1. Safety Information
Please read all safety warnings and instructions carefully before using the AKOASM Rollator Walker and Wheelchair Combo. Failure to follow these instructions may result in injury.
- Walker Only — NOT a wheelchair replacement. This device is designed as a mobility aid for walking and temporary transport, not a full-time wheelchair.
- Do NOT use if damaged or missing parts. Inspect the device before each use.
- Test brakes before each use to ensure proper function.
- Avoid rough, uneven, or obstacle-heavy paths to prevent slips or tips.
- Move at a steady, controlled pace — NO sudden speeds or abrupt changes in direction.
- Ensure all locking mechanisms are engaged before sitting or using the device as a transport chair.
- Do not exceed the maximum weight capacity of 300 lbs.
- Always use the safety fastening straps on the waist and footrest when using as a transport chair.
2. Product Overview
The AKOASM Foldable Rollator Walker with Seat and Wheelchair Combo is a versatile mobility solution designed for comfort, stability, and ease of use. It functions as both a rollator walker and a transport chair, offering flexibility for various mobility needs.
Key Features
- Adjustable Handle & Seat Height: 6-level handle adjustment (33"-41") and 3-level seat adjustment (20.7"-23") for personalized comfort. Ideal for users 5'6" to 6'6".
- Thicker and Wider Seat & Backrest: Waterproof, durable PU seat with high-density foam and a sturdy wooden frame. 7.7" widened, thickened, breathable backrest for optimal comfort.
- 3-Mode Braking System: Features Free, Slow, and Stop modes for enhanced safety on various terrains and in crowded areas.
- Fast Folding & Storage: Folds quickly and includes a locking mechanism for stability when folded, making it easy to store and transport.
- Lightweight & Easy to Assemble: Weighs only 25 pounds with a maximum load capacity of 300 pounds. Simple, tool-free assembly.
- Excellent Durability & Stability: Equipped with 10-inch all-terrain rubber front wheels for superior stability, durability, and shock absorption. Features reflective strips for added safety.
- Integrated Storage: Includes a large detachable storage bag under the seat and a concealed Velcro-secured pocket for personal items.
- Sturdy Aluminum Main Frame: High-quality aluminum construction with a triangular mechanical structure for easy maneuverability and exceptional durability.
- Additional Accessories: Anti-slip cup holder and walking stick rack included.
Visual Overview
3. Setup Instructions
The AKOASM Rollator Walker is designed for easy assembly without additional tools. Follow these steps to set up your device.
3.1 Unboxing and Initial Assembly
Refer to the video below for a visual guide on the initial assembly process, including unfolding the main frame and attaching the wheels and handles.
Video 3.1: This video demonstrates the step-by-step installation of the AKOASM 2-in-1 Walker Wheelchair Combo, covering unfolding the frame, attaching front and rear wheels, and securing handles.
3.2 Attaching Footrests
The footrests are easily attached for converting the rollator into a transport chair. Ensure they are securely locked into place.
Video 3.2: This video illustrates the process of attaching and detaching the footrests, and demonstrates the seamless transition between rollator and transport chair modes.
3.3 Adjusting Height
Adjust the handle and seat height to your preference for optimal comfort and posture. The device offers multiple adjustment levels.
Video 3.3: This video shows how to adjust the height of the handles and seat, as well as the folding mechanism for compact storage.
3.4 Step-by-Step Setup Guide
- Unfold the walker: Gently pull the frame apart until it fully extends and all parts are securely attached.
- Adjust Handle Height: Use the 6-level adjustment mechanism to set the handles to your preferred height. Ensure both handles are at the same level.
- Adjust Seat Height: Utilize the 3-level adjustment to set the seat to a comfortable height.
- Check Brakes: Before use, ensure the brakes are in the 'Stop' position.
- Positioning: Grip the handles firmly and ensure a stable stance.
- Braking System: Familiarize yourself with the 3-mode braking system (Free/Slow/Stop) to control speed and stability.
- Footrests (if applicable): If using as a transport chair, attach the footrests by aligning them at a 60-75 degree angle to the frame slot and pushing them in until they click.
- Accessories: Attach the cup holder and cane holder to their designated slots on the frame.
4. Operating Instructions
This section details how to operate your AKOASM mobility aid in both rollator and transport chair modes.
4.1 Using as a Rollator Walker
- Ensure the footrests are either detached or retracted if not being used.
- Adjust the handle height so your elbows are slightly bent when holding the grips.
