1. Introduction
Thank you for choosing the FOGARI Touch Keyboard Case. This manual provides detailed instructions for setting up, operating, and maintaining your new keyboard case, designed to enhance your iPad experience by transforming it into a versatile laptop-like device.
Image 1.1: The FOGARI Touch Keyboard Case with an iPad, showcasing its integrated design and backlit keyboard.
What's in the Box:
- FOGARI Touch Keyboard Case
- USB Cable (Type-C)
- User Manual (this document)
2. Compatibility
This keyboard case is designed for specific iPad models. Please verify your iPad model number (found on the back of your tablet) against the list below to ensure compatibility.
Image 2.1: Visual guide to compatible iPad models and their corresponding model numbers.
Compatible Models:
- New iPad Air 13-inch (M3, 2025): A2925, A2926, A3007
- iPad Air 13-inch (M2, 2024): A2898, A2899, A2900
- iPad Pro 13-inch (M4, 2024): A2925, A2926, A3007
- iPad Pro 12.9-inch (6th Gen, 2022): A2436, A2437, A2764, A2766
- iPad Pro 12.9-inch (5th Gen, 2021): A2378, A2379, A2461, A2462
- iPad Pro 12.9-inch (4th Gen, 2020): A2229, A2069, A2232, A2233
- iPad Pro 12.9-inch (3rd Gen, 2018): A1876, A2014, A1985, A1983
Note: This keyboard case is NOT compatible with iPad Pro 12.9-inch 1st Gen (A1584/A1652) or 2nd Gen (A1670/A1671/A1821).
3. Setup Instructions
3.1 Inserting Your iPad:
- Gently align your iPad with the case's frame.
- Press firmly around the edges until the iPad is securely seated within the protective hardshell. Ensure all corners are properly fitted.
- The case is designed to hold your iPad firmly, preventing accidental slipping.
Image 3.1: Illustration of how the iPad fits securely into the case, highlighting the pencil charging area and full protection.
3.2 Bluetooth Pairing:
- Ensure the keyboard case is charged (refer to Section 5 for charging instructions).
- Turn on the keyboard by sliding the power switch located on the side of the keyboard. The indicator light will flash.
- On your iPad, go to Settings > Bluetooth.
- Turn on Bluetooth. Your iPad will search for available devices.
- Locate and select "FOGARI Keyboard" (or similar name) from the list of devices.
- If prompted, enter the pairing code displayed on your iPad using the keyboard, then press Enter.
- Once paired, the indicator light on the keyboard will turn off, and your iPad will show the keyboard as "Connected."
4. Operating Instructions
4.1 Keyboard Features:
The keyboard features a standard key layout and includes a full set of iPadOS multimedia shortcuts for convenient control.
Image 4.1: Overview of the keyboard's features, including 360-degree rotation, 7-color backlight, and iPadOS shortcuts.
Backlight Control:
The keyboard features 7-color backlighting and 2 breathing backlight modes, allowing for comfortable typing in various lighting conditions.
Image 4.2: Detailed view of the keyboard's 7-color backlight and breathing modes, with key combinations for control.
- Turn on/off backlight or adjust brightness: Press Fn + ⌘ (light icon key). Repeat to cycle through brightness levels.
- Switch backlight color: Press Fn + → (right arrow key).
- Turn on/off breathing backlight function: Press Fn + Q.
- Adjust breathing backlight rate: Press Fn + W.
iPadOS Shortcuts:
Utilize the dedicated function row for quick access to common iPadOS features:
- Home, Search, Screenshot, Keyboard Hide/Show, Media Controls (Previous, Play/Pause, Next), Volume Controls (Mute, Down, Up), Lock Screen.
4.2 Precise Multi-Touch Trackpad:
The integrated multi-touch trackpad provides precise responses for navigation, editing, browsing, and video control, transforming your iPad into a laptop-like device.
Image 4.3: Close-up view of the precise multi-touch trackpad, illustrating smooth and sensitive operation for various gestures.
Trackpad Gestures:
- Single Finger Tap: Click/Select
- Two Finger Scroll: Scroll up/down or left/right
- Two Finger Pinch: Zoom in/out
- Three Finger Swipe Up: Open App Switcher
- Three Finger Swipe Down: Return to Home Screen
- Three Finger Swipe Left/Right: Switch between open apps
- Four Finger Pinch: Return to Home Screen
4.3 360° Rotatable Hinge & Usage Modes:
The robust 360° rotatable hinge allows for versatile positioning, offering 7 different usage modes to suit various activities.
Image 4.4: Examples of the keyboard case in different usage scenarios, including working, drawing, and carrying.
- Laptop Mode: Traditional laptop setup for typing and trackpad use.
- Stand Mode: Fold the keyboard back to prop up the iPad for viewing.
