, ensuring sufficient water for extended periods.

• Smart Alerts & Ultra Quiet Operation: The upgraded water pump operates at less than 20dB, quieter than a ticking clock, making it suitable for indoor use and sound-sensitive pets. Built-in reminders notify you when to replace filters and recharge the battery.


Figure 6: Illustrates the low noise level of the fountain, comparing it to common household sounds.

• 4-Layer Recirculation System: Water is continuously filtered through multiple layers: activated carbon for odor removal, ion exchange resin for softening and heavy metal removal, non-woven fabric for trapping hair and impurities, and a high-density pump sponge for fine particles.

Figure 7: Diagram showing the four layers of filtration for circulating water, ensuring freshness.

3. Components Overview

The FEELNEEDY Wireless Cat Water Fountain consists of the following main components:

• Stainless Steel Water Tank: The main reservoir for water.
• Stainless Steel Tray/Top Plate: Sits atop the tank, providing a drinking surface and housing the pump assembly.
• Pump Module: Contains the water pump and smart control unit, including the motion sensor and mode buttons.
• Detachable Battery: 4000mAh rechargeable battery that powers the fountain wirelessly.
• Filter: Multi-layer filter for water purification.
• USB-C Charging Cable: For recharging the detachable battery.

4. Setup Guide

Follow these steps to set up your FEELNEEDY Wireless Cat Water Fountain:

1. Unpack Components: Carefully remove all parts from the packaging. Inspect for any damage.
2. Charge the Battery: Before first use, fully charge the detachable battery module using the provided USB-C cable. The charging port is located on the module.
3. Assemble the Fountain:
   • Place the pump module into its designated slot on the underside of the stainless steel tray. Ensure it is securely fitted.
   • Insert the multi-layer filter into the filter housing on the stainless steel tray, ensuring it sits flat.
   • Place the stainless steel tray onto the water tank, aligning the pump with the central opening.
   • Insert the charged battery module into the slot on the pump module.

Figure 8: Step-by-step visual guide for assembling the fountain components.
4. Fill with Water: Fill the stainless steel water tank with clean water up to the 'MAX' indicator line visible on the side. Do not overfill.
5. Power On: Press the power button on the pump module to turn on the fountain. It will typically default to Sensor Mode.

5. Operating Modes

The fountain offers three operating modes, selectable via the mode button on the pump module:

• Sensor Mode (Recommended for energy saving): The fountain activates for 20 seconds when a pet is detected by the motion sensor within a 120° x 5ft range. This mode conserves battery life.
• Timed Mode: The fountain runs for 15 seconds every 15 minutes, providing regular access to fresh water.
• Continuous Mode: The fountain provides a continuous flow of water. This mode is only available when the fountain is plugged into a power source via the USB-C cable.

To switch between modes, simply press the mode button on the pump module until the desired mode indicator light illuminates.

6. Maintenance

Regular maintenance ensures the longevity and hygiene of your pet water fountain.

• Cleaning:
  • The stainless steel water tank and tray are dishwasher-safe.
  • The pump module and battery module are NOT dishwasher-safe and should never be immersed in water. Clean these components with a damp cloth.
  • It is recommended to clean the fountain thoroughly at least once a week.
• Filter Replacement: The 4-layer filter should be replaced every 2 weeks to ensure optimal water quality and filtration efficiency. Official replacement filters can be found by searching for "B0DXKLM31C".
• Water Level: Monitor the water level using the indicator on the side of the tank. Refill as needed to ensure the pump is always submerged.

7. Troubleshooting

If you encounter any issues with your fountain, please refer to the following common solutions:

• No Water Flow:
  • Check if the battery is charged or if the fountain is properly plugged in (for Continuous Mode).
  • Ensure the water level is above the minimum mark.
  • Verify that the pump is correctly installed and not obstructed.
  • Clean the pump and filter for any debris or hair.
• Unusual Noise:
  • Check the water level; low water can cause pump noise.
  • Ensure the pump is clean and free of debris.
  • Make sure all components are assembled correctly and securely.
• Indicator Lights: Refer to the product's quick start guide for specific meanings of indicator lights (e.g., low power, filter change reminder).

If problems persist, please contact customer support.

8. Specifications

9. Warranty & Support

This FEELNEEDY Wireless Cat Water Fountain (Model FN-W19) comes with a 3-Year Warranty from the date of purchase.

For warranty claims, technical support, or any inquiries, please contact FEELNEEDY customer service through the retailer's platform or visit the official FEELNEEDY store online. Please retain your proof of purchase for warranty validation.
