Gartory Solar Animal Repeller Instruction Manual

Introduction

Thank you for choosing the Gartory Solar Animal Repeller. This device is designed to deter various animals from your garden, yard, or farmland using advanced ultrasonic technology, flashing lights, and alarm sounds. It features a 360° induction design for comprehensive coverage and is powered by solar energy with a USB charging option. Please read this manual carefully before use to ensure proper installation and operation.

Image: The Gartory Solar Animal Repeller effectively deters various animals from your property.

Safety Information

• Keep the device out of reach of children.
• Do not immerse the device completely in water, despite its IP66 waterproof rating. Ensure it is at least 5 inches above ground if water accumulates.
• Do not attempt to open or modify the device. Refer all servicing to qualified personnel.
• The ultrasonic frequency is designed not to harm humans, but prolonged direct exposure to the ultrasonic speaker at close range is not recommended.
• Ensure the solar panel is clean and free of obstructions for optimal charging.

Product Features

• 360° Protection: Features a double-sided induction design with front and rear infrared sensors covering a 240° area, providing a longer sensing distance and wider range compared to single-sided repellents.
• Dual Ultrasonic Horns: Equipped with ultrasonic horns on both sides for enhanced coverage.
• 7 Operation Modes: Offers multiple modes to target different animals and environments. Modes 1-6 are for ground animals, while the last mode uses a buzzer for underground animals like rats and snakes.
• Solar & USB Charging: Primarily charged by high-conversion polysilicon crystal solar panels. Can also be charged via USB on cloudy or rainy days. Features a 2200mAh battery for extended use.
• IP66 Waterproof: Constructed from high-quality ABS resin with an IP66 waterproof rating, allowing normal operation in various weather conditions.
• Wide Sensing Range: Infrared sensing angle of 240° with a sensing distance of 1-12 meters (3-39 feet), depending on animal size and temperature.

Image: The repeller is designed for all-weather use with IP66 waterproofing and flexible charging options.

Image: The device provides 360° all-around protection with burst lights and a wide infrared sensor range.

Product Diagram and Components

Familiarize yourself with the different parts of your Gartory Solar Animal Repeller:

Image: Labeled diagram of the repeller's components for easy identification.

• PIR Sensor: Passive Infrared sensor for motion detection.
• Solar Panel: Converts sunlight into electrical energy for charging.
• Ultrasonic Speaker: Emits high-frequency sound waves to deter animals.
• USB Charging Port: For alternative charging via USB cable.
• Gear/Mode Adjustment: Dial or button to select different operating modes.
• LED Flash Light: Flashing lights to scare away animals, especially at night.
• Connecting Rod: Connects the main unit to the mounting rod.
• Mounting Rod: Stake for inserting the device into the ground.
• Buzzer Interface: Connection point for the buzzer (for seismic wave mode).
• Lithium Battery: Internal rechargeable battery.

Setup and Installation

1. Unpack: Carefully remove all components from the packaging.
2. Assemble: Connect the main repeller unit to the connecting rod, and then attach the mounting rod to the connecting rod.
3. Placement: Choose an outdoor location that receives ample direct sunlight for the solar panel to charge effectively. Ensure the area is clear of obstructions that might block the PIR sensor's view.
4. Ground Insertion: Gently push the mounting rod into the ground. Ensure the repeller unit is at least 5 inches above the ground to prevent submersion during heavy rain.
5. Initial Charge: For first-time use, it is recommended to fully charge the device using the provided USB cable for 4-6 hours, especially if solar charging conditions are not ideal.

Operating Instructions

The Gartory Solar Animal Repeller offers 7 distinct operating modes. Use the Gear/Mode Adjustment dial/button to select the desired mode based on the type of animal you wish to deter.

Image: Detailed breakdown of the 7 operational modes and their functions.

Note: The device is triggered by motion detection. The working frequency for most modes is triggered every 5 minutes when an animal is detected.

Charging

Your Gartory Solar Animal Repeller is designed for efficient power management:

• Solar Charging: The primary charging method. Ensure the solar panel is exposed to direct sunlight for several hours daily. Clean the panel regularly to maximize efficiency.
• USB Charging: In prolonged cloudy or rainy weather, or for initial charging, use the provided Type-C USB cable to charge the device. Connect the cable to the USB Charging Port and a standard USB power adapter (not included). A full charge can last for more than 10 days.

Maintenance

• Cleaning: Regularly wipe the solar panel and the device body with a soft, damp cloth to remove dust, dirt, or debris. Do not use abrasive cleaners or solvents.
• Placement Check: Periodically check the device's placement to ensure it remains securely in the ground and is not submerged in water, especially after heavy rainfall.
• Battery Care: While the device has a built-in battery, avoid storing it for extended periods with a completely depleted battery. If storing, ensure it has a partial charge.

Troubleshooting

Specifications

• Model: B0DXKCQ6LZ
• Dimensions: 7.01 x 6.18 x 3.31 inches (Package)
• Weight: 1.1 pounds
• Waterproof Rating: IP66
• Battery: 2200mAh Lithium Battery
• Sensing Angle: 240° (Infrared)
• Sensing Distance: 1-12 meters (3-39 feet)
• Ultrasonic Frequency: 13.5kHz-65.5kHz
• Charging: Solar Panel, Type-C USB Port

Package Contents

The package for your Gartory Solar Animal Repeller includes the following items:

Image: Contents included in the product package.

• 1 x Packing Box
• 1 x Animal Repeller Unit
• 1 x Mounting Rod (consisting of connecting rod and ground stake)
• 1 x Type-C USB Cable

Warranty and Support

Gartory provides customer support for its products. If you encounter any issues or have questions regarding your Solar Animal Repeller, please do not hesitate to contact us. We aim to provide a satisfactory reply within 24 hours.

Please refer to your purchase platform or retailer for specific warranty details and return policies.
