ZOWEETEK Voice Amplifier with Wireless Lavalier Lapel Microphone User Manual

1. Product Overview

The ZOWEETEK Voice Amplifier is a portable personal microphone system designed to amplify your voice clearly and effectively. It is ideal for teachers, public speakers, meeting facilitators, yoga instructors, and anyone needing to project their voice without strain. This system includes a compact voice amplifier and a wireless lavalier microphone, offering freedom of movement and high-fidelity sound.

The ZOWEETEK Voice Amplifier and its accompanying wireless lavalier microphone.

Key features of the ZOWEETEK Voice Amplifier system, including HiFi original sound, portability, 10W output, 2.4G lavalier microphone, 1800mAh battery, music player function, TF card support, and USB disk compatibility.

Dimensions of the voice amplifier (4.13 inches height, 3.35 inches width, 1.42 inches depth) and the microphone (5.9 inches height, 0.92 inches width, 0.8 inches depth), along with their respective weights.

2. What's in the Box

Upon opening your ZOWEETEK Voice Amplifier package, please ensure all the following items are present:

• 1 x Wireless voice amplifier
• 1 x Wireless lavalier microphone
• 1 x Adjustable waistband
• 1 x Charging plug and Type-C charging cable
• 1 x User Manual

All components included in the ZOWEETEK Voice Amplifier package: the amplifier, wireless microphone, adjustable waistband, charging cable and plug, and user manual.

3. Setup Guide

3.1 Charging the Devices

Before first use, fully charge both the voice amplifier and the wireless microphone. Use the provided charging cable and plug.

• Voice Amplifier: Working time 8-12 hours, Charging time 3-5 hours.
• Wireless Microphone: Working time 4-6 hours, Charging time 2-3 hours.

An illustration showing the working and charging times for both the voice amplifier and the wireless microphone.

3.2 Pairing the Microphone and Amplifier

The wireless voice amplifier and microphone are designed for quick and automatic pairing. They should connect within 2 seconds of being powered on.

1. Turn on the voice amplifier by rotating the volume/power knob.
2. Turn on the wireless microphone.
3. The devices will automatically pair. A successful connection is indicated by a stable blue light on the microphone.

If the microphone has no sound after pairing:

• Method 1: Long press the "M" key on the voice amplifier.
• Method 2: Long press the wireless signal key on the microphone.

Diagram illustrating the 2-second pairing process between the voice amplifier and the wireless microphone, and troubleshooting steps if no sound is produced.

4. Operating Instructions

4.1 Using the Voice Amplifier

1. Power On/Off and Volume Control: Rotate the volume knob on the amplifier to turn it on or off and adjust the volume level.
2. Wearing the Amplifier: Use the adjustable waistband to wear the amplifier comfortably around your waist or clip it to your clothing.
3. Microphone Placement: Clip the wireless lavalier microphone to your collar or lapel, ensuring it is close to your mouth for optimal sound pickup. The microphone can also be held.

The wireless microphone offers versatility, allowing it to be used as a handheld microphone or clipped as a lavalier microphone.

Close-up view of the lavalier microphone clipped to clothing, demonstrating its discreet and effective placement for voice amplification.

4.2 Music Playback

The ZOWEETEK Voice Amplifier supports music playback from TF (Micro SD) cards and USB flash drives.

• Insert your TF card or USB flash drive into the corresponding slot on the amplifier.
• Use the control buttons on the amplifier to play, pause, skip tracks, and loop music.

4.3 Application Scenarios

A teacher effectively using the voice amplifier in a classroom setting, ensuring their voice is clearly heard by all students.

An instructor leading a yoga session, utilizing the voice amplifier to provide clear instructions to participants.

A speaker presenting to an audience, with the voice amplifier ensuring their voice carries across the room for effective communication.

5. Maintenance

To ensure the longevity and optimal performance of your ZOWEETEK Voice Amplifier, follow these maintenance guidelines:

• Cleaning: Wipe the amplifier and microphone with a soft, dry cloth. Do not use liquid cleaners or abrasive materials.
• Storage: Store the device in a cool, dry place away from direct sunlight and extreme temperatures.
• Battery Care: Avoid fully discharging the battery frequently. Charge the device regularly, even if not in use for extended periods, to maintain battery health.
• Handling: Handle the devices with care to prevent drops or impacts, which can damage internal components.

6. Troubleshooting

If you encounter issues with your ZOWEETEK Voice Amplifier, please refer to the following common problems and solutions:

Important note: Do not place the microphone directly in front of or too close to the voice amplifier, as this can cause unwanted noise or feedback.

7. Specifications

8. Warranty and Support

ZOWEETEK stands behind the quality of its products. For warranty information, technical support, or any inquiries regarding your Voice Amplifier, please contact ZOWEETEK customer service directly. Refer to the contact information provided in the product packaging or on the official ZOWEETEK website.

Manufacturer: ZOWEETEK

Website: Visit the ZOWEETEK Store on Amazon