- Walk behind the rollator, pushing it forward. Maintain a comfortable distance and posture.
- Use the hand brakes to control speed. Squeeze the levers for active braking, or push them down to lock the wheels for parking.
- To sit, ensure the brakes are locked (Park mode) and carefully lower yourself onto the seat.
4.2 Using as a Transport Chair
- Attach the footrests as described in the setup section.
- Ensure the user is seated comfortably and securely. Use the waist safety strap and foot fixation bands for added security.
- The person pushing the chair should stand behind it, holding the handles.
- Push the chair forward, maintaining a steady pace.
- Use the hand brakes to control speed and stop the chair. Always engage the Park mode when the chair is stationary.
Video 4.1: This video demonstrates the versatility of the AKOASM 2-in-1 device, showcasing its use as both a rolling walker and a transport wheelchair, including the easy conversion process.
4.3 Braking System
- Free Mode: Brakes are disengaged, allowing the wheels to roll freely.
- Slow Mode: Partially engage the brakes by gently squeezing the levers to provide resistance, useful for controlling speed on inclines or declines.
- Stop (Park) Mode: Push the brake levers down until they lock into place. This locks the wheels, preventing movement when sitting or standing. Always engage Park mode when stationary.
4.4 Folding and Storage
- Ensure the device is empty of all personal items.
- Retract or remove the footrests.
- Pull the folding strap (usually located on the seat) upwards to initiate the folding mechanism.
- Once folded, secure the device with the specially designed locking mechanism or strap to maintain its compact form.
- The compact size allows for easy storage in a car trunk or for air travel.
5. Maintenance
Regular maintenance ensures the longevity and safe operation of your AKOASM Rollator Walker.
- Cleaning: Wipe down the frame and seat with a damp cloth and mild soap. Avoid abrasive cleaners. The waterproof PU seat is easy to clean.
- Wheel Inspection: Regularly check the 10-inch all-terrain rubber wheels for wear and tear. Ensure they rotate freely and are free of debris.
- Brake Check: Periodically test the braking system to ensure it engages effectively in all three modes (Free/Slow/Stop). Adjust if necessary (consult a professional if unsure).
- Fastener Check: Ensure all screws, bolts, and locking mechanisms are tight and secure. Do not overtighten.
- Storage: Store the rollator in a dry, clean place when not in use.
6. Troubleshooting
This section addresses common issues you might encounter with your AKOASM Rollator Walker.
- Wheels not rolling smoothly: Check for debris (hair, lint) caught in the wheel axles. Clean as needed. Ensure wheels are properly attached and not loose.
- Brakes not engaging/disengaging properly: Inspect the brake cables for kinks or damage. Ensure the brake levers are not obstructed. If the issue persists, professional adjustment may be required.
- Device feels unstable: Verify that all frame components are fully extended and locked into place. Check that the locking knobs for the wheels and handles are securely tightened. Ensure the weight capacity is not exceeded.
- Difficulty folding: Ensure all accessories (bag, cup holder, cane holder) are removed. Check for any obstructions in the folding mechanism.
- Footrests not attaching securely: Ensure the footrests are aligned correctly at the specified angle (60-75 degrees) before pushing them into the frame slots.
7. Specifications
| Feature | Detail |
|---|---|
| Product Dimensions | 39"D x 24.9"W x 41"H |
| Item Weight | 25 Pounds |
| Maximum Weight Capacity | 300 Pounds |
| Material | Aluminum |
| Color | Grey |
| Handle Height Adjustment | 6 levels (33" - 41") |
| Seat Height Adjustment | 3 levels (20.7" - 23") |
| Backrest Width | 7.7 inches |
| Wheel Type | 10-inch All-Terrain Non-Pneumatic Rubber Front Wheels |
| Braking System | 3-Mode (Free/Slow/Stop) |
| Model Number | WALKER FOR SENIORS KLD1005 |
8. Warranty and Support
AKOASM is committed to providing high-quality products and customer satisfaction.
8.1 Contact Information
For any inquiries, assistance, or support regarding your AKOASM Rollator Walker, please do not hesitate to contact us. We assure a response within 24 hours.
Please refer to your purchase documentation or the AKOASM official website for specific contact details.
8.2 Legal Disclaimer
Statements regarding dietary supplements have not been evaluated by the FDA and are not intended to diagnose, treat, cure, or prevent any disease or health condition. This product is a mobility aid and not a medical device intended for diagnosis, treatment, or prevention of any disease.
