1. Introduction
Thank you for choosing the VEHHE Filtered Shower Head. This manual provides essential information for the safe and efficient installation, operation, and maintenance of your new shower head. Please read these instructions carefully before use and retain them for future reference.
2. Product Features
- 9 Spray Modes with Pause: Offers a variety of spray settings for a customized showering experience, including a convenient pause mode. The 12.8cm wide panel ensures full-body coverage.
- 6-Stage KDF Filter: Designed to reduce chlorine and impurities from water. This replaceable filter is effective for hard water and acts as a water softener.
- Easy Installation: Simple screw-on design for quick setup.
- Durable Construction: Made from plated ABS with a stainless steel hose and adjustable bracket, suitable for home and RV use.
- Versatile Use: Handheld design is ideal for rinsing hair, bathing children, and washing pets. The filter also benefits hair and skin health.
Figure 2.1: Illustration of the 9 distinct spray modes and the pause function available on the shower head.
Figure 2.2: Detailed diagram showing the layers of the 6-stage KDF filtration system and its purification process.
Figure 2.3: Visual representation of the benefits of filtered water, including improved skin and hair health, and reduction of chlorine and odors.
Figure 2.4: Before and after comparison illustrating the positive impact of filtered water on hair, skin, and overall water quality.
3. Package Contents
Verify that all components are present in the package:
- 1 x Shower Head
- 1 x Stainless Steel Hose (150 cm / 59 inches)
- 1 x Universal Bracket
- 1 x Filter Rod (pre-installed or separate)
- 1 x Teflon Tape
Figure 3.1: Overview of all items included in the VEHHE Filtered Shower Head package, with dimensions.
4. Installation Guide
Follow these steps for proper installation:
- Prepare: Ensure your water supply is turned off before beginning installation. Remove your old shower head and clean any residue from the shower arm threads.
- Apply Teflon Tape: Wrap the included Teflon tape clockwise around the threads of your shower arm 3-5 times.
- Install Bracket: Screw the universal bracket onto the shower arm. Hand-tighten first, then use a wrench if necessary, but do not overtighten.
- Connect Hose: Attach one end of the stainless steel hose to the bracket and the other end to the handheld shower head. Ensure washers are in place at both connections to prevent leaks. Hand-tighten securely.
- Install Filter Rod (if separate): If your filter rod is not pre-installed, gently insert it into the shower head handle as shown in the diagram below.
- Test: Turn on the water supply and check for any leaks. If leaks occur, tighten connections slightly.
Figure 4.1: Step-by-step visual guide for installing the filter element into the shower head handle.
5. Operating Instructions
Your VEHHE Filtered Shower Head offers multiple spray settings for a personalized shower experience.
- Changing Spray Modes: Rotate the spray dial on the shower head face to cycle through the 9 available spray patterns (e.g., Massage, Fan-Shaped Outlet, Misty, Saturating, Power Jet, Wide Fan, and combinations).
- Pause Function: Use the dedicated pause button or lever on the shower head to temporarily stop water flow, conserving water while lathering or performing other tasks.
- Filter Operation: The integrated 6-stage KDF filter continuously purifies water as it passes through the shower head.
Figure 5.1: Examples of using the built-in power wash mode for cleaning tasks such as toilets, drains, tiles, and bathtubs.
Figure 5.2: Versatile applications of the handheld shower head for adults, children, and pets.
6. Maintenance
- Filter Replacement: The 6-stage KDF filter should be replaced approximately every 3 to 6 months, depending on your local water quality and usage frequency. To replace, unscrew the shower head handle, remove the old filter rod, insert a new one, and reassemble.
- Nozzle Cleaning: The liquid silicone shower head water outlets can be gently wiped to remove scale buildup, especially in hard water areas. This helps maintain optimal spray performance.
- General Cleaning: Clean the exterior of the shower head and hose with a soft cloth and mild soap. Avoid abrasive cleaners that may damage the finish.
Figure 6.1: Reminder to replace the filter element every 3-6 months based on water quality.
7. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Low water pressure | Clogged nozzles or filter; kinked hose; low household water pressure. | Clean nozzles by gently wiping. Replace filter if due. Check hose for kinks. Consult a plumber for household water pressure issues. |
| Leaks at connections | Loose connections; missing or worn washers; insufficient Teflon tape. | Ensure all connections are hand-tightened. Check that washers are properly seated. Apply more Teflon tape if needed. |
| Hose leaking | Damage to the hose. | Inspect the hose for visible damage. If damaged, the hose may need to be replaced. |
8. Specifications
| Feature | Detail |
|---|---|
| Brand | VEHHE |
| Model Number | SDGLCA-SLR |
| Colour | Silver |
| Material | Acrylonitrile Butadiene Styrene (ABS) |
| Finish Type | Brushed |
| Installation Type | Wall Mounted |
| Product Dimensions (L x W) | 28.8L x 12.8W centimetres (11.3 x 5 inches) |
| Hose Length | 150 centimetres (59 inches) |
| Number of Spray Modes | 9 (including Pause) |
| Filter Type | 6-Stage KDF Filter |
| Included Components | Shower Head, Stainless Steel Hose, Universal Bracket, Filter Rod, Teflon Tape |
Figure 8.1: Key features and components of the VEHHE Filtered Shower Head, including the stainless steel hose and adjustable joint.
Figure 8.2: Visual comparison highlighting the high-pressure and high-flow design of the VEHHE shower head.
9. Warranty and Support
VEHHE is committed to providing quality products and customer satisfaction. For any questions, concerns, or support needs regarding your shower head, please contact VEHHE customer service through the retailer where you purchased the product. Please have your model number (SDGLCA-SLR) and purchase information ready.
For more information about VEHHE products, you can visit the official VEHHE store online.