- Tent Mode: Invert the case to create a stable tent shape for media consumption.
- Tablet Mode: Fold the keyboard completely behind the iPad for handheld tablet use.
- Corner Mode: Adjust the angle for comfortable drawing or writing.
- Share Mode: Rotate the screen 180 degrees to share content with others.
- Protect Mode: Close the case to fully protect the iPad and keyboard.
4.4 Built-in Pencil Holder:
The case includes a built-in holder for your Apple Pencil, ensuring it is securely stored and easily accessible for charging and use.
4.5 Wake/Sleep Feature:
The keyboard case supports automatic wake/sleep functionality. Opening the case will wake your iPad, and closing it will put your iPad to sleep, conserving battery life.
Image 4.5: Visual representation of the automatic wake/sleep feature, showing the iPad screen turning on when opened and off when closed.
5. Charging the Keyboard
The keyboard case is equipped with a rechargeable lithium battery. Use the provided USB-C cable to charge the keyboard.
Image 5.1: The keyboard case connected to a USB-C charging cable, indicating the charging port location.
- Charging Time: Approximately 3 hours for a full charge.
- Working Time (backlight off): Up to 72 hours.
- Standby Time: Up to 90 days.
Connect the USB-C end of the cable to the charging port on the keyboard and the USB-A end to a power adapter (not included) or a computer's USB port. The charging indicator light will illuminate during charging and turn off when fully charged.
6. Maintenance and Care
To ensure the longevity and optimal performance of your FOGARI Touch Keyboard Case, follow these maintenance guidelines:
6.1 Cleaning:
- Use a soft, lint-free cloth to wipe down the exterior of the case and keyboard.
- For stubborn marks, slightly dampen the cloth with water or a mild, non-abrasive cleaner. Avoid excessive moisture.
- Do not use harsh chemicals, solvents, or abrasive materials, as these can damage the surface.
- Ensure the keyboard is powered off before cleaning.
6.2 Protection:
The premium hardshell provides robust front and back protection for your iPad, preventing scratches, fingerprints, and dust in daily use.
Image 6.1: The keyboard case offering full body protection for the iPad, safeguarding it from daily wear and tear.
- Avoid dropping the case or subjecting it to strong impacts.
- Keep the case away from extreme temperatures and direct sunlight.
- Do not expose the keyboard to liquids. While it offers some water resistance, it is not waterproof.
7. Troubleshooting
If you encounter issues with your FOGARI Touch Keyboard Case, please refer to the following common solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Keyboard not connecting via Bluetooth. | Keyboard is off, low battery, Bluetooth off on iPad, or pairing issue. | Ensure keyboard is on and charged. Turn iPad Bluetooth off and on. Forget the device in iPad Bluetooth settings and re-pair. |
| Keyboard not responding. | Low battery, connection lost, or iPad software issue. | Charge the keyboard. Reconnect Bluetooth. Restart your iPad. |
| Backlight not working or stuck. | Backlight off, low battery, or setting issue. | Ensure backlight is turned on (Fn + ⌘). Charge the keyboard. Try cycling through backlight colors (Fn + →). |
| Trackpad not working. | Trackpad disabled, connection issue, or iPad settings. | Ensure trackpad is enabled in iPad settings (Settings > General > Trackpad). Reconnect Bluetooth. |
| Keys are sticky or unresponsive. | Dust or debris under keys. | Gently clean around and under the keys with compressed air or a soft brush. |
If the problem persists after trying these solutions, please contact FOGARI customer support for further assistance.
8. Specifications
| Feature | Detail |
|---|---|
| Product Dimensions | 12.64 x 10.04 x 1.2 inches (32.1 x 25.5 x 3.05 cm) |
| Item Weight | 2.68 pounds (1.22 kg) |
| Connectivity Technology | Bluetooth, USB-C (for charging) |
| Keyboard Description | Multimedia, Standard QWERTY |
| Special Features | Backlit (7-color RGB), Ergonomic, Rechargeable, Trackpad, Water Resistant (splash-proof) |
| Battery Capacity | 450mAh (Rechargeable Lithium Battery) |
| Charging Port | USB Type-C |
| Manufacturer | FOGARI |
9. Warranty and Support
9.1 Warranty Information:
FOGARI products typically come with a standard manufacturer's warranty. Please refer to the product packaging or the official FOGARI website for specific warranty terms and conditions applicable to your region. Keep your purchase receipt as proof of purchase for warranty claims.
9.2 Customer Support:
For technical support, troubleshooting assistance, or any inquiries regarding your FOGARI Touch Keyboard Case, please contact FOGARI customer service through the retailer's platform where you purchased the product or visit the official FOGARI brand store on Amazon:
Visit the FOGARI Store on Amazon
When contacting support, please have your product model number (B0DX2618DC) and a detailed description of the issue ready.
